User Manual GEM420 4G M2M Router...
Page 2: Table Of Contents
Proroute GEM420 4G M2M Router TABLE OF CONTENTS CHAPTER 1 INTRODUCTION ..........................7 ............................. 8 ONTENTS ..........................9 ARDWARE NSTALLATION 1.2.1 WARNING ..........................9 1.2.2 SYSTEM REQUIREMENTS ...................... 9 1.2.3 Hardware Configuration ......................10 1.2.4 LED Indication ......................... 12 CHAPTER 2 GETTING STARTED ........................
Page 3 Proroute GEM420 4G M2M Router 3.1.3.1.3 WDS Hybrid Mode ..........................70 3.1.3.1.4 WPS Setup ............................... 73 3.1.3.2 Wireless Client List........................74 3.1.3.3 Advanced Configuration ........................ 75 3.1.4 IPv6 Setup ..........................77 3.1.4.1 Static IPv6 ............................. 78 3.1.4.2 DHCP v6 ............................80 3.1.4.3...
Page 4 Proroute GEM420 4G M2M Router 3.2.1.4.3 Web Content Filter Configuration ......................107 3.2.1.5 MAC Control ..........................107 3.2.1.5.1 Configuration ............................108 3.2.1.5.2 MAC Control Rule List .......................... 108 3.2.1.5.3 MAC Control Rule Configuration ......................109 3.2.1.6 Application Filters ........................109 3.2.1.6.1...
Page 5 Proroute GEM420 4G M2M Router 3.2.3.3.2 L2TP Server Status ..........................135 3.2.3.3.3 User Account List ........................... 136 3.2.3.3.4 User Account Configuration ........................136 3.2.3.3.5 L2TP Client ............................136 3.2.3.3.6 L2TP Client List & Status ........................137 3.2.3.3.7 L2TP Client Configuration ........................137 3.2.3.4...
Page 6 Proroute GEM420 4G M2M Router ADDITIONAL INFORMATION ..............ERROR! BOOKMARK NOT DEFINED. GEM420 User Manual...
Page 7: Chapter 1 Introduction
Proroute GEM420 4G M2M Router Chapter 1 Introduction Thank you for purchasing the Proroute GEM420 4G Cellular M2M Gateway. For M2M (Machine-to-Machine) applications, the Proroute Cellular M2M Gateway is absolutely the right choice. With built-in world-class 4G LTE module, you just need to insert SIM card from local mobile carrier to get to Internet.
Page 8: Contents List
Proroute GEM420 4G M2M Router 1.1 Contents List Items Description Contents Quantity GEM420AM 1pcs Cellular M2M Gateway Cellular Antenna 2pcs WiFi Antenna 2pcs Power Adapter 1pcs (DC 12V/2A) 1pcs DC Jack Converter RJ45 Cable 1pcs Console Cable 1pcs 1pcs (Manual)
Page 9: Hardware Installation
Proroute GEM420 4G M2M Router 1.2 Hardware Installation 1.2.1 WARNING  Do not use the product in high humidity or high temperatures.  Only use the power adapter that comes with the package. Using a different voltage rating power adaptor is dangerous and may damage the product.
Page 10: Hardware Configuration
Proroute GEM420 4G M2M Router 1.2.3 Hardware Configuration Reset LED Indicators USB Port Button Cellular Auto MDI/MDIX RJ-45 Ports Console Cellular Antenna 4x FE LAN to connect local devices Port Antenna ※Reset Button The RESET button provides user with a quick and easy way to resort the default setting.
Page 11 Proroute GEM420 4G M2M Router 2.4G WiFi 2.4G WiFi Antenna Antenna Power Terminal Block GEM420 User Manual...
Page 12: Led Indication
Proroute GEM420 4G M2M Router 1.2.4 LED Indication LED Icon Indication LED Color Description Steady ON: Device is powered on by power Power Source 1 Green source 1 Power Source 2 Steady ON: Device is powered on by power Green...
Page 13: Chapter 2 Getting Started
2.1 Hardware Installation 2.1.1 Mount the Unit The GEM420 series can be placed on a desktop, mounted on the wall, or mounted on a DIN-rail. It has designed with “ears” for attaching to the wall or the inside of a cabinet. The wall-mount kits and DIN-rail bracket are not screwed on the product when out of factory.
Page 14: Connecting Power
Proroute GEM420 4G M2M Router 2.1.3 Connecting Power The GEM420 series can be powered by connecting a power source to the terminal block. It supports dual 9 to 48VDC power inputs . Following picture is the power terminal block pin assignments. Please check carefully and connect to the right power requirements and polarity.
Page 15: Easy Setup By Configuring Web Ui
LAN ports on the front panel. If you need to configure or troubleshoot the device, you may need to connect the GEM420 series directly to the host PC. In this way, you can also use the RJ-45 Ethernet cable to connect the GEM420 series to the host PC’s Ethernet port.
Page 16 Proroute GEM420 4G M2M Router A. Configure with the Network Setup Wizard Step 1 The network setup wizard will guide you to finish some basic settings, including login password, time zone, WAN interface, Ethernet LAN interface and WiFi LAN interface.
