Booklet Making In 4 Easy Steps
Step 1
Center the paper on the grid
Step 3
Reverse the lever to activate folder
Replacement Parts:
Item#
Description
M-S025052
65T double-sided belt
M-S033073
Illuminated ON/OFF switch
200
Martin Yale Roller Cleaner
Trouble Shooting / Technical Assistance
Call 1-800-225-5644
Contact Information:
251 Wedcor Avenue
Wabash, IN. 46992
www.martinyale.com
info@martinyale.com
Step 2
Bring the lever down to activate both staplers
Step 4
Remove fi nished booklet
M-S027913
Model BM101 - Booklet Maker
Thank you for purchasing the BM101 Booklet Maker. This product will
prove to be a great value and allow you to effi ciently produce booklets of up to
40 pages (10 sheets) inside your choice of cover material for many years.
Specifi cations:
Dimension of Unit: 15
3
/
" x 19
4
Weight of Unit:
34 lbs.
Voltage:
120V
Paper Capacity:
10 sheets of 20 lb bond with cover
Paper Sizes:
8
1
/
" x 11", 8
2
A3, A4, B4 and B5
Staplers (2):
4 position - used standard staples
WARNING!
Never connect power to the model BM101 booklet maker until you are ready to set up and operate
the machine. This machine contains moving parts. During setup, operation, and maintenance; keep hands, hair,
loose clothing, and jewelry away from all moving parts. Serious bodily injury could result. Service or disassembly
of the unit should only be performed by qualifi ed personnel with the power disconnected and locked out.
3
/
" x 5
1
/
"
4
2
1
/
" x 14", 11" x 17",
2
