Summary of Contents for MOTU 112D

  • Page 1 112D ™ User Guide Title Page 1280 Massachusetts Avenue Cambridge, MA 02138 Business voice: (617) 576-2760 Business fax: (617) 576-3609 Web site: www.motu.com Tech support: www.motu.com/support...

  • Page 2: Important Safeguards

    The MOTU product is equipped with a three-conductor cord and grounding type plug which has a grounding prong, approved by Underwriters' Laboratories and the Canadian Standards Association. This plug requires a mating three-conductor grounded type outlet as shown in Figure A below. If the outlet you are planning to use for the MOTU product is of the two prong type, DO NOT REMOVE OR ALTER THE GROUNDING PRONG IN ANY MANNER.

  • Page 3: Table Of Contents

    112D Rear Panel MOTU AVB Control Web App About the 112D Packing List and System Requirements Software Installation Hardware Installation Part 2: Using the 112D Presets The Front Panel LCD Working with Host Audio Software Mixer Effects Networking Part 3: Appendices...
  • Page 4 Authorization Number on the outside of the box below the shipping address. That license agreement is a contract, and clicking “Accept” binds you and MOTU to This warranty does not apply if the equipment has been damaged by accident, all its terms and conditions.

  • Page 5: Part 1: Getting Started

    Part 1 Getting Started...

  • Page 7: Quick Start Guide

    ☛ Your iPhone and iPad must be on the same Wi-Fi network as your computer. 3 Connect the 112D to your computer with a USB cable (included) or Thunderbolt cable (sold separately). If you have a Thunderbolt-equipped Mac running OS X Yosemite (10.10) or later, you can alternately connect the 112D to the Mac’s...

  • Page 9: D Front Panel

    112D employs the SMUX and-play” protocols. That means that you can turn off standard. 7. Push ID to display network settings for the device, the 112D and turn it back on without restarting your including its IP address. computer.

  • Page 10: D Rear Panel

    (labeled in blue), using the SMUX standard. ■ cannot slave to the clock supplied by their digital I/O interface, such as the 1248, 8M, 16A, 24Ai, 24Ao, 112D, connection with the 112D. 6. This section provides 24 channels of AES/EBU digital I/O Monitor 8, etc.

  • Page 11: Motu Avb Control Web App

    Obtaining the 112D’s IP address AVB WebUI Setup (Windows) and other software On the front panel of the 112D, push the ID button elements. Visit the Apple App Store to download once. The LCD now displays the unit’s IP address, the discovery app onto your iPad or iPhone.
  • Page 12 DEVICE TAB 1. If you have two or more MOTU AVB 8. Choose the desired sample rate. 13. Choose the clock source from the 17. If you have AVB network input interfaces, the Device list lets you Clock Mode menu. Your MOTU device streams enabled (18), connect them 9.
  • Page 13 Doing so hides them from a file can be done offline from your channels you would like to be able to 26. The digital mixer in the 112D the routing matrix and mixer to computer, using an update you’ve stream to and from your computer, supports up to 48 channels.
  • Page 14 ROUTING TAB The Routing Tab lets you route inputs to 6. When you make a connection, the ure how many AVB streams you wish 14. Here, local inputs (ADAT bank A and outputs. Inputs are listed in columns source (input) signal is listed by to work with.

  • Page 15: Mixing Tab

    12. The Monitor Bus can mirror the 20. Solo and mute. On the Monitor bus, the SC button clears all solos. the 48-channel mixer in the 112D, which provides labels and controls for output of any other bus, or it can act provides a main mix bus, monitor bus, channel strip sections.

  • Page 16: Aux Mixing Tab

    The Aux Mixing tab provides quick 8. This is the master fader for the 12. Click the View Personal Mix button access to the 112D’s mix busses (aux control which aux bus or group you current aux bus being viewed (4).