Page 17 Proroute GEM420 4G M2M Router Press “Next” to continue. Step 4: WAN WAN Interface Configuration: Choose type of WAN connection. You can select Ethernet WAN if you want to connect to Internet through fixed line. Or select 3G/4G if you want to connect to Internet through 3G/4G network.
Page 18 Proroute GEM420 4G M2M Router usually chosen when you use ADSL for WAN connection. Press “Next” to continue. Step 4-4: Ethernet (PPTP) If choosing Ethernet->PPTP, you need to input required dial-up information that you get from ISP. This option is usually chosen when your ISP requests it.
Page 19 Proroute GEM420 4G M2M Router WiFi Interface Configuration: Change the SSID, Channel Number, Authentication and Encryption Algorithm for first virtual AP of this gateway. You will see on your PC when doing wireless network scan. It’s strongly recommending you to add authentication and encryption in your wireless network to prevent any unknown WiFi clients and keep transferred data secured.
Page 20 Proroute GEM420 4G M2M Router Step 2: VPN Type Select type of VPN connection you want to create. Here you can choose IPSec, PPTP, or L2TP. Press “Next” to continue. Step 2-1: IPSec If choosing IPSec, there are two options of tunnel scenario can be chosen.
Page 21 Proroute GEM420 4G M2M Router Step 2-2: PPTP If choosing PPTP, there are two options of mode can be chosen. Choose “Client” if you want this device to connect to another PPTP server. Or choose “Server” if you want other PPTP clients to connect to it.
Page 22 Proroute GEM420 4G M2M Router Step 2-3: L2TP If choosing L2TP, there are two options of mode can be chosen. Choose “Client” if you want this device to connect to another L2TP server. Or choose “Server” if you want other L2TP clients to connect to it.
Page 23: Status
Proroute GEM420 4G M2M Router Step 3: Confirm and Apply Confirm new settings. If all new settings are correct, please press “Apply” button to save these new settings and take them effective. 2.2.2 Status There are 5 kinds of system status to be shown at this window. They are Network Status, WiFi Status, LAN Client List, Firewall Status and VPN Status.
Page 24 Proroute GEM420 4G M2M Router 1. 3G/4G Icon: Indicates if 3G/4G connection is established or not. 2. xDSL/Cable Icon: Indicates if Ethernet WAN connection is established or not. 3. Wired Client Icon: Indicates how many Ethernet clients are connected now.
Page 25 Proroute GEM420 4G M2M Router 3G/4G Modem Status Display modem information, link status, signal strength, and network (carrier) name of 3G/4G connection. Press “Detail” button to browse detailed information of cellular connection status. Internet Traffic Statistics Display number of transmitted packets and received packets of each WAN interface.
Page 26 Proroute GEM420 4G M2M Router of that dedicated virtual AP. WiFi Traffic Statistics: In order to view the traffic statistics of WiFi virtual APs, it will display operation band, virtual AP ID and the numbers of received packets and transmitted packets of all virtual APs on status page.
Page 27 Proroute GEM420 4G M2M Router In Firewall Status page, you can review lots information of filter status, including Packet Filters, URL Blocking, Web Content Filters, MAC Control, Application Filters, IPS and other options of firewall. Packet Filters Display all detected contents of firing activated packet filter rules.
Page 28: Chapter 3 Making Configurations
Proroute GEM420 4G M2M Router E. VPN Status In VPN Status page, you can review lots information of VPN status, including IPSec status, PPTP Server status, PPTP Client status, L2TP Server status and L2TP Client status. IPSec Status Display the status of all activated tunnels of IPSec.
Page 29 Proroute GEM420 4G M2M Router or to check the system status. These task buttons can be easily found in the cover page of the UI (User Interface). Enter the default password “admin” in the Password and then click ‘Login’ button.
Page 30: Basic Network
Proroute GEM420 4G M2M Router You can check status of WiFi at WiFi Status page, connected clients at LAN Client List page, and other advanced function status at Firewall Status page and VPN Status page. 3.1 Basic Network You can enter Basic Network for WAN, LAN&VLAN, WiFi, IPv6, NAT/Bridging, Routing, and Client/Server/Proxy settings as the icon shown here.
Page 31: Wan Setup
RJ45 cable from your external DSL modem and follow UI setting to setup. 6 The specification of embedded module depends on respective model. 7 Please refer to compatibility (www.gem420.com) list to check which 3G or LTE dongles are supported by this device.
Page 32: Physical Interface
Proroute GEM420 4G M2M Router 3.1.1.1 Physical Interface Click on the “Edit” button for each WAN interface and you can get the detail physical interface settings and then configure the settings as well. By default, the WAN-1 interface is forced to “Always-on” mode, and operates as the primary internet connection;...
Page 33 Proroute GEM420 4G M2M Router use embedded 3G/4G modem to operate as the primary Internet connection (WAN-1), please choose “3G/4G” for configuring the embedded 3G/4G modem as primary WAN connection. Or you can select “USB 3G/4G” if you want to use attached 3G/LTE USB dongle as an Internet connection.
