  • Page 1 Notebook PC Hardware User’s Manual AF2.0 MEGA PIXELS E3842 / May 2008...

  • Page 2: Table Of Contents

    Contents Table of Contents Table of Contents 1. Introducing the Notebook PC About This User’s Manual ..................6 Notes For This Manual................... 6 Preparing your Notebook PC..................9 2. Knowing the Parts Top Side........................12 Bottom Side ......................15 Right Side ......................... 17 Left Side ........................
  • Page 3 Contents Table of Contents (Cont.) Status Indicators ....................34 4. Using the Notebook PC Pointing Device......................38 Using the Touchpad ..................... 38 Touchpad Usage Illustrations................39 Caring for the Touchpad..................40 Automatic Touchpad Disabling................40 Storage Devices ....................... 41 Expansion Card ....................41 Optical Drive ......................
  • Page 4 Contents...

  • Page 5: Introducing The Notebook Pc

    1. Introducing the Notebook PC About This User’s Manual Notes For This Manual Safety Precautions Preparing your Notebook PC There may be differences between your Notebook PC and the drawings shown in this manual. Please accept your Notebook PC as being correct. Photos and icons in this manual are used for artistic purposes only and do not show what is actually used in the product itself.

  • Page 6: About This User's Manual

    Introducing the Notebook PC About This User’s Manual You are reading the Notebook PC User’s Manual. This User’s Manual provides informa- tion on the various components in the Notebook PC and how to use them. The following are major sections of this User’s Manuals: 1.

  • Page 7: Safety Precautions

    Introducing the Notebook PC Safety Precautions The following safety precautions will increase the life of the Notebook PC. Follow all precautions and benzene, or other chemicals on or near the surface. IMPORTANT! Disconnect the AC power and remove the battery pack(s) before clean- ing.

  • Page 8: Transportation Precautions

    Introducing the Notebook PC Transportation Precautions To prepare the Notebook PC for transport, you should turn it OFF and disconnect all external peripher- als to prevent damage to the connectors. The hard disk drive’s head retracts when the power is turned OFF to prevent scratching of the hard disk surface during transport.

  • Page 9: Preparing Your Notebook Pc

    Introducing the Notebook PC Preparing your Notebook PC These are only quick instructions for using your Notebook PC. Read the later pages for detailed informa- tion on using your Notebook PC. 2. Connect the AC Power Adapter 1. Install the battery pack 3.
  • Page 10 Introducing the Notebook PC...

  • Page 11: Knowing The Parts

    2. Knowing the Parts Basic sides of the Notebook PC There may be differences between your Notebook PC and the drawings shown in this manual. Please accept your Notebook PC as being correct. Photos and icons in this manual are used for artistic purposes only and do not show what is actually used in the product itself.

  • Page 12: Top Side

    Knowing the Parts Top Side Refer to the illustration below to identify the components on this side of the Notebook PC. The keyboard will be different for each territory. AF2.0 MEGA PIXELS Num Lk Pause Scr Lk Prt Sc SysRq Break &...

  • Page 13: Display Panel

    Knowing the Parts Camera Indicator The camera indicator shows when the built-in camera is in use. The camera may be auto-activated by supported software. Multi-Position Camera (on selected models) The built-in camera allows picture taking or video recording. Can be Back used with video conferencing and other interactive applications.

  • Page 14: Touchpad And Buttons

    Knowing the Parts Touchpad and Buttons The touchpad with its buttons is a pointing device that provides the same functions as a desk- top mouse. A software-controlled scrolling function is available after setting up the included touchpad utility to allow easy Windows or web navigation. Fingerprint Scanner (on selected models) Status Indicators (front) Status indicators represent various hardware/software conditions.

  • Page 15: Bottom Side

    Knowing the Parts Bottom Side Refer to the illustration below to identify the components on this side of the Notebook PC. The bottom side may vary in appearance depending on model. The battery pack size will vary depending on model. WARNING! The bottom of the Notebook PC can get very hot.

  • Page 16: Battery Pack

    Knowing the Parts Battery Pack The battery pack is automatically charged when the Notebook PC is connected to an AC power source and maintains power to the Notebook PC when AC power is not connected. This allows use when moving PC.

  • Page 17: Right Side

    Knowing the Parts Right Side Refer to the illustration below to identify the components on this side of the Notebook PC. The compo- nents vary by model. Optical Drive The Notebook PC comes in various models with different optical drives. The Notebook tions for details on each model.

  • Page 18: Left Side

    Knowing the Parts Modem Port The RJ-11 modem port with two pins is smaller than the RJ-45 LAN port and supports a standard telephone cable. The internal modem supports up to 56K V.90 transfers. The built-in connector allows convenient use without additional adapters. IMPORTANT! The built-in modem does not support the voltage used in digital phone systems.

  • Page 19: Expresscard Slot

    Knowing the Parts HDMI Port (on selected models) HDMI and A/V receiver and an audio and/or video monitor, such as a digital television 8-channel digital audio, with bandwidth to spare to accommodate future enhancements or requirements. E-SATA E-SATA Port (on selected models) External SATA or eSATA allows external connection of Serial-ATA devices originally designed for use inside the computer.

  • Page 20: Front Side

    Knowing the Parts Front Side Refer to the illustration below to identify the components on this side of the Notebook PC. Flash Memory Slot Normally an external memory card reader must be purchased separately in order to use memory cards from devices such as digital cameras, MP3 players, mobile phones, and IEEE1394 Port (on selected models) IEEE1394 is a high speed serial bus like SCSI but has simple connections and hot- plugging capabilities like USB.
