Summary of Contents for Russound TS3
- Page 1 Color Touchscreen TS3 Installation Manual...
-
Page 2: Safety Instructions
Object and Liquid Entry - Care should be taken apparatus. Russound TS3 Installation Manual... -
Page 3: Table Of Contents
Screen Setup ....................14 Installers Setup Functions ..............14 IP and MAC Address ................14 Firmware Version and update ..............14 Diagnostics ....................15 Factory Init ....................15 Setting Favorites ..................16 Source Screen Features and Examples ........17-19 Technical Specifi cations .................20 Warranty ......................20 Russound TS3 Installation Manual... -
Page 4: Product Overview
The TS3 makes a great addition to an installed RNET system, as it IR Receiver can be installed into an existing double-gang junction box. -
Page 5: Front Panel
Touchscreen - Full color resistive touchscreen with multi-sound feedback. Screen can be programmed to go blank after a period of inactivity. Touching the screen anywhere reactivates it. TS3 Front Panel Showing Source Selection Screen Russound TS3 Installation Manual... -
Page 6: Back Panel
IR receiver Controller - RJ-45 CAT-5 connection to controller keypad input Ethernet - RJ-45 CAT-5e port for future use Update Port - USB 2.0 port for software updates (on bottom edge of touchscreen) TS3 Rear Panel Russound TS3 Installation Manual... -
Page 7: Touchscreen Location
TOUCHSCREEN LOCATION The TS3 is an in-wall touchscreen. For installation, you will need a UL/CSA approved plastic 32ci double-gang electrical box. Notice the minimum clearance around the electrical box Size of TS3 bezel required for the bezel. This is larger than a typical light switch 6.0”... -
Page 8: Touchscreen Installation
The bezel can now be lifted from the touchscreen. To replace the bezel, center it over the front of the touchscreen and press fi rmly until the bezel clicks into place. TS3 bezel Russound TS3 Installation Manual... -
Page 9: Controller Connections
CONTROLLER CONNECTIONS input with CAT-5e cable using an RJ-45 connector with T568A The TS3 Touchscreen is designed for use with the C-Series wiring standard. Cable length from the touchscreen back to the controllers, and connects to a keypad port on the back of the controller should be no more than 250 feet. -
Page 10: External Ir Connection
EXTERNAL IR CONNECTION / FRONT IR DISABLE The TS3 Touchscreen has an External IR Receiver In terminal for connecting an external IR Receiver such as the Russound 858, SaphIR 862 Eye, or SaphIR 860 Phantom. Russound 858 IR receiver (back) -
Page 11: Zone And Controller Id
Installers Setup until the "Installer Setup" screen appears. Select Zone and Controller ID. On this screen, enter the zone number the TS3 is controlling and the ID number of the controller to which it is connected. -
Page 12: Alarm Settings
Alarm is active - The touchscreen displays a screen showing a ringing alarm clock. To Turn off active alarm - Press the Alarm Off button on the TS3 or press the Power button on the SRC-C5 remote control. To Snooze - Press the snooze button on TS3, or pause button on the SRC-C5 remote control. -
Page 13: Sound Control
Master. Do Not Disturb - Someone in another room has chosen a source and locked out anyone else from controlling it. That room also won’t be disturbed by paging. Russound TS3 Installation Manual... -
Page 14: Screen Setup
IP and MAC addresses when applicable. It also shows the Brightness - Adjust the touchscreen brightness IP and MAC addresses of the controller to which the TS3 is connected. Screen Blank (min) - The screen blank darkens the screen after a period of inactivity. -
Page 15: Diagnostics
This option allows a factory initialization to be performed on the touchscreen. This sets the unit back to its factory settings. Diagnostics and Factory Init are accessed by selecting the page down button on the right side of Installer Setup screen. Russound TS3 Installation Manual... -
Page 16: Setting Favorites
SETTING FAVORITES Favorites (top leftt corner of screen) The TS3 supports 32 system favorites. These choices can be selected at any time to recall a source selection, mode, channel, station, etc. Saving a Favorite Favorites are saved from the Favorites screen. Before storing a favorite, select a source to be stored, choose the desired station, channel, etc. -
Page 17: Source Screen Features And Examples
Shared Icon "Shared" Icon (status bar - bottom of screen) The small graphic “S” becomes highlighted on the right side of the main display when the selected source is also selected in one or more other rooms. Russound TS3 Installation Manual... - Page 18 Press the music note button in the top right corner. Page Page Indicators Indicators If more than one page of information is available the page indictor icons will be displayed to the right of the list allowing you to page up or down. Russound TS3 Installation Manual...
- Page 19 SOURCE SCREENS - EXAMPLES Sources selection menu iBridge Dock RNET AM/FM Tuner DMS-3.1 Streamer IR controlled legacy device Press the source Now Playing screen to access source specifi c options. Russound TS3 Installation Manual...
-
Page 20: Technical Specifications
(2) years from the date of purchase. During Before returning a unit for repair, call Russound at (603) 659-5170 for a this period, Russound will replace any defective parts and correct any Return Authorization number. - Page 21 Russound TS3 Installation Manual...
- Page 22 Russound TS3 Installation Manual...
- Page 23 Russound TS3 Installation Manual...
-
Page 24: Installation Manual
5 Forbes Road, Newmarket, NH 03857 All trademarks are the property of their respective tel 603.659.5170 • fax 603.659.5388 owners. Specifi cations are subject to change without email: tech@russound.com www.russound.com notice. Russound is not responsible for typographical 28-1358 01/29/13, Rev. 2 errors or omissions.