Page 34: Internet Setup
Proroute GEM420 4G M2M Router changes. 3.1.1.2 Internet Setup There are three physical WAN interfaces that you can configure one by one to get proper Internet connection setup. They include the 3G/4G WAN, if the ISP is a mobile operator that can provide LTE, HSPA+, HSPA, WCDMA, EDGE, GPRS data services .
Page 35 Proroute GEM420 4G M2M Router 1. WAN Type: Choose “3G/4G” from the drop list. 1. Preferred SIM Card: Choose “SIM-A”, “SIM-B”, “SIM-A First” or “SIM-B First” for 3G/4G connection. There are two SIM card slots on this gateway and with four kinds of SIM card usage scenarios, including "SIM-A", "SIM-B", “SIM-A First”...
Page 36 Proroute GEM420 4G M2M Router 1. Dial-up Profile: After you subscribe 3G/4G data service, your operator will provide some information for you to setup connection, such as APN, dialed number, account or password. If you know this information exactly, you can choose “Manual-configuration”...
Page 37 Proroute GEM420 4G M2M Router 1. Time Schedule: This option allows you to limit WAN connection available in a certain time period. There is only “(0) Always” option available by default. You can add a new time schedule at System -> Scheduling menu.
Page 38: Ethernet Wan
Proroute GEM420 4G M2M Router Check Timeout: Set allowance of time period to receive response of keep-alive packet. If this gateway doesn’t receive response within this time period, this gateway will record this keep alive is failed. Latency Threshold: Set acceptance of response time. This gateway will record this keep-alive check is failed if the response time of replied packet is longer than this setting.
Page 39 Proroute GEM420 4G M2M Router WAN Type: choose “Dynamic IP” from the drop list. Host Name: Optional, required by some ISPs, for example, @Home. ISP registered MAC Address: Some ISP would ask you to register a MAC address for Internet connection. In this case, you need to enter the registered MAC address here, or simply press “Clone”...
Page 40 Proroute GEM420 4G M2M Router NAT: By default, it is enabled. If you disable this option, there will be no NAT mechanism between LAN side and WAN side. Network Monitoring: You can do preferred settings by using this feature to monitor the connection status of WAN interface.
Page 41 Proroute GEM420 4G M2M Router 3.1.1.2.2.2 Static IP Address Select this option if ISP provides a fixed IP address to you. You will need to enter in the IP address, subnet mask, and gateway address, provided to you by your ISP.
Page 42 Proroute GEM420 4G M2M Router DNS Query/ICMP Checking: Do the keep alive through DNS query packets or ICMP packets. Loading Checking: The response time of replied keep-alive packets may increase when WAN bandwidth is fully occupied. To avoid keep-alive feature...
Page 43 Proroute GEM420 4G M2M Router WAN Type: Choose “PPPoE” from the drop list. IPv6 Dual Stack: You can enable this option if your ISP provides not only one IPv4 but also one IPv6 address. PPPoE Account and Password: The account and password your ISP assigned to you.
Page 44 Proroute GEM420 4G M2M Router connection is available all the time. If choosing “Dial-on-demand”, this gateway won’t start to establish Internet connection until local data is going to be sent to WAN side. After that, this gateway will disconnect WAN connection if idle time reaches value of Maximum Idle Time.
Page 45 Proroute GEM420 4G M2M Router record this keep-alive check is failed if the response time of replied packet is longer than this setting. Fail Threshold: Times of failed checking. This WAN connection will be recognized as broken if the times of continuous failed keep-alive checking equals to this value.
Page 46 Proroute GEM420 4G M2M Router WAN Type: Choose “PPTP” from the drop list. IP Mode: Please check the IP mode your ISP assigned, and select “Static IP Address” or “Dynamic IP Address” accordingly. If you select “Static IP Address” option, you have to specify additional “WAN IP Address”, “WAN Subnet Mask”, and “WAN Gateway”...
Page 47 Proroute GEM420 4G M2M Router selecting “Auto-reconnect (Always-on)”, this gateway will start to establish Internet connection automatically since it’s powered on. It’s recommended to choose this scheme if for mission critical applications to ensure Internet connection is available all the time. If choosing “Dial-on-demand”, this gateway won’t start to establish Internet connection until local data is going...
Page 48 Proroute GEM420 4G M2M Router period, this gateway will record this keep alive is failed. Latency Threshold: Set acceptance of response time. This gateway will record this keep-alive check is failed if the response time of replied packet is longer than this setting.
Page 49 Proroute GEM420 4G M2M Router WAN Type: Choose “L2TP” from the drop list. IP Mode: Please check the IP mode your ISP assigned, and select “Static IP Address” or “Dynamic IP Address” accordingly. If you select “Static IP Address” option, you have to specify additional “IP Address”, “Subnet Mask”, and “WAN Gateway IP”...
Page 50 Proroute GEM420 4G M2M Router to choose this scheme if for mission critical applications to ensure Internet connection is available all the time. If choosing “Dial-on-demand”, this gateway won’t start to establish Internet connection until local data is going to be sent to WAN side. After that, this gateway will disconnect WAN connection if idle time reaches value of Maximum Idle Time.