  • Page 17: Mixer Input Channel Strips

    Double-click to return to zero (unity 2. Provides hardware settings for gain) or -∞. inputs, if any, on other MOTU AVB interfaces. If there are no hardware 17. Click the dB scale numbers to make settings for the assigned input, this the fader jump exactly to that level.

  • Page 18: Main Mix And Monitor Channel Strips

    MAIN MIX AND MONITOR CHANNEL STRIPS To access the Main Mix and Monitor bus 6. Indicates that the bus is stereo. channel strips, go to the Mixing tab 7. The four-band parametric EQ for the (page 15) and scroll the display to the Main Mix bus operates the same as right, beyond the inputs and groups.

  • Page 19: Aux Bus Channel Strips

    AUX BUS CHANNEL STRIPS Aux busses can be used to create sub-mixes. An aux bus can be assigned to any output in the Routing grid (page 14). To access an Aux bus channel strip, go to the Mixing tab (page 15), reveal the side bar (item #3 on page 15), and then show the aux busses you want in the Mixer Outputs section (27).

  • Page 20: Group And Reverb Channel Strips

    GROUP AND REVERB CHANNEL STRIPS Group busses can be used to create a mix sub- group, which is a set of inputs you wish to control together as a group. Groups differ from aux busses in that they have aux sends, a reverb send, as well as a main mix send.

  • Page 21: About The 112D

    I/O and 24 channels of ADAT optical digital I/O at banks of network audio input and output (at 1x sample rates up to 96 kHz. The 112D also serves as and 2x sample rates) for an additional 128 channels a 64-channel MADI interface, router, converter, of simultaneous audio I/O.
  • Page 22 Total operation through AVB Ethernet. 24Ao On-board DSP with mixing and effects 72 simultaneous audio channels; 112D is equipped with a powerful DSP engine that drives both an extensive routing matrix and a Connection Input Output 48-input digital mixer with 12 stereo busses and Balanced analog on 3x D-sub or 6x Phoenix effects.
  • Page 23 256 channels of network audio I/O for your host computer Effects include “classic” reverb, compression The 112D lets you stream up to 128 audio channels modeled after the legendary Teletronix LA-2A in and out, simultaneously, through the compressor, and 4-band EQ modeled after British Thunderbolt connection to a host computer.
  • Page 24 Mac and Windows that is interface is operating at 96 kHz, it can generate available as a free download for you as a 112D word clock output at either 96 or 48 kHz; the 1x owner. Visit motu.com/avb to obtain your copy.

  • Page 25: Packing List And System Requirements

    CHAPTER System Requirements PACKING LIST PLEASE REGISTER TODAY! The 112D ships with the items listed below. If any Please register your 112D today. There are two of these items are not present in the box when you ways to register.
  • Page 26 P A C K I N G L I S T A N D S Y S T E M R E Q U I R E M E N T S...

  • Page 27: Software Installation

    Mac using a standard, high-grade (CAT-5e or MOTU AVB USB Control Panel ..... . . 28 CAT-6) network cable up to 100 meters in length.

  • Page 28: Audio Drivers

    On Windows, to enable the 112D in your ASIO host software, choose the MOTU AVB USB ASIO driver. Figure 3-2: The MOTU AVB USB Audio Control Panel Buffer Settings tab. USB Streaming Mode USB Streaming Mode (Figure 3-2) determines how frequently the USB driver transfers audio.

  • Page 29: Audiodesk Workstation Software

    PDF document. Figure 3-3: AudioDesk. WORKING WITH HOST AUDIO SOFTWARE For further information about using the 112D with host audio software, see “Working with Host Audio Software” on page 49. S O F T W A R E I N S T A L L A T I O N...
  • Page 30 S O F T W A R E I N S T A L L A T I O N...

  • Page 31: Hardware Installation

    Syncing word clock devices......40 Use this setup if you want to use your MOTU Syncing an AVB network.

  • Page 32: Usb Audio Interface Setup

    Use this setup if you want to use your MOTU As an alternative to Thunderbolt or USB, use this device as a USB audio interface. setup if you want to use the 112D as an AVB Ethernet audio interface for a recent-generation Use a standard USB cable.

