INSTALLATION STEPS
STEP 1: Download the firmware .zip - file
associated with the Cavalry CAU3G.
1
STEP 2: Once the firmware is downloaded,
2
un-zip the file contents onto your desktop.
Make sure you see 2 folders:
"GL3310 FW 0006" and "GL3310 MultiTool_2.0.4.2".
STEP 3: Plug in your Cavalry CAU3G to a power source with the packaged power supply.
3
Connect the Bulldog into your computer via USB 2.0 or 3.0 cable and allow your computer to
detect the device.
Unplug any other external devices from your computer, aside from the product you are
updating.
STEP 4: Open the
4
"GL3310 Multi-
folder and locate
Tool_2.0.4.2"
the "MultiTool" file.
Right-click and
select "Run as
Administrator."
Allow this program
to make changes to
your computer.
Firmware Instructions
PORTABLE CAU3G-BLACK
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Cavalry CAU3G
Summary of Contents for Cavalry CAU3G
- Page 1 Make sure you see 2 folders: “GL3310 FW 0006” and “GL3310 MultiTool_2.0.4.2”. STEP 3: Plug in your Cavalry CAU3G to a power source with the packaged power supply. Connect the Bulldog into your computer via USB 2.0 or 3.0 cable and allow your computer to detect the device.
- Page 2 CAU3G-BLACK FIRMWARE INSTRUCTIONS STEP 5: MultiTool will open with the screen shown below. Press the “F/W & EEPROM” button to take you to the firmware update window. STEP 6: Once the firmware update window (shown to the right) appears, select the “Load...
- Page 3 CAU3G-BLACK FIRMWARE INSTRUCTIONS STEP 7: A window will open. Within this window, locate the CAU3G-B firmware folder that you placed on your desktop and select the “GL3310 FW 0006” folder. Then press the “Open” button. STEP 8: The “GL3310 FW 0006”...
- Page 4 CAU3G-BLACK FIRMWARE INSTRUCTIONS STEP 9: Once the file is selected. The “Write F/W” button will now be selectable. Press the “Write F/W” button to begin the firmware update. STEP 10: The status bar located at the bottom of the window will show you the progress.
- Page 5 Exit out of all the windows and begin using your Cavalry CAU3G. Cavalry, the names of series and the Cavalry logo are registered trademarks of Cavalry Storage. All other trademarks or registered trademarks are the property of their respective owners. When referring to hard drive capacity, one gigabyte, or GB, equals one billion bytes, and one terabyte, or TB, equals one trillion bytes. Your computer’s operating system may use a different standard of measurement and report a lower capacity.
