Table of Contents
Advertisement
Quick Links
wireless
H E A D P H O N E S
2.4GHz Digital Stereo
Wireless Headphone System
Wit h 16 Ban d FSK Tr ansmission
LTB wants to thank you for choosing the Concert
Series Wireless Headphones.
Before attempting to use your Wireless
Headphones, please remove all parts from the box and
read the installation and use instructions carefully
Limited 1 Year Warranty
2.4GHz Stereo
DIGI TA L
LTB-WR-ST
Advertisement
Table of Contents
Related Manuals for LTB Audio Systems LTB-WRST
Summary of Contents for LTB Audio Systems LTB-WRST
- Page 1 Wit h 16 Ban d FSK Tr ansmission LTB wants to thank you for choosing the Concert Series Wireless Headphones. Before attempting to use your Wireless Headphones, please remove all parts from the box and read the installation and use instructions carefully Limited 1 Year Warranty LTB-WR-ST...
-
Page 2: Headset Safety
IN TRODU CTION This 2.4 GHz ster eo wireless headphone system features a compact design that uses the latest wireless technology that enables you to enjoy music and TV sound anywhere inside or outside your home. You can simply connect the system to any sound source, such as a DVD, DBS, CD, TV, VCR, stereo receiver and radio. - Page 3 W R-ST SPECIFICATION S Transmission Mode Operating at 2.4GHz ISM band with 8 selectable channels Carrier Frequency 2410, 2419 ~ 2473 MHz Operation Voltage : Transmitter, 3.6 ~ 5VDC Receiver, 3.9 ~ 5VDC (2 x AAA rechargeable batteries) Frequency Response : 20 ~ 20 KHz, -1dB Frequency stability : ±100 KHz...
-
Page 4: Troubleshooting Your System
- The connected audio/video equipment is not playing. Turn on the equipment. - The volume of the headphones is turned down. Adjust the volume to an appropriate level. NO SIGNAL - Make sure the power indicator on the base unit is on. -
Page 5: Charging The Batteries
CHA RGING THE BA TTERIES 1. Switch the ON/OFF button on the headphone receiver OFF . 2. Plug the charge cord into the charge input jack of the headphone receiver to charge the batteries. 3. The charging process starts automatically when the batteries are charged and the charging RED LED lights up. - Page 6 CH-SEL on the top of the transmitter base and then select CH-SEL on the headset. This should help you to obtain better reception withthe headphones. You may have to try this adjustment several times to obtain optimum performance, depending on the conditions.
-
Page 7: Operation
3. Replace the cover by sliding it in place until it snaps into position. 4. The batteries must now be charged before you use the headphones. Refer to the instructions on page 6 Charging the Batteries for details. -
Page 8: Installation
IN STALLATION TRANSMITTER 1. Remove the Transmitter from the packaging. 2. Plug the AC power adapter into the DC jack located on the rear of the transmitter. 3. Connect the AC power adapter to an electrical wall outlet. 4. The audio cord on the rear of the transmitter can be connected to the audio output jack (R &... - Page 9 2,4GHZ TRAN SMI TTER FRON T FREQUENCY ADJUST CHARGE INDICATOR (GREEN) POWER ON/SIGNAL INDICATOR (RED) BACK CHARGE CORD AUDIO CORD 2.4GHZ HEADPHON E RECEIV ER TUNING CONTROL VOLUME CONTROL RIGHT EARPHONE CHARGE LEFT EARPHONE INPUT DC POWER JACK ON/OFF SWITCH POWER INDICATOR TTER...
- Page 10 LTB LIMI TED 1 Y EAR WA RRAN TY LTB Audio Systems, Inc. warrants that for 1 year from the date of original purchase, it will r eplace this product if found to be defective in materials or workmanship. Return it postage prepaid to the Product Exchange Center address for prompt, no charge replacement with a current equivalent.
