FineVu FINE Safer S Installation Manual

Components and names

Usage/Installation Manual

FINE Safer S
Continuous Power Supply
No Name
1 B+terminal (yellow) Connects to the B+ of the fuse box.
2 GND terminal (black) Connects to the ground of the fuse box.
3 ACC terminal (red)
4 Main Unit
5 Cigar socket
Double-sided
6
adhesive tape
Main unit 7 5-pin connector
Cigar socket with 5-pin connector
The components or appearance of the product may be changed without
prior notice.

5-pin connector wiring diagram

Remarks
No Name Remarks
Connects to the ACC of the fuse box. 1 White line Black box (+) power
Attaches to a desired location inside the
2 Black line Black box (-) power
fuse box of the vehicle using the double-
3 Yellow line B+ power
sided adhesive tape.
4 Black line GND
Connects to the cigar jack of the black box.
5 Red line ACC (+) power
Attaches the main power unit to a desired
location inside the fuse box.
Connects to the main unit.

Installation and use

Open the fuse box on the left
side of the driver's seat.
1
2
3
4
Make sure to install the product only when the engine is turned
off.
5
The location and appearance of the fuse box may vary depending
on the vehicle you are driving.
Connect the wires of the Connect the GND
continuous power supply terminal to the
(in the order of B+, ACC and grounding parts.
GND).
Connect the power cigar jack of the black box into the cigar socket.
Connect the 5-pin connector to the main unit.

Special features

y Various modes(stand-by mode / ACC mode) supported
y Applicable to all types of black box
After finishing with the wiring, wait for 40 seconds for automatic
y Low power consumption
detection and configuration.
- Operation : 7~10 mA
- Stand-by : 1~2 mA
y Indicator LEDs for checking the voltage, timer, and operation
Using the double-sided adhesive tape,
status
securely attach the main power unit to a
y Short-circuit prevention program applied
desired location.
8
Close the cover of the fuse box. Now
installation is complete.
