- Page 1 ® BRANCH WIZARD™ ELECTRIC PRUNING SAW OWNER’S MANUAL MODEL DPS-1: 111409-01 IMPORTANT: Read and understand this manual before assembling or operating this Pole Saw. Improper use of Pole Saw can cause severe injury. Keep this manual for future reference. ® LISTED...
-
Page 2: Save These Instructions
9. Wear the following safety gear when operating SAVE THESE INSTRUCTIONS Pole Saw: INTRODUCTION • heavy-duty gloves (wear rubber gloves when working outdoors) Before operating Pole Saw, make certain you read • steel-toed safety footwear with non-skid soles and understand all Important Safety Information. •... - Page 3 KICKBACK IMPORTANT SAFETY INFORMATION WARNING: Kickback may occur when Continued the nose or tip of the guide bar touches an object, or when the wood closes in 13. When cutting a limb that is under tension, use and pinches the saw chain in the cut. Tip extreme caution.
-
Page 4: Pole Saw Trimming Precautions
IMPORTANT SAFETY INFORMATION Continued POLE SAW TRIMMING PRECAUTIONS Keep other persons away from cutting end of Pole Saw and at a safe distance from work area. Never stand directly under the limb you are trimming. Always position yourself out of the path of falling debris. - Page 5 FIGURES DPS-1 BRANCH WIZZARD Guide Bar 111409-01 Trigger Switch Lock-out Saw Chain Pole Grip Area Trigger Switch Handle Power Cord Figure 1 - Pole Saw Product Identification December 2004 M&S Service Co.Inc 1-800-475-5660...
- Page 6 FIGURES Guide Bar Continued Guide Bar #1 Phillips Screwdrive Guide Bar Nut Figure 6 - Chain Tension Adjustment Bushing Belleville Washer Sprocket Cover Figure 2 - Installing Guide Bar Guide Bar Nut Towards Guide Bar Nose Guide Bar Cutting Edge Correct Tension Guide Bar Saw Chain...
- Page 7 FIGURES Continued 2nd Cut - Pruning Cut (to avoid pinching) 4th Cut - Final Stub Cut Chain Oil 6" (15 cm) Guide Bar 2" to 4" (5 a 10 cm) 1st Cut - Pruning Undercut (to avoid splintering) 3rd Cut - Stub Undercut (to avoid splintering) Figure 12 - Cutting A Limb Figure 9 - Oil Chain and Guide Bar...
- Page 8 FIGURES Continued Depth Gauge (right side of chain) Burr Depth Gauge (left side of chain) Groove Groove Top Plate (left Flat File Guide Bar side of chain) Top Plate (right side of chain) Right Side of Chain Cleaning Groove With Putty Knife Figure 16 - Chain Part Locations Oil Slot Flat File...
-
Page 9: Pole Saw Names And Terms
1. Lay chain out flat. ® 2. Loosen and remove guide bar nut, sprocket cover, and washer (see Figure 2). 3. Install guide bar onto saw body. Place center slot BRANCH WIZARD™ of guide bar onto guide bar bolt. 4. Place chain around drive sprocket, then along top MODEL DPS-1: 111409-01 groove of guide bar and around guide bar nose. -
Page 10: Extension Cords
provided is pre-lubricated at the factory. With each SAW CHAIN TENSION use of the Pole Saw apply a small amount of lubri- ADJUSTMENT cating oil directly to the saw chain (see Figure 9). Continued The oil will distribute itself around the chain and guide bar groove during use–preventing rust. -
Page 11: Care Of Guide Bar
CARE OF GUIDE BAR OPERATING POLE SAW Uneven bar wear causes most guide bar problems. Continued Incorrect sharpening of chain cutter and depth gauge settings often cause this. When bar wears unevenly, CAUTION: Seek professional help if it widens guide bar groove (see Figure 13). This facing conditions beyond your ability. -
Page 12: Technical Service
5. Wipe off outside of Pole Saw body. Do this with CLEANING AND soft cloth dampened with a mild soap and water MAINTENANCE mixture. Continued 6. Store Pole Saw • in a high or locked place, out of children’s reach 3. -
Page 13: Repair Service
damage, we will repair or replace product without REPAIR SERVICE charge. Note: Normal wear, misuse, abuse, neglect, Note: Only use original replacement parts. This will or accidental damage is not covered under warranty. protect your warranty coverage for parts replaced NON-WARRANTY SERVICE under warranty. - Page 14 REPLACEMENT PARTS/PARTES DE REPUESTO/ PIÈCES DE RECHANGE For original replacement parts, contact authorized dealers of this product or your nearest parts central listed below. Para conseguir partes de repuesto originales, póngase en contacto con distribuidores autorizados de este producto o con su central más cercana de repuestos que se listan más abajo. Pour l'obtention de pièces de rechange d'origine, s'adresser aux concessionnaires agréés ou au dépositaire de pièces le plus proche Figurant dans la liste ci-après.
- Page 15 NOTES/NOTAS_______________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ 111607 www.desatech.com...
- Page 16 NOTES/NOTAS_______________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ www.desatech.com 111607...
- Page 17 NOTES/NOTAS_______________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ ______________________________________ 111607 www.desatech.com...
- Page 18 Industries of Canada, Inc. 2220 Argentia Road Unit #4 Mississauga, Ontario L5N 2K7 P.O. Box 90004 905-826-8010 111607-01 Bowling Green, KY 42102-9004 FAX 905-826-8236 Rev. B www.desatech.com www.desatech.com 08/03 www.desatech.com 111607...
