- Page 1 Programme Series 30E/35E 30ET/35ET OWNER’S MANUAL OPERATING MANUAL AND USER GUIDE...
- Page 2 Programme Series 30E/30ET/35E/35ET IMPORTANT WARNINGS & SAFETY INSTRUCTIONS 1. READ ALL INSTRUCTIONS carefully and become familiar with the features and functions of these products before operating them. 2. RETAIN THESE INSTRUCTIONS for future reference. 3. COMPLY WITH ALL WARNINGS –...
-
Page 3: Table Of Contents
Programme Series 30E/30ET/35E/35ET TABLE OF CONTENTS Page Important Warnings and Safety Instructions 2……………………………………What about the Programme Series? 3…………………………………..Introduction and Overview 4……………………………………Features 5……………………………………Setting up/ Speaker Placement 7……………………………………Connections/Wiring 9..………………………………..Specifications 10…………………………………. Dimensional Drawings 11…………………………………..Warranty... - Page 4 When you need a powerful, easy to install and use sound reinforcement or background music system, you choose the system that can deliver the biggest sound for your money. The Programme 30E/30ET/35E/35ET system is just what you asked for.
- Page 5 We take great pride in engineering and building every Wharfedale Pro loudspeaker and wish to thank you for entrusting us with your sound. Please take a few minutes to read this manual completely in order to ensure that you get the most out of your Programme Series Loudspeaker system.
-
Page 6: Features
Programme Series 30E/30ET/35E/35ET FEATURES – Programme 30E/30ET 2-way loudspeaker system 1” (25.4mm) Mylar Dome drive unit Low distortion, high power, 5-1/4" (133.4mm) woofer 50 Watts Continuous Power Handling High strength MDF cabinet Pro-tech (PTC) driver protection ® Four (4) M6 hanging points... -
Page 7: Setting Up/ Speaker Placement
A set of wall mounting brackets is included with each pair of speakers to make installation easy and safe. The Programme 30E/30ET/35E/35ET can be oriented in a vertical or hori- zontal position. All models have been designed for tabletop or bookshelf installation or, with the use of the included brackets they can be mounted on the wall or ceiling. - Page 8 Programme Series 30E/30ET/35E/35ET Pro 30E/35E Line picture of the panel...
-
Page 9: Connections/Wiring
Programme Series 30E/35E CONNECTIONS/ WIRING Wiring and setting up your Programme 30E/30ET/35E/35ET is as easy as plugging in a household appliance. You simply run your speaker cables from your amplifier to one of the parallel spring style input connectors on the Pro- gramme 30E/30ET/35E/35ET input panel. - Page 10 Programme Series 30ET/35ET HIGH-IMPEDANCE/CONSTANT-VOLTAGE SYSTEM: The Programme 30ET features an internal line-matching transformer with four power/impedance selections for 100-volt line. In speaker systems, anything over 32Ω is considered high impedance. Smaller wire can be used without excessive power loss. The four switchable power taps are 1.25W, 2.5W, 5W and 10W (Pro30ET) and 5W, 10W, 20W, 40W (Pro35ET).
-
Page 11: Specifications
Programme Series 30E/30ET/35E/35ET SPECIFICATIONS E/30ET E/35ET Frequency response 75Hz-20kHz 65Hz – 20kHz v i t y t i Coverage Pattern (degrees) 70° H x 70°V 70° H x 70°V Power Continuous 50 Watts 60 Watts Program 100 Watts 120 Watts... - Page 12 Programme Series 30E/30ET/35E/35ET DIMENSIONS 166.000 140.000 TOP VIEW 5.500 REAR VIEW(30E) 2.500 166.000 166.000 SIDE VIEW FRONT VIEW REAR VIEW(30ET) PROGRAMME30E/30ET BOTTOM VIEW 196.00 Ø7.90 TOP VIEW 180.00 196.00 90.00 20.00 REAR VIEW(35E) 4-Ø7.9 196.00 FRONT VIEW SIDE VIEW Ø7.90...
-
Page 13: Warranty
Wharfedale Programme 30E/30ET/35E/35ET are warranted of manufacturing or material defects for a period of one year from the original date of purchase. In the event of malfunction, contact your authorized Wharfedale Pro dealer or distributor for information. *Be aware that warranty details may differ from country to country. Contact your deal-...
