Work Pro STUDIO 20 LINE User Manual page 6

STUDIO 50 LINE
EN
A STUDIO 50 LINE carton contains two loudspeakers (black or white) and two metallic
wall-mount brackets.
276
(*) Power Taps (70V) .................................
Power Taps (100V).................................
Low Impedance position..........................
Sensitivity (1W/1m) .................................. 72 dB
Max. SPL ..................................................... 90 dB
Frequency Response .............................. 40Hz - 20kHz
Elements.................................................... 8" Woofer + 1" Tweeter
Dimensions .............................................. 276 x 366 x 240 mm
Material (enclosure) ................................. ABS plastic
Material (grille) .........................................
Weight ....................................................... 6,3 Kg
(*) The power taps indicated on the selector switch are calculated for 100V line. In the case of 70V line installation, each power
tap will correspond to half the value
Specifications are subject to change without notice
The power tap is
position rotary switch to the desired tap.
Make sure to select the correct power tap
position before connecting the loudspeaker
to a 70/100V line amplifier. If the low
impedance position (8Ω) is selected, the
loudspeaker could be damaged!
The connection is made through Binding Post terminals.
Ensure the correct polarity is observed.
2W(2k45Ω)/4W(1k22Ω)8W(612Ω)/16W(306Ω)
4W(2k5
8Ω (70W)
Aluminium
User Manual/Manual de Uso
5
selected by rotating
Ω) /8W(1k25 Ω) /16W(625
STUDIO Series
the 5
Ω) /32W(312 Ω)
