Summary of Contents for VVME QA-4050A
- Page 1 MINI DESIGN MOSFET CAR AMPLIFIERS 1200W QA-4050A QA-4080A...
- Page 3 PRODUCT SPECIFICATIONS INTRODUCTION QA-4050A VVME RMS @ 4 Ohm (<1% DISTORTION)........4 X 60W RMS @ 2 Ohm (<1% DISTORTION)........4 X 80W Maximum Power Output............ 2 X 150W Frequency Response............5Hz ~ 30kHz VVME S/N Ratio................. >80dB THD................<0.05% VVME Input Sensitivity Level............
- Page 4 AMPLIFIER FUNCTIONS TROUBLESHOOTING QA-4050A FRONT REAR REAR FRONT 3.RCA Input Jacks 1.Front Speaker Output 4.Remote Control 2.Rear Speaker Output VVME For additional questions please contact your authorized dealer. PROTECT POWER FUSE Ground 4.40Amp Fuse 2.Remote Turn-on Input 5.Protection Circuit Indicator LED 3.Battery +12V Input...
- Page 5 QA-4080A 4-Channel Full-Range and Subwoofer System CH2 Full Range Ch4 Full Range CH1 Full Range Ch3 Full Range FRONT BASS GAIN BOOST FRONT FLAT 12dB BASS GAIN BOOST 50Hz 1.2KHz 50Hz 500Hz FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz FLAT 12dB FLAT 12dB 50Hz...
- Page 6 QA-4080A QA-4080A 2-Channel Full-Range Satellite, or Subwoofer FLAT System FRONT REAR REAR FRONT 1.Front Speaker Output 3.RCA Input Jacks 2.Rear Speaker Output 4.Remote Control FRONT BASS GAIN BOOST Ground 4.40Amp Fuse FLAT 12dB 2.Remote Turn-on Input 5.Protection Circuit Indicator LED 50Hz 1.2KHz 50Hz...
- Page 7 QA-4080A Bridged - Mono Subwoofer System CH2 Full Range FRONT CH1 Full Range BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz FLAT 12dB Subwoofer 50Hz 1.2KHz 50Hz 500Hz REAR FRONT BASS GAIN BOOST FLAT 12dB 50Hz 1.2KHz 50Hz 500Hz 1.Front GAIN Control 6.Rear GAIN Control FLAT...
- Page 8 QA-4080A INSTALLATION 4-Channel Full-Range Operation VVME We recommend you have the installation done by an Authorized Dealer. The ground wire should be connected directly with the chassis of your vehicle which should be a metal to metal ground point connection. The amplifier must be mounted securely at a solid, dry and low vibration surface in the trunk or passenger area.
- Page 9 QA-4050A WIRING AND APPLICATIONS 4-Channel Full-Range and Subwoofer System Our mini amplifiers can be used in a variety of system applications. A few examp- les are provided below. QA-4050A 4-Channel Full-Range Operation FRONT REAR M I N Remote Turn-on REAR...
- Page 10 QA-4050A QA-4050A Bridged - Mono Subwoofer System 4-Channel Satellite System FRONT REAR FRONT REAR REAR FRONT REAR FRONT CH2 Full Range Minimum Minimum Minimum CH1 Full Range Minimum Subwoofer Minimum Minimum Minimum FRONT FRONT BASS BASS GAIN GAIN BOOST BOOST...