Page 51: Load Balance
Proroute GEM420 4G M2M Router record this keep-alive check is failed if the response time of replied packet is longer than this setting. Fail Threshold: Times of failed checking. This WAN connection will be recognized as broken if the times of continuous failed keep-alive checking equals to this value.
Page 52 Proroute GEM420 4G M2M Router device will automatically allocate the outbound traffics to each WAN interface. By Priority If you choose the “By Priority” strategy, you have to further specify the outbound traffic percentage for each WAN interface. The load balancing mechanism will follow these settings to allocate proper traffics for each WAN to access the internet.
Page 53: Lan & Vlan Setup
Proroute GEM420 4G M2M Router 1. Source IP Address: Enter the expected Source IP Address for the load balance policy. It can be “Any”, “Subnet”, “IP Range”, or “Single IP”. Just choose one type of the source IP address, and specify its value as well. If you don’t want to specify a certain source IP address for this policy, just leave it as “Any”.
Page 54: Ethernet Lan
Proroute GEM420 4G M2M Router local networks. 3.1.2.1 Ethernet LAN Please follow the following instructions to do IPv4 Ethernet LAN Setup. LAN IP Address: The local IP address of this device. The computer on your network must use the LAN IP address of this device as their Default Gateway.
Page 55: Vlan
Proroute GEM420 4G M2M Router 3.1.2.2 VLAN This section provides a brief description of VLANs and explains how to create and modify virtual LANs which are more commonly known as VLANs. A VLAN is a logical network under a certain switch or router device to group lots of client hosts with a specific VLAN ID.
Page 56 Proroute GEM420 4G M2M Router There are some common VLAN scenarios as follows:  Port-Based VLAN Tagging for Differentiated Services Port-based VLAN function can group Ethernet ports, Port-1 ~ Port-4, and WiFi Virtual Access Points, VAP-1 ~ VAP-8, together for differentiated services like Internet surfing, multimedia enjoyment, VoIP talking, and so on.
Page 57 Proroute GEM420 4G M2M Router  Tag-based VLAN Tagging for Location-free Departments Tag-based VLAN function can group Ethernet ports, Port-1 ~ Port-4, and WiFi Virtual Access Points, VAP-1 ~ VAP-8, together with different VLAN tags for deploying department subnets in Intranet. All packet flows can carry with different VLAN tags even at the same physical port for Intranet.
Page 58 Proroute GEM420 4G M2M Router the packet frames that are received on a port. Administrator can further use a VLAN switch to separate the VLAN trunk to different groups based on VLAN ID. Following is an example. In SMB or a company, administrator schemes out 3 segments, Lobby &...
Page 59: Port-Based Vlan
Proroute GEM420 4G M2M Router only for trusted staffs or are accessed in secure tunnels. Inter VLAN Group Routing: In Port-based tagging, administrator can specify member hosts of one VLAN group to be able to communicate with the ones of another VLAN group or not. This is a communication pair, and one VLAN group can join many communication pairs.
Page 60 Proroute GEM420 4G M2M Router By default, all the 4 LAN ports and 8 virtual APs belong to one VLAN, and this VLAN is a NAT type network, all the local device IP addresses are allocated by DHCP server 1. If you want to divide them into different VLANs, click on the “Edit” button related to each port.
Page 61: Tag-Based Vlan
Proroute GEM420 4G M2M Router Above configuration example supports 3 access policies. The first one is Internet Access Policy that includes Port-1, Port-2, VAP-1 ~ VAP-4. All client hosts via these interfaces can access the Internet. The second policy is Intranet access Policy that includes Port-3 and VAP-5~ VAP-8.
Page 62: Wifi Setup
Proroute GEM420 4G M2M Router By default, all the LAN ports and virtual APs belong to one VLAN, and this VLAN ID is forced to “1”. It is a special tag based VLAN for device to operated, there is no tag required for this default VLAN ID.
Page 63: Wifi Configuration
Proroute GEM420 4G M2M Router 3.1.3.1 WiFi Configuration This device is equipped with IEEE802.11b/g/n 2Tx2R wireless radio, you have to configure 2.4G Hz operation band’s wireless settings and then activate your WLAN. There are several wireless operation modes provided by this device. They are: “AP Router Mode”, “WDS Hybrid Mode”, and “WDS Only Mode”.
Page 64 Proroute GEM420 4G M2M Router This mode allows you to get your wired and wireless devices connected with NAT. In this mode, this gateway is working as a WiFi AP, but also a WiFi hotspot. It means local WiFi clients can associate to it, and go to Internet. With its NAT mechanism, all of wireless clients don’t need to get public IP addresses from ISP.
Page 65 Proroute GEM420 4G M2M Router 4. Multiple AP Names: This device supports up to 8 SSIDs for you to manage your wireless network. You can select VAP-1 ~ VAP-8 and configure each wireless network if it is required. 5. Time Schedule: The wireless radio can be turn on according to the schedule rule you specified.
Page 66 Proroute GEM420 4G M2M Router In this mode, you can only choose “None” or “WEP” in the encryption field.  Shared Shared key authentication relies on the fact that both stations taking part in the authentication process have the same "shared" key or passphrase. The shared key is manually set on both the client station and the AP/router.
