INPUTS AND OUTPUTS
Your SpinDoctor features all the input and output options you need to get
the perfect sound in any situation.
Plug your guitar into the INPUT jack, and run a cable from the OUTPUT jack
to your combo amp or power amp, or from the SIM. OUT to a studio mixer or
your computer's AD converter.
When running SpinDoctor into a combo amp, make sure the HI/LOW button
on the bottom of the unit is in the "up" position (this lowers output).
If you use SpinDoctor as a preamp – either with a power amp or running into
a mixer/AD converter – keep the HI/LOW button in the "down" position.
SpinDoctor makes a great preamp for recording guitar in the studio.
When you're in the studio, try using the SIM. OUT to simulate the sound
of real speaker cabinet. Use the SIM. LEVEL knob to adjust volume, and the
FREQUENCY button to define the character of your "cabinet".
Your SpinDoctor also features a MIDI input for controlling the unit
remotely via an external MIDI device. Read on to learn how to use these MIDI
capabilities.

SETUP OPTIONS

OVERDRIVE PEDAL
POWER AMP
WITH COMBO AMP:
FROM GUITAR
PREAMP WITH POWER AMP
HOWER AMP:
CABINET
CABINET
FROM GUITAR
STUDIO PREAMP:
MIXER
FROM GUITAR
TO MIXER LINE INPUT
GUITAR
TO POWER AMP INPUT
(SET HIGH/LOW BUTTON TO LOW - TOP POSITION)
GUITAR
TO POWER AMP INPUT
(SET HIGH/LOW BUTTON TO HIGH - BOTTOM POSITION)
GUITAR
