TTS Easi-Pulse User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Warranty & Support
This product is provided with a one year warranty for problems found during
normal usage. Mistreating the Easi-Pulse or opening the unit will invalidate
this warranty. Any data stored on the unit and any consequential loss is not
covered by this warranty. The battery is not user replaceable.

Technical Support

Please visit www.tts-group.co.uk for the latest product information.
Email feedback@tts-group.co.uk for technical support.
TTS Group Ltd.
Park Lane Business Park
Kirkby-in-Ashfield
Nottinghamshire,
NG17 9GU, UK.
Freephone: 0800 318686 Freefax: 0800 137525
Easi-Pulse
WARNING: Do not dispose of this product in
household waste. Hand it over to a collection
point for recycling electronic appliances.
WARNING! Not suitable for children under 36
months due to small parts – choking hazard.
Made in China, on behalf of the TTS Group Ltd.
TM
N448
Nxxxxx
TTS Product Code:
EL00145

Advertisement

Table of Contents
loading

Summary of Contents for TTS Easi-Pulse

  • Page 1: Technical Support

    Warranty & Support This product is provided with a one year warranty for problems found during normal usage. Mistreating the Easi-Pulse or opening the unit will invalidate this warranty. Any data stored on the unit and any consequential loss is not covered by this warranty.
  • Page 2 Easi-Pulse measures the pulse oxygen saturation and pulse rate USER GUIDE www.tts-shopping.com...
  • Page 3 Instructions to User Dear users, thank you very much for purchasing the Pulse Oximeter. This Manual is written and compiled in accordance with the council directive MDD93/42/EEC for medical devices and harmonized standards. In case of modifications and software upgrades, the information contained in this document is subject to change without notice.
  • Page 4 Easi-Pulse WARNING: Uncomfortable or painful feeling may occur if using the device continuously, especially for microcirculation barrier patients. It is recommended that the sensor is applied for no longer than 2 hours. The device cannot be clipped on the edema or tender tissue.

  • Page 5: Table Of Contents

    CONTENTS 1 Safety 1.1 Instructions for safe operation 1.2 Warnings 1.3 Attention 2 Overview 2.1 Features 2.2 Major applications and scope of application 2.3 Environment requirements 3 Principle 4 Technical specifications 4.1 Main performance 4.2 Main Parameters 5 Installation 5.1 View of the front panel 5.2 Battery installation 5.3 Accessories 6 Operating Guide...

  • Page 6: Safety

    Easi-Pulse 1 Safety 1.1 Instructions for safe operations Check the main unit and all accessories periodically to make sure that there is no visible damage that may affect patient’s safety and check cables. It is recommended that the device should be inspected once a week. When there is obvious damage, stop using the device.

  • Page 7: Attention

    1.3 Attention Keep the oximeter away from dust, vibration, corrosive substances, explosive materials, high temperature and moisture. If the oximeter gets wet, stop use. The Oximeter should be left to acclimatize to different environments. DO NOT the operate keys on front panel with sharp materials. High temperature or high pressure steam disinfection of the oximeter is not recommended.

  • Page 8: Environment Requirements

    Easi-Pulse and pulse rate through finger. The product is suitable for being used at home, in the hospital, at an oxygen bar, in community healthcare, and for physical care in sports (it can be used before or after sports, it is not recommended to use the device during sport) and etc.

  • Page 9: Technical Specifications

    4 Technical specifications 4.1 Main performance A. SpO2 value display B. Pulse rate value display, bar graph display C. Pulse waveform display D. Low-voltage indication E. Automatically power off: it will automatically power off within 5 seconds if the finger falls out of probe. F.

  • Page 10: Installation

    Easi-Pulse D. Measurement Performance in Weak Filling Condition SpO2 and pulse rate can be shown correctly when pulse-filling ratio is 0.4%. SpO2 error is ±4%, pulse rate error is ±2 bpm or ±2% (select larger). E. Resistance to surrounding light The deviation between the value measured in the condition of man-made light or indoor natural light and that of darkroom is less than ±1%.