Page 67: Wds Only Mode
Proroute GEM420 4G M2M Router characters as the shared key. The key value is shared by the RADIUS server and this router. This key value must be consistent with the key value in the RADIUS server. The available encryption modes are “TKIP”, “AES”, or “TKIP/AES”.
Page 68 Proroute GEM420 4G M2M Router 1. Wireless Module: Enable the wireless function. 2. Wireless Operation Mode: Choose “WDS Only Mode” from the drop list. 3. Lazy Mode: This device support the Lazy Mode to automatically learn the MAC address of WDS peers, you don’t have to input other peer AP's MAC address.
Page 69 Proroute GEM420 4G M2M Router AP/router (WiFi gateway) containing a success or failure message. An example of when a failure may occur is if the client's MAC address is explicitly excluded in the AP/router configuration. In this mode you can enable 802.1x feature if you have another RADIUS server for user authentication.
Page 70: Wds Hybrid Mode
Proroute GEM420 4G M2M Router 8. Remote AP MAC 1 ~ Remote AP MAC 4: If you do not enable the Lazy mode, you have to enter the wireless MAC address for each WDS peer one by one. Afterwards, click on “Save” to store your settings or click “Undo” to give up the changes.
Page 71 Proroute GEM420 4G M2M Router 1. Wireless Module: Enable the wireless function. 2. Wireless Operation Mode: Choose “WDS Hybrid Mode” from the drop list. 3. Lazy Mode: This device support the Lazy Mode to automatically learn the MAC address of WDS peers, you don’t have to input other peer AP's MAC address.
Page 72 Proroute GEM420 4G M2M Router and WPA2-PSK.  Open Open system authentication simply consists of two communications. The first is an authentication request by the client that contains the station ID (typically the MAC address). This is followed by an authentication response from the AP/router (WiFi gateway) containing a success or failure message.
Page 73: Wps Setup
Proroute GEM420 4G M2M Router the “Scan” button to get the available AP’s MAC list automatically and select the expected item and copy its MAC address to the Remote AP MAC 1~4 one by one. 12. Remote AP MAC 1 ~ Remote AP MAC 4: If you do not enable the Lazy mode, you have to enter the wireless MAC address for each WDS peer one by one.
Page 74: Wireless Client List
Proroute GEM420 4G M2M Router connection will generate a new profile. 3. Configuration Mode: Select your Configuration Mode from “Registrar” or “Enrollee”. In most cases, for an AP router or AP, it should be in “Registrar” mode, so that other wireless clients in “Enrollee” mode can connect to the discovered “Registrar”.
Page 75: Advanced Configuration
Proroute GEM420 4G M2M Router 3.1.3.3 Advanced Configuration This device provides advanced wireless configuration for professional user to optimize the wireless performance under the specific installation environment. 1. Operation Band: Select the WiFi operation band that you want to configure. But the device supports only 2.4G single WiFi band.
Page 76 Proroute GEM420 4G M2M Router government regulations. 3. Beacon interval: Beacons are broadcast packets that are sent by a wireless AP/router. The main purpose of beacon packet is let wireless clients know this AP (SSID) when doing wireless network scan.
Page 77: Ipv6 Setup
Proroute GEM420 4G M2M Router 10. RF Bandwidth: Select Auto, HT20 or HT40 to define the RF bandwidth for a channel. By default, it is Auto for the device. 11. Transmit Power: Normally the wireless transmission power operates at 100% out power specification of this device.
Page 78: Static Ipv6
Proroute GEM420 4G M2M Router simplifies aspects of address assignment (stateless address auto-configuration), network renumbering and router announcements when changing Internet connectivity providers. This gateway supports various types of IPv6 connection (Static IPv6 / DHCPv6 / PPPoE / 6 to 4 / IPv6 in IPv4 tunnel). Please ask your ISP of what type of IPv6 is supported before you proceed with IPv6 setup.
Page 79 Proroute GEM420 4G M2M Router 1. IPv6 address: Enter the IPv6 address here; IPv6 addresses have a size of 128 bits. Therefore, IPv6 has a vastly enlarged address space compared to IPv4. An example of an IPv6 address is “2001:0db8:85a3:0000:0000:8a2e:0370:7334”...
Page 80: Dhcp V6
Proroute GEM420 4G M2M Router 1. Global Address: Please enter the global IPv6 address for LAN interface. 2. Link-Local Address: To show the IPv6 Link-Local address of LAN interface. Address Auto-configuration 1. Auto-configuration: Disable or enable this auto configuration setting.
Page 81 Proroute GEM420 4G M2M Router 1. DNS: You may select to obtain DNS server address from Server or entry IPv6 address Primary DNS address and secondary DNS address. 2. MLD Snooping: MLD snooping, IPv6 multicast data is selectively forwarded to a list of ports that want to receive the data, instead of being flooded to all ports in a VLAN.
Page 82: Pppoev6
Proroute GEM420 4G M2M Router announcing the IP address of that interface. Hosts discover the addresses of their neighboring routers simply by listening for advertisements. When a host attached to a multicast link starts up, it may multicast a Router Solicitation to ask for immediate advertisements, rather than waiting for the next periodic ones to arrive;...