  • Page 33: Setup For Two Interfaces

    Ethernet patch cable. They are available wherever network cables are sold. Use this setup if you want to connect two MOTU interfaces to your computer. The connection to the computer can be either ■ USB or Thunderbolt, if you have a Thunderbolt- equipped MOTU AVB interface such as the 1248, 8M, 16A or another 112D.

  • Page 34: Setup For Three To Five Interfaces

    Use standard CAT-5e Ethernet network cables to ■ Use this setup if you want to connect three to five connect the interfaces to the MOTU AVB Switch MOTU interfaces to your computer using a MOTU using their NETWORK ports. AVB Switch™ (sold separately).

  • Page 35: Setup For A Multi-Switch Network

    C below are chained properly, but don’t employs multiple AVB switches. AVB Ethernet is an connect C back to A. Alternately, you could industry standard, so you can use MOTU AVB connect both Switches B and C to Switch A. Switches or 3rd-party AVB switches.

  • Page 36: Setup For Multiple Thunderbolt And Usb Interfaces

    USB 3.0 port. USB 2.0 provides enough bus speed Thunderbolt and USB ports. Alternately, you can for several USB 2.0 devices, but due to the 112D’s connect multiple interfaces, operating as AVB high-performance requirements for real-time...

  • Page 37: Setup For Web App Control

    Web app control through standard Ethernet Web app control can be set up independently The 112D can also be controlled by the web app of audio connections running on any device that has a standard Ethernet...
  • Page 38 Figure 4-3: Web app control through a standard Ethernet hub or network (LAN). (Sold separately) Figure 4-5: Using the Ethernet port on the MOTU AVB Switch. H A R D W A R E I N S T A L L A T I O N...

  • Page 39: Audio Connections

    8-channel AES/EBU input and output. This cable has detected MADI input format. The Output settings four female XLR connectors and four male XLR connectors. See “112D let you configure the 112D’s MADI output as Rear Panel” on page 10 for pin out details.

  • Page 40: Syncing Optical And Aes/Ebu Devices

    SYNCING OPTICAL AND AES/EBU DEVICES There are several ways to sync an optical device or Figure 4-9: Slaving another digital audio device to the 112D via word clock. For the 112D clock source, choose any source besides word AES/EBU device with the 112D: clock, as it is not advisable to chain word clock.

  • Page 41: Syncing An Avb Network

    112D’s operational sample rate or its corresponding 1x sample rate. For example, if the 112D is operating at 192kHz, you can choose to generate a word out rate of 48kHz using the Force 1x Clock setting in the Device tab of the MOTU AVB Control web app (item #15 on page 12).

  • Page 42: Syncing Multiple Avb Audio Interfaces Connected To A Mac

    SYNCING MULTIPLE AVB AUDIO INTERFACES CONNECTED TO A MAC There are several options for clocking multiple AVB audio devices connected to the Mac: You can resolve them to an external clock source ■ (like word clock, if available). You can create an aggregate device, as usual. The ■...

  • Page 43: Part 2: Using The 112D

    Part 2 Using the 112D...

  • Page 45: Presets

    Your MOTU device is highly capable and audio connections to audio gear configurable, allowing it to perform many tasks Figure 5-1: Using your MOTU AVB device as an audio interface. simultaneously. Video tutorials To view several excellent video tutorials for the presets described in this chapter, visit: www.motu.com/avb...
  • Page 46 Mix 1 Mix 2 mixer and audio networking features are disabled. Audio inputs Figure 5-2: Using 112D as an audio interface and mixer, simulta- neously. P R E S E T S...

  • Page 47: The Front Panel Lcd

    Version menu........48 Figure 6-2: Buttons on the 112D front panel.
  • Page 48 Setting What it does that has a network connection to the 112D, as Clock Mode Sets the digital audio clock source for the explained in “Setup for web app control” on device.
  • Page 49 Run the web app........49 Enabling and disabling input/output banks Choosing the MOTU AVB Audio driver....52 In the web app Device tab (page 13), enable all Reducing monitoring latency.

