  • Page 1 User Manual Version 1.0 April 2015 J2 240...
  • Page 2 Copyright 2015 All Rights Reserved Manual Version 1.0 The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose.

  • Page 3: Important Safety Instructions

    Safety IMPORTANT SAFETY INSTRUCTIONS To disconnect the machine from the electrical Power Supply, turn off the power switch and remove the power cord plug from the wall socket. The wall socket must be easily accessible and in close proximity to the machine. Read these instructions carefully.
  • Page 4 CAUTION ON LITHIUM BATTERIES There is a danger of explosion if the battery is replaced incorrectly. Replace only with the same or equivalent type recommended by the manufacturer. Discard used batteries according to the manufacturer’s instructions. Battery Caution Risk of explosion if battery is replaced by an incorrectly type. Dispose of used battery according to the local disposal instructions.
  • Page 5 Revision History Revision Date Description V1.0 April, 2015  Release...

  • Page 6: Table Of Contents

    Table of Contents 1 Item Checklist ..........1   1-1  Standard Items ................1  1-2  Optional Items ................2  2 System View ........... 3   2-1  Front View & Rear View ..............3  2-2  Side View ..................4  2-3  Bottom View ..................4  2-4 ...

  • Page 7: Item Checklist

    Item Checklist Standard Items a. System b. Power adapter (65W) c. Power cable d. RJ45-DB9 cable (x4) e. Manual CD...

  • Page 8: Optional Items

    Optional Items a. MSR module b. iButton module c. Addimat reader d. Customer display ( Graphic LCM ) display Wall Mount kit...

  • Page 9: System View

    System View Front View & Rear View Number Description LED indicator Touch screen Thumb screw for the cable cover Ventilation hole HDD door VFD/2 display dummy cover MSR/iButton/Addimat key module dummy cover Swing arm base...

  • Page 10: Side View

    Side View Fold down the swing arm base Bottom View Number Description Rubber foot Power adapter (with holder bracket) IO ports...

  • Page 11: Dimension & View Angle

    Dimension & View Angle...

  • Page 13: I/O View

    I/O View Number Description Line out Display port Mic in Power button 19V DC in COM1~3 (from right to left) USB x 4 (USB2.0) Cash drawer USB x 2 (USB3.0)

  • Page 14: System Assembly & Disassembly

    System Assembly & Disassembly Install the Power Adapter The system is equipped with a 65W power adapter. Please follow the steps below to install the power adapter. The swing arm base is designed to allow for clean cable management. There is a cable channel through the swing arm base, which has a quick access cover.

  • Page 15: Replace The Hdd

    Replace the HDD Remove the HDD/SSD cover retaining a screw and sliding the drive out. Unclip the HDD cover from the drive as shown in the picture. Replace the SSD Card Remove the HDD/SSD cover retaining a screw and sliding the drive out.

  • Page 16: Peripherals Installation

    Peripherals Installation Install the MSR Module MSR is installed on the right side of the system. Please make sure the unit is powered down before starting. Remove the dummy cover first. Connect the MSR cable (x1) to the connector on the system side. Insert the MSR module in place and fasten the screws (x2) on the back to secure the module.

  • Page 17: Install The Ibutton Module

    Install the iButton Module iButton is installed on the left side of the system. Please make sure the unit is powered down before starting. Remove the dummy cover first and then unfasten the screws (x2). Connect the iButton cable to the connector on the system side.

  • Page 18: Install The Addimat Key Reader

    Install the Addimat Key Reader Addimat key reader is an option instead of iButton module. It is also installed on the left side of the system. Please make sure the unit is powered down before starting. Remove the dummy cover first and then unfasten the screws (x2).

  • Page 19: Install The Customer Display (Graphic Lcm)

    Install the Customer Display (Graphic LCM) Remove the dummy cover first. After the dummy cover is removed, plug the 8-pin LCM cable into the CN8 / LCM connector on the system board. Fasten the screws (x2) to secure the LCM display to the system. The Customer Display is directly connected to COM6 and uses the following communication parameters: 9600, N, 8, 1.

  • Page 20: Install The 2 Nd Display

    Install the 2 Display Remove the dummy cover first. After the dummy cover is removed, plug the 20-pin 2 display cable into the CN6 connector on the system board. Fasten the screws (x2) to secure the display to the system.

