Xtrfy XG1-R LED User Manual

Backlit mechanical keyboard

Advertisement

Quick Links

1. QTLA Hardware Macro – Functions
• XG1-R LED has an extra internal memory and it supports hardware macro function
which records the user defined macro keys directly and promptly without any S/W.
• Hard-ward Macro doesn't need any software or extra driver to set/use Macro feature. Even
though user connects XG1-R LED to other PCs, user can use the same macro features
Instantly without any installation of S/W or Driver. Just it's true plug and play.
• XG1-R LED supports professional hardware macro features (4 distinct and different
modes: Quick, Timing, Loop, Auto). So, we call it 'QTLA' Hardware Macro after the first
initials of them.
• Factory defaults of 8 macro keys are same with F1~F8. 'FN' key also works as 'ESC' when
it's (pressed) entered alone.
• 'Macro' is to record the sequences of keystrokes and run the sequences when the
nominated macro key is entered.
2. QTLA Hardware Macro
Quick Macro
• When a macro is recorded and programmed via Quick Macro, it ignores the time interval
(Q1~Q3)
among each key input and runs the macro (nominated and input keys) with the fastest
speed (30CPS) which OS can accept and support.
• For sample, even though user records and program "He..l....l..o!" with different time interval
among each character via Quick Macro, it runs "Hello!" with the fastest speed when the
macro key is entered. It's very useful for users to use their frequently used or repetitive
sequences in gaming and office.
User Manual
1
Ver. A

Advertisement

loading
Need help?

Need help?

Do you have a question about the XG1-R LED and is the answer not in the manual?

Questions and answers

Summary of Contents for Xtrfy XG1-R LED

  • Page 1 • Hard-ward Macro doesn’t need any software or extra driver to set/use Macro feature. Even though user connects XG1-R LED to other PCs, user can use the same macro features Instantly without any installation of S/W or Driver. Just it’s true plug and play.
  • Page 2 Timing Macro • When a macro is recorded and programmed via Timing Macro, it remembers not only the (T1~T3) input keys, but also the exact time interval among each key input. So, the macro runs the input keys with the same time intervals which user make in the previous macro setting. •...
  • Page 3 Second, record and nominate new Timing or Quick Macro. When recording the new Timing or Quick Macro, just nominate the first Macro (ex: Q1) key as the last input key. Then, 2 Macro keys run in order. We call it ‘Macro in Macro”. It’s a unique and special function of XG1-R LED.
  • Page 4 4. LED Introduction • XG1-R LED supports innovative and brilliant LED effects which you’ve never experienced. • Press <FN> button and keep it pressed, it shows the current LED mode and status. (LED on each related key lights on) • If “Back Light” brightness is set (adjusted) brightly and “Key LED”...
  • Page 5 Key Mask Mode • Turn on your favorite keycaps (LED) only, and then the lighted keys work <FN> + <F8> only. In this mode, other keys don’t work even though they’re pressed. After pressing <FN> + <F12>, then select your favorite keycaps you want to light up and work.
  • Page 6: Function Key

    5. Repeat Speed Control • Repeat Speed Control (10 steps) • To adjust and change the Repeat Speed, press <FN>+<Num Pad ‘0~9’> together. • <FN>+<Num ‘0’> is standard speed and <FN>+<Num ‘9’> is the fastest repeat speed. • Repeat Speed means the input speed of one key which is pressed continuously. 6.