Page 83: To 4
Proroute GEM420 4G M2M Router LAN Configuration 1. Global Address: Please enter the global IPv6 address for LAN interface. 2. Link-Local Address: To show the IPv6 Link-Local address of LAN interface. Address Auto-configuration 1. Auto-configuration: Disable or enable this auto configuration setting.
Page 84 Proroute GEM420 4G M2M Router 1. 6 to 4 Address: You may obtain IPv6 DNS automatically or set DNS address manually for Primary DNS address and secondary DNS address. 2. Primary / Secondary DNS: Please enter IPv6 primary DNS address and secondary DNS address.
Page 85: In 4
Proroute GEM420 4G M2M Router solicitation a small number of times, but then must desist from sending any more solicitations. Any routers that subsequently start up, or that were not discovered because of packet loss or temporary link partitioning, are eventually discovered by reception of their periodic (unsolicited) advertisements.
Page 86: Nat / Bridging
Proroute GEM420 4G M2M Router Address Auto-configuration 1. Auto-configuration: Disable or enable this auto configuration setting. 2. Auto-configuration Type: You may set stateless or stateful (Dynamic IPv6). 3. Router Advertisement Lifetime: You can set the time for the period that the router send (broadcast) its router advertisement.
Page 87: Configuration
Proroute GEM420 4G M2M Router 3.1.5.1 Configuration 1. NAT Loopback: Allow you to access the WAN IP address from inside your local network. This is useful when you run a server inside your network. For an example, if you set a mail server at LAN side, your local devices can access this mail server through gateway’s WAN IP address.
Page 88: Virtual Computer
Proroute GEM420 4G M2M Router Private port 80) at 192.168.123.3, and a VPN server at 192.168.123.6, then you need to specify the following virtual server mapping table Public Port Server IP Private Port Protocol Rule 192.168.123.1 Enable 192.168.123.2 Enable 8080 192.168.123.3...
Page 89: Dmz
Proroute GEM420 4G M2M Router conferencing, Internet telephony, etc. Because of the firewall function, these applications cannot work with a pure NAT router. The Special Applications feature allows some of these applications to work with this product. If the mechanism of Special Applications fails to make an application work, try setting your computer as the DMZ host instead.
Page 90: Routing Setup
Proroute GEM420 4G M2M Router specific application is blocked by NAT mechanism, you can indicate that LAN computer as a DMZ host to solve this problem. 1. IP Address of DMZ Host: Enter IP address of Server or Host. 2. DHCP Relay: DHCP Relay Agent component relays DHCP messages between DHCP clients and DHCP servers on different IP networks.
Page 91: Dynamic Routing
Proroute GEM420 4G M2M Router to determine which physical interface addresses are utilized for outgoing IP data grams. You can enter the destination IP address, Subnet Mask, Gateway, and Metric for each routing rule, and then enable or disable the rule by checking or un-checking the Enable checkbox.
Page 92 Proroute GEM420 4G M2M Router 1. RIP: Routing Information Protocol (RIP) will exchange information about destinations for computing routes throughout the network. Please select RIPv2 only if you have different subnets in your network. Otherwise, please select RIPv1 if you need this protocol.
Page 93 Proroute GEM420 4G M2M Router You can enable the OSPF routing function by checking “Enable” checkbox for the OSPF item and filling the “Backbone Subnet”. You can add up to 8 area subnets for the OSPF network and enable them individually. But also you can modify some existed OSPF areas by clicking corresponding “Edit”...
Page 94: Routing Information
Proroute GEM420 4G M2M Router You can enable the BGP routing function by checking “Enable” checkbox for the BGP item and filling the “Self ID”. You can add up to 8 BGP neighbors for the BGP network and enable them individually. But also you can modify some existed BGP neighbors by clicking corresponding “Edit”...
Page 95: Client/Server/Proxy
3.1.7 Client/Server/Proxy 3.1.7.1 Dynamic DNS For remote access to the GEM420 4G router via 3G/4G network connection to use port forwarding to connect to devices on the LAN and you are not using Fixed IP SIM card services then there is the option of using a DDNS service provider. It can be free or charged.
Page 96: Dhcp Server
Proroute GEM420 4G M2M Router Host Name: Register a domain name to the DDNS provider. The fully domain name is concatenated with hostname (you specify) and a suffix(DDNS provider specifies). Username/E-mail: Input username or E-mail based on the DDNS provider you registered.
Page 97 Proroute GEM420 4G M2M Router 1. DHCP Server Name: The server name of DHCP server. By default, they are “DHCP 1” ~ “DHCP 4”. 2. LAN IP Address: Specify the local IP address of the enabled DHCP Server. It’s the LAN IP address of this gateway for DHCP server. For other DHCP servers, their LAN IP Addresses also have default values and can be modifies by user.
Page 98 Proroute GEM420 4G M2M Router 4. IP Pool Starting / Ending Address: Whenever there is a request, the DHCP server will automatically allocate an unused IP address from the IP address pool to the requesting computer. You must specify the starting / ending address of the IP address pool.
Page 99: Advanced Network
Proroute GEM420 4G M2M Router For internal servers, you can use this feature to ensure each of them receives same IP address all the time. 3.2 Advanced Network This device also supports many advanced network features, such as Firewall, QoS &...