  • Page 50: Working With Host Audio Software

    Routing tab, as explained below. Figure 7-1: An example of routing computer channels (from host audio software) to the outputs on a 112D. Channels 1-8 are going to ADAT Bank B, and channels 9-16 are going to AES/EBU channels 17-24. All computer channels are also being routed to MADI.
  • Page 51 Figure 7-2: An example of routing physical inputs on the 112D to computer channels (for host audio software). W O R K I N G W I T H H O S T A U D I O S O F T W A R E...
  • Page 52 Reaper Preferences > Audio prefs > Devices software and enable the MOTU AVB audio driver, which allows your host software to use the 112D as Other audio software an audio interface. Consult your software’s manual for further information.
  • Page 53 112D. This is done by your computer, from when it first enters an input opening the Mix In group in the Outputs column...
  • Page 54 Figure 7-5: In Cubase or Nuendo, choose Devices menu > Device Under Mac OS X, audio I/O buffer size is handled Setup. Select your interface (112D), then click the Control Panel button to access the window above and the Buffer Size setting.
  • Page 55 For increase the overall processing load on your example, the 112D can serve as a monitor mixer, computer, leaving less CPU bandwidth for things routing channels to musicians, or it can serve as an like real-time effects processing.
  • Page 56 W O R K I N G W I T H H O S T A U D I O S O F T W A R E...

  • Page 57: High Pass Filter

    Aux bus channel strips....... 19 The hardware mixer in the 112D provides several Group and Reverb channel strips .

  • Page 58: Mixer Effects

    GATE Enabling EQ Each band has an enable/disable button All input channel strips provide a Gate module. (Figure 8-3), allowing you to enable as few or as many bands as needed for the channel strip. Figure 8-2: The Gate module. The gate silences the signal when the input signal’s Enable/disable level drops below the Threshold.

  • Page 59: Compressor

    be flexible enough to cover a broad range of follows a loud passage. Short Release times may applications. By adjusting Gain and Bandwidth cause the attenuation to “pump”, a term used to together, you can emulate the smooth and musical describe the sound of the compressor when the character of classic analog EQ circuits, in which the average input level quickly fluctuates above and...

  • Page 60: Leveler

    LEVELER form a capacitor. Making one of the electrodes The Leveler™ (Figure 8-5) provides an accurate transparent allows the light to escape. These model of the legendary Teletronix™ LA-2A® devices are essentially glow-in-the-dark paint on a optical compressor, known for its unique and piece of foil covered by metalized glass or plastic, highly sought-after Automatic Gain Control and are the same devices used in low-power night...

  • Page 61: Reverb

    Enabling or disabling the Leveler Routing inputs and groups to the reverb processor The Leveler models the LA-2A so closely, it also The reverb processor is a single, independent unit models the time it takes for an actual LA-2A to that provides stereo reverb.
  • Page 62 setting represents the bottom frequency of the Mid band. The Ratio determines the length for each band specified in a percentage of the low frequency reverb time. DSP USAGE The DSP Usage meter (item #26 on page 17) shows how much of the available DSP processing power is currently being used by the mixer for the mix and for effects processing.
  • Page 63 Just plug your MOTU AVB interfaces The MOTU AVB Switch ....... 67 into a standard AVB switch and go.