  • Page 21: How To Activate The 2 Nd Display Under Windows

    4-5-1 How to activate the 2 display Under Windows Make sure to connect the 2 display cable and begin the installation after your  system has booted. The Setup program requires about one minute for the installation. If you turn the ...
  • Page 22 Click the Appearance and Personalization to enter the menu. Select Display from the menu and the display properties windows appears.
  • Page 23 Arrange the monitors displayed in the order they are actually used. Remember to click Apply before exiting the menu. Click Keep Changes and then click OK to save the setting.

  • Page 24: Install The Wall Mount Kit

    Install the Wall Mount Kit The wall mount come with the following parts: 8mm screw x 8 Mounting Clip x 4 4 mm screw x 1 Mounting bracket First attach the four mounting clips using the 3 mm screws as shown in the picture.
  • Page 25 Next step is to route any cables you need to go to the system as required. A space is provided just by the power supply for the cable to exit cleanly, assuming they are routed via the swing arm cable channel as in a normal install.
  • Page 26 Some possible viewing angles using the wall mount bracket.

  • Page 27: Install The Cash Drawer

    Install the Cash Drawer You can install a cash drawer through the cash drawer port. Please verify the pin assignment before installation. Cash Drawer Pin Assignment Signal Cash drawer 1 Out Cash drawer 1 In 12V / 19V (OR 24v) Cash drawer 2 Out Cash Drawer Controller Register The Cash Drawer Controller use one I/O addresses to control the Cash Drawer.
  • Page 28 Bit 7: Cash Drawer 2 pin output control Bit 6: Reserved Bit 5: Cash Drawer 2 pin input control Bit 4: Cash Drawer 1 pin output control. = 1: Opening the Cash Drawer = 0: Allow close the Cash Drawer Bit 3: Cash Drawer 1 pin input control.

  • Page 29: Specification

    Specification Model Name J2 240 Motherboard Intel Bay Trail SoC CPU support Celeron J1900 2.0GHz, L2 2MB, TDP 10W (default) Chipset System memory DDR3L S.O. DIMM x1, FSB 1066/1333hz, default 2G, max. 8G Graphic memory Intel HD Graphic DX11.1 LAN controller...
  • Page 30 Model Name J2 240 Motherboard Cash drawer 1 x RJ 11 (12V/24V cash drawer ), jumper setting, default 24V Display port Power button Audio jack 1 x Line-out / 1x Mic-in Speaker speaker 1 x 2W Power Power adapter Ext. 65W/19V...

  • Page 31: Configuration

    Configuration D36 Motherboard Layout...

  • Page 32: Connectors & Functions

    Connectors & Functions Connector Function Front I/O board Inverter connector LVDS connector System FAN connector LPT port connector Speaker & MIC connector 40pin external connector CN10 HDD LED connector CN11 Power LED connector CN12 SATA power connector CN13/14 USB port (internal) CN15 PS2 keyboard connector CN16...

  • Page 33: Jumper Settings

    Jumper Settings Inverter Selection Function (1-2) (3-4) ▲LED CCFL Cash Drawer Power Setting Function (1-2) (3-4) ▲+19V +12V LCD ID Setting Panel LVDS Output Resolution (1-2) (3-4) (5-6) (7-8) (9-10) Number Bits Channel Interface 800 x 600 Single LVDS Panel 800 x 600 Single LVDS Panel...
  • Page 34 1024 x 600 Single LVDS Panel 1280 x 1024 Dual LVDS Panel 1440 x 900 Dual LVDS Panel 1920 x 1080 Dual LVDS Panel COM1/COM2/COM3 Power Setting COM1, COM2 and COM3 can be set to provide power to your serial device. The voltage can be set to +5V or 12V in the BIOS.
  • Page 35 To enable the power, select COM1 , COM2 or COM3 Power setting and press <Enter>. Select Power and press <Enter>. Save the change by pressing F10.

  • Page 36: Appendix: Driver Installation

    Appendix: Driver Installation To download the most recent drivers and utilities, and obtain advice regarding the installation of your equipment, please visit the J2 Technical Support Website: http://www.j2retailsystems.com/support.php...