Page 100: Firewall
Proroute GEM420 4G M2M Router 3.2.1 Firewall The firewall functions include Packet Filters, URL Blocking, Web Content Filters, MAC Control, Application Filters, IPS and some firewall options. 3.2.1.1 Configuration One Firewall Enable check box lets you activate all firewall functions that you want.
Page 101: Configuration
Proroute GEM420 4G M2M Router 3.2.1.2.1 Configuration You can enable packet filter function here. And select one of the two filtering policies as follows. The first one is to define the black list. System will block the packets that match the active filter rules. However, the second one is the white list. System will allow the packets to pass the gateway, which match the active filter rules.
Page 102: Packet Filter Rule Configuration
Proroute GEM420 4G M2M Router 3.2.1.2.3 Packet Filter Rule Configuration It supports the adding of one new rule or the editing of one existed rule. There are some parameters need to be specified in one packet filter rule. They are Rule Name, From Interface, To Interface, Source IP, Destination IP, Destination Port, Protocol, Time Schedule and finally, the rule enable.
Page 103: Url Blocking
Proroute GEM420 4G M2M Router 7. Protocol: Specify which packet protocol is to be filtered. It can be TCP, UDP, or Both. 8. Time Schedule: The rule can be turn on according to the schedule rule you specified, and give user more flexibility on access control. By default, it is always turned on when the rule is enabled.
Page 104: Configuration
Proroute GEM420 4G M2M Router 3.2.1.3.1 Configuration 1. URL Blocking: Check the enable box if you want to activate URL Blocking function. 2. Black List / White List: Select one of the two filtering policies for the defined rules in URL Blocking Rule List.
Page 105: Url Blocking Rule Configuration
Proroute GEM420 4G M2M Router 3.2.1.3.3 URL Blocking Rule Configuration It supports the adding of one new rule or the editing of one existed rule. There are some parameters need to be specified in one URL blocking rule. They are Rule Name, URL / Domain Name / Keyword, Destination Port, Time Schedule and finally, the rule enable.
Page 106: Configuration
Proroute GEM420 4G M2M Router like ".exe", ".bat" (applications), "mpeg” (video), and block HTML requests with some script types, like Java Applet, Java Scripts, cookies and Active X. 3.2.1.4.1 Configuration 1. Web Content Filters: Check the Enable box if you want to enable Web Content Filters function.
Page 107: Web Content Filter Configuration
Proroute GEM420 4G M2M Router 3.2.1.4.3 Web Content Filter Configuration It supports the adding of one new rule or the editing of one existed rule. There are some parameters need to be specified in one Web Content Filter rule. They are Rule Name, User-defined File Extension List, Time Schedule and finally, the rule enable.
Page 108: Configuration
Proroute GEM420 4G M2M Router 3.2.1.5.1 Configuration 1. MAC Control: Check the “Enable” box to activate the MAC Control function. All of the settings in this page will take effect only when “Enable” is checked. 2. Black List / White List: Select one of the two filtering policies for the defined rules.
Page 109: Mac Control Rule Configuration
Proroute GEM420 4G M2M Router Control Rule List. Besides, unnecessary rules can be removed by checking the “Select” box for those rules and then clicking on the “Delete” command button at the MAC Control Rule List caption. 3.2.1.5.3 MAC Control Rule Configuration It supports the adding of one new rule or the editing of one existed rule.
Page 110: Configuration
Proroute GEM420 4G M2M Router 3.2.1.6.1 Configuration 1. Application Filters: Check the “Enable” box to activate the Application Filters function. All of the settings in this page will take effect only when “Enable” is checked. 2. Log Alert: Enable the log alerting so that system will record Application Filter events when filtering rules are fired.
Page 111: Options
Proroute GEM420 4G M2M Router system will record Intrusion events when corresponding intrusions are detected. 3.2.1.8 Options 1. Stealth Mode: Enable this feature, this device will not respond to port scans from the WAN so that makes it less susceptible to discovery and attacks on the Internet.
Page 112: Qos & Bwm
It is indeed required that an access gateway satisfies the requirements of latency-critical applications, minimum access right guarantee, fair bandwidth usage for same subscribed condition and flexible bandwidth management. PROROUTE Security Gateway provides a Rule-based QoS to carry out the requirements.
Page 113: Configuration
Proroute GEM420 4G M2M Router 3.2.2.1 Configuration  QoS on Multiple WAN Interfaces  QoS on all WAN interfaces satisfies the requirements of latency-critical applications, minimum access right guarantee, fair bandwidth usage for same subscribed condition and flexible bandwidth management in a more flexible approach.
Page 114: Rule-Based Qos
Proroute GEM420 4G M2M Router 1. Total Priority Queues of All WANs: Input the maximum number of priority queues for all WAN interfaces. 2. WAN Interface: Select the WAN interface to configure following parameters. 3. Bandwidth of Upstream: The maximum bandwidth of uplink in Mbps.