  • Page 64: Networking

    Over 500 channels of network audio — MOTU’s Personal studio expansion ■ Let’s say you have a 112D mounted in a rack next to AVB network can stream over 500 channels of your computer. You could add an 8M interface and audio throughout the network.
  • Page 65 A studio installation of three to five interfaces can Concert systems must be flexible so they can adapt be handled with a single MOTU AVB Switch. See to each new venue while on tour. Because of its “Setup for three to five interfaces” on page 34.
  • Page 66 ■ AVB-compatible switch. You can use any standard switches. However, you can daisy-chain more than AVB switch on the market. MOTU offers the five- seven switches and route audio freely among them. port MOTU AVB Switch™ (sold separately). You just won’t be able to create point-to-point ☛...
  • Page 67 (through USB), mapping network input and output streams is accomplished as described in the 1 In the MOTU AVB Control web app, choose the previous two sections. Simply enable AVB streams device (item #1 on page 12).
  • Page 68 N E T W O R K I N G...

  • Page 69: Part 3: Appendices

    Part 3 Appendices...

  • Page 71: Troubleshooting

    Troubleshooting APPENDIX Some or all of my 112D inputs and outputs are not The Routing tab (page 14) doesn’t display some of available in my host audio software. the inputs or outputs on my interface. Make sure that the inputs and outputs are enabled The Routing tab only displays input and output in the Device tab (“Device tab”...
  • Page 72 Connecting or powering gear during operation... The serial number of your MOTU device. This is ■ It is not recommended that you connect/ printed on a label placed on the bottom of the rack disconnect, or power on/off devices connected to unit.

  • Page 73: Audio Specifications

    Audio Specifications APPENDIX AES/EBU 24 channels Organized in 3x 25 pin “D-sub” connectors Connector Type D-sub, 4-40 jackscrew sockets Pin-outs as per AES-59 Format AES-3 24-bit linear PCM Input 1 vpp to 7 v p-p (with termination) Transformer coupled Output 5.0 vpp (with termination) Transformer coupled Impedance...
  • Page 74 A P P E N D I X B : A U D I O S P E C I F I C A T I O N S...

  • Page 75: Mixer Schematics

    Mixer Schematics APPENDIX MONO INPUT CHANNEL...
  • Page 76 STEREO INPUT CHANNEL A P P E N D I X C : M I X E R S C H E M A T I C S...
  • Page 77 GROUP BUS A P P E N D I X C : M I X E R S C H E M A T I C S...
  • Page 78 MONITOR BUS A P P E N D I X C : M I X E R S C H E M A T I C S...
  • Page 79 D-sub Connector Specifications APPENDIX D-SUB CABLE PIN-OUTS Signal The AES/EBU D-sub connectors on the 112D Channel 7/8 Out (+) follow the Panasonic/Tascam (AES-59) standard SG (Signal Ground) specification for a four-stereo pair input/output XLR or DB-25 breakout cable. Channel 5/6 Out (-)
  • Page 80 A P P E N D I X D : D - S U B C O N N E C T O R S P E C I F I C A T I O N S...

  • Page 81: Updating Firmware

    An AVB port on a MOTU AVB switch ■ (connected to your office network through the Ethernet port) Figure E-1: The firmware update banner appears automatically at the top of the Device tab when your web host has internet access and MOTU posts an update.
  • Page 82 Updating off-line, without internet access Viewing the latest firmware version information If the 112D (and the computer it is connected to) You can confirm the firmware version at the has no internet access, you can download a bottom of the Device tab (Figure E-2).

  • Page 83: Osc Support

    MOTU AVB audio interfaces support OSC, which provides remote control of all device settings and mixer controls from any OSC-enabled controller. For further details about remote control through...
  • Page 84 A P P E N D I X F : O S C S U P P O R T...

  • Page 85: Index

    Index Computer Setup Computer Volume Controls setting 112D High pass filter Connecting multiple interfaces expansion 28, 54 Control Panel installing Control surface support (through OSC) 11, 12, 47 ID knob/button specifications Core Audio driver IEEE 802.1 summary of features 49, 52...
  • Page 86 Discovery app Compressor Installer 49, 52 Reaper Technical support USB ASIO driver Reason Threshold WebUI Setup Propellerhead Reason Compressor MOTU AVB WebUI Setup Record Thru (word clock) Registration To Computer Release 63-67 Networking TOSLink 58, 59 Compressor 34, 35 installation...
