The World's smallest and finest CCPM
motor power Radio Control Helicopter
INSTRUCTION MANUAL
Specification :
Length w/blade: 736 mm (29")
Body Length : 533 mm (21")
Height
:
Rotor Diameter: Main - 584 mm (23")
Gear Ratio :
Flying weight : 550g (19.4 oz.)
Engine
:
Rotor blade : 270mm, Semi-symmetrical
Carrying case : Aluminium (included)
Recommended accessories (Not included):
Radio control : CCPM Program Mixing
Servo
:
Gyro
:
Battery
:
Speed control : 30A w/o brake
AMD
216 mm (8-1/2")
Tail - 123 mm (4.9")
101 : 1
4.5 : 1
with motor and radio
480 motor (included)
6 CH, 4 micro Servos
GWS PICO STD x 4
Futaba GY240 or GWS PG-01, PG-03
Li-Po 1,500mAh, 3S (11.1v)
Designed and Manufuactured by :
Aero Model Design
e-mail : info@amdhobby.com
Web Site : http://www.amdhobby.com
- Please read this manual in its entirety before
attempting to assemble the helicopter. In particular,
please read the section entitled 'Always follow these
rules for safety' before attempting to fly the helicopter.
- Keep this manual in a safe place.
- Changes in product specifications may be effected
without notice.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Cybercopter and is the answer not in the manual?

Questions and answers

Summary of Contents for AMD Cybercopter

  • Page 1 Designed and Manufuactured by : Aero Model Design e-mail : info@amdhobby.com Web Site : http://www.amdhobby.com The World's smallest and finest CCPM motor power Radio Control Helicopter INSTRUCTION MANUAL Specification : Length w/blade: 736 mm (29") Body Length : 533 mm (21") Height 216 mm (8-1/2") Rotor Diameter: Main - 584 mm (23")
  • Page 2 1500 rpm or the rotor fly off from the blade holder. Immediately replace parts if any suspicious condition is noted. The tip speed of the main rotor of Cybercopter may reach 200 kph or more. Make sure that there are no persons nearby upon flight.
  • Page 3 approximately 1km or more. It is necessary to confirm that there is nobody else using RC equipment within the area. (dangerous radio wave interference may occur unless a distance of 2km or more is provided when radio waves of the same frequency are being used.) Please note that the maker shall not be liable for any crashes or damages due to loosening of machine screws and poor servicing.
  • Page 4 Do not use the helicopter for purposes it was not designed for. Do not remodel or reconfigure the helicopter. Always operate within the designated limitations for the helicopter. Do not use for aerial photography or for the aerial application of chemicals.
  • Page 5 Use official replacement parts. Do not use parts other than those shown in this operating manual, or in AMD Catalogues, There is danger of accidents or injury. Practice operating the helicopter without turning the motor on.
  • Page 6 (10) Check to be sure that the gyro operates properly. In particular check the direction of operation the direction of operation during the startup. (11) Check to be sure that the helicopter body is properly lubricated. BEFORE TAKING OFF Before starting the motor , check to be sure that there no objects nearby that might be hit by, or become entangled in the rotor.
  • Page 7 WHILE INFLIGHT Maintain a good posture. Do not operate while sitting or lying on the ground. It is easy to lo se your footing on slopes. Please take care. Always unplug the motor connector : When adjusting the helicopter body or transmitter. When attaching or replacing parts.
  • Page 8 Always store with care. Store in a dry place, out of the reach of children. Consult your dealer, or our engineering service section regarding repairs. Repairs undertaken by persons without sufficient knowledge, or lacking the proper tools, can result in impaired performance, leading to accidents or injury.
  • Page 9 SWASHPLATE CONTROL SYSTEMS 3 - SERVO CCPM SWASHPLATE MIXING The 120 CCPM or Cyclic/Collective Pitch Mixing system offers the user a control system that accomplish the same control inputs as the one servo standard system, but with increased precision and reduced complexity. With the one servo system, CCPM system utilizes three servos for the three main controls : Aileron , elevator, and collective.
  • Page 10 CCPM SERVO CONNECTIONS The 120 CCPM system requires the use of three servos to operate, aileron, elevator, and Aux 1 (Pitch). The labeling of these servo can become quite confusing because with the CCPM with the CCPM function; the three servos no longer work independently, but rather as a team, and their functions are now combined. For this reason, we will refer to the three servos in the following manner: Aileron Servo : We will refer to this servo as the "Right"...
  • Page 11 CCPM PROGRAM ACTIVATION AND INITIAL ADJUSTMENT Radio system to be used : JR 3810 A) CCPM Setting Turn the power switch on, then press the up and down keys simultaneously to enter the fucntion mode. Press the Up key until "Swash Mix" apears on the screen. Once this has been completed, it will be necessary to change the value of the aileron, elevator, and pitch fucntions from the factory default setting using the + and - keys.
  • Page 12 Servo installation Left Front (Pitch) Front (Elevator) Rear Right (Aileron) Servo to be used : GWS PICO+F BB x 4...
  • Page 13 Cut away...
  • Page 14 Servo Installation - CCPM program mixing (Front) Elevator servo (Right) Aileron servo Rudder servo Receiver Speed control Battery Gyro Set the Swash plate to level (left) 25mm (Front) Pitch servo Elevator servo Rudder Receiver servo Speed control Batte Gyro Recommended accessories : Servo : GWS PICO+ F BB x 4 Speed control : ESC-30A (30Amp w/o brake) Battery : 1500 - 1800 mAh Li-Po, 3S, (11.1v)

  • Page 15: Main Body Assembly

    Main body assembly 106 -- 001...

  • Page 16: Main Frame Assembly

    Main Frame assembly 101 -- 003 101 -- 001...
  • Page 17 Main Mast assembly 101 -- 002 104 -- 005 101 -- 004 Landing Gear assembly 102 -- 001...
  • Page 18 Tail pipe assembly 103 -- 001 103 -- 003 103 -- 004 103 -- 005 103 -- 002 103 -- 006 103 -- 005...

  • Page 19: Rotor Head Assembly

    Rotor Head assembly 104 -- 007 104 -- 004 104 -- 001 104 -- 002 104 -- 003 104 -- 006...
  • Page 20 Code No Particulars Price(USD) Main Frame 101-001 Main Frame 32.00 101-002 Auto-rotation drive drive shaft assembly 19.20 101-003 480 motor with gear 15.40 101-004 Main gear 11.50 Landing gear 102-001 Landing gear set 1 set 15.40 Tail assembly 103-001 Tail gear assembly 1 set 12.80 103-002...