  • Page 11: Battery Installation

    5.2 Battery installation A. Refer to Figure 3. and insert the two AAA size batteries with the correct polarity. B. Replace the cover. Figure 3 5.3 Accessories C. User manual A. Lanyard D. USB lead B. Two dry batteries (AAA) (optional) E.
  • Page 12 Easi-Pulse B. Change display direction On the measuring interface, press the button to change the display. C. Pause alarm: a) Alarm including can be set to sound for data going beyond the predetermined limits, low battery, and finger removed. c) To turn off the alarm, setting can be changed in the operation menu.
  • Page 13 On the measuring interface, the display direction can be changed by pressing the power button quickly. There are six modes of data display that can be viewed. a. Adjusting the high and low limits of alarms On the alarm setting interface, Click the power button to select “Dir”, then Press and hold the power button (1 second) to enter the Settings Menu Interface (see Figure 7).
  • Page 14 Easi-Pulse Press the button (1sec) to enter the alarm direction setting interface as shown in Figure 9: On the alarm direction setting interface, Click the power button to select “SpO2 Alm”or “PR Alm”, then Press the button (1 sec) to enter the...
  • Page 15 c. The alarm state setting On the alarm setting interface as shown in Figure 8, Click the power button to select “Alarm”, then Press the power button to choose alarm on or off, press “ on” to turn on the alarm and “ off” to turn off the alarm. d.

  • Page 16: Operation

    Easi-Pulse F. Power off The device will power off automatically when it gets no signal for 5 seconds. The device cannot power off when it is storing data. 6.2 Attention for operation A. Please check the device before use. B. The finger should be in a proper position (see the attached illustration of Figure 4 for reference), or else it may result in an inaccurate measurement.

  • Page 17: Transportation And Storage

    7.3 Transportation and storage A. There are not special transportation requirements. B. The packed device should be stored in room with: Temperature: -40°C~60°C; Humidity: ≤95% Troubleshooting The SpO2 and 1. The finger is not 1. Place the finger properly Pulse Rate cannot properly positioned and try again.

  • Page 18: Key Of Symbols

    Easi-Pulse 9 Key of Symbols Warning – See User Manual The pulse oxygen saturation(%) %SpO2 Pulse rate (bpm) PRbpm Low-voltage Open the alarm sound indication Open the pulse sound indication menu button/power button/function button Type BF Serial number 1. the finger clip falls off ( no finger inserted)] 2.

  • Page 19: Function Specification

    The Pulse Oxygen Saturation (SpO2) 2-digit digital OLED display Pulse Rate(PR) 3-digit digital OLED display Pulse Intensity (bar-graph) bar-graph OLED display SpO2 Parameter Specification 0%-100%, (the resolution is 1%). Measuring range 70%-100% ±2% , Below 70% Accuracy unspecified. Calculate the Average value in every Average value 4 measure value.

  • Page 20: Appendix

    Easi-Pulse Dimensions and Weight Dimensions 58.5(L) × 31(W) × 32 (H) mm Weight About 52g (with the batteries) Appendix Guidance and manufacturer’s declaration – electromagnetic emissions- for all Equipment and Systems Guidance and manufacturer’s declaration – electromagnetic emission The CMS50D+ is intended for use in the electromagnetic environment specified below.
  • Page 21 Guidance and manufacturer’s declaration – electromagnetic immunity – for all Equipment and Systems Guidance and manufacturer’s declaration – electromagnetic immunity The CMS50D+ is intended for use in the electromagnetic environment specified below. The customer or the user of CMS50D+ should assure that it is used in such an environment.
  • Page 22 Easi-Pulse Immunity IEC 60601 Compliance Electromagnetic environment - test test level level guidance Radiated RF 3 V/m 3 V/m Portable and mobile RF IEC 61000- 80 MHz to communications equipment 2.5 GHz should be used no closer to any part of the CMS50D+, including...
  • Page 23 NOTE 1 At 80 MHz and 800 MHz, the higher frequency range applies. NOTE 2 These guidelines may not apply in all situations. Electromagnetic propagation is affected by absorption and reflection from structures, objects and people. a Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast cannot be predicted theoretically with accuracy.
  • Page 24 Easi-Pulse Recommended separation distances between portable and mobile RF communications equipment and the CMS50D+ The CMS50D+ is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the CMS50D+ can help prevent electromagnetic interference by maintaining...