Page 115: Configuration
Proroute GEM420 4G M2M Router  Well-known services include FTP(21), SSH(TCP:22), Telnet(23), SMTP(25), DNS(53), TFTP(UDP:69), HTTP(TCP:80), POP3(110), Auth(113), SFTP(TCP:115), SNMP&Traps(UDP:161-162), LDAP(TCP:389), HTTPS(TCP:443), SMTPs(TCP:465), ISAKMP(500), RTSP(TCP:554), POP3s(TCP:995), NetMeeting(1720), L2TP(UDP:1701) and PPTP(TCP:1723).  Available Control Functions  There are 4 resources can be applied in a QoS rule: bandwidth, connection sessions, priority queues and DiffServ Code Point (DSCP).
Page 116: Qos Rule Configuration
Proroute GEM420 4G M2M Router corresponding “Edit” command buttons at the end of each rule in the QoS Rule List. Besides, unnecessary rules can be removed by checking the “Select” box for those rules and then clicking on the “Delete” command button at the QoS Rule List caption.
Page 117 Proroute GEM420 4G M2M Router defined as an IP range. And “Group Object” is defined in the System -> Grouping menu. But what kinds of groups to use depend on model. 3. Service: There are 5 options for service, including All, DSCP, TOS, User-defined Services and Well-known Service, like By default, it is “All”.
Page 118 Proroute GEM420 4G M2M Router 4. Resource: There are 4 resources can be chosen to control in a QoS rule. They are “Bandwidth”, “Connection Sessions”, “Priority Queues” and “DiffServ Code Points”. 5. Control Function: It depends on the chosen resource. For “Bandwidth” resource, the control function is “Set MINR &...
Page 119 Proroute GEM420 4G M2M Router Scheduling menu. 9. Enable: Check the box if you want to enable the rule. Each rule can be enabled or disabled individually. Afterwards, click on “Save” to store your settings or click “Undo” to give up the changes.
Page 120: Vpn Setup
Proroute GEM420 4G M2M Router  Interface: Select “WAN-1”.  Group: Select “IP” and enter IP range: 192.168.75.10 ~ 40.  Service: Select “ALL”.  Resource: Select “Connection Sessions”.  Control Function: Select “Set Session Limitation”, and set session number to 20000.
Page 121: Ipsec
Proroute GEM420 4G M2M Router NetBIOS over IPSec, NAT Traversal and Dynamic VPN. In Configuration page, there is only one parameter, “VPN” with “Enable” checkbox. Check that box to activate the VPN function whatever you use which tunneling technology beforehand.
Page 122 Proroute GEM420 4G M2M Router  Dynamic VPN Business Security Gateway can ignore IP information of clients when using Dynamic VPN, so it is suitable for users to build VPN tunnels with Business Security Gateway from a remote mobile host or mobile site. Remote peer is a host or a site will be indicated in the negotiation packets, including what remote subnet is.
Page 123: Ipsec Configuration
Proroute GEM420 4G M2M Router 3.2.3.1.2 IPSec Configuration IPSec: You could trigger the function of IPSec VPN if you check “Enable” box. NetBIOS over IPSec: If you would like two Intranets behind two Business Security Gateways to receive the NetBIOS packets from Network Neighborhood, you have to check “Enable”...
Page 124: Tunnel List & Status
Proroute GEM420 4G M2M Router 3.2.3.1.3 Tunnel List & Status Add: You can add one new IPSec tunnel with Site to Site scenario by clicking the “Add” button. Delete: Delete selected tunnels by checking the “Select” box at the end of each tunnel list and then clicking the “Delete”...
Page 125: Authentication
Proroute GEM420 4G M2M Router Full Tunnel: All traffic from Intranet of Business Security Gateway goes over the IPSec VPN tunnel if these packets don’t match the Remote Subnet of other IPSec tunnels. That is, both application data and Internet access packets land up at the VPN concentrator.
Page 126: Ike Proposal Definition
Proroute GEM420 4G M2M Router Negotiation Mode: Choose Main Mode or Aggressive Mode: Main Mode provides identity protection by authenticating peer identities when pre-shared keys are used. The IKE SA’s are used to protect the security negotiations. Aggressive mode will accelerate the establishing speed of VPN tunnel, but the device will suffer from less security in the meanwhile.
Page 127: Ipsec Phase
Proroute GEM420 4G M2M Router There are 4 IKE proposals can be defined by you and used in IKE phase of negotiation between two VPN peers. Encryption: There are six algorithms can be selected: DES, 3DES, AES-auto, AES-128, AES-192, and AES-256.
Page 128: Manual Proposal
Proroute GEM420 4G M2M Router PFS Group: There are nine groups can be selected: None, Group 1 (MODP768), Group 2 (MODP1024), Group 5 (MODP1536) and Group14 ~ 18. Once the PFS Group is selected in one IPSec proposal, the one in other 3 IPSec proposals uses the same choice.
Page 129: Pptp / L2Tp Vpn Tunnel Scenarios
Proroute GEM420 4G M2M Router to encapsulate PPP packets. The PPTP specification does not describe encryption or authentication features and relies on the Point-to-Point Protocol being tunneled to implement security functionality. However, the most common PPTP implementation shipping with the Microsoft Windows product families implements various levels of authentication and encryption natively as standard features of the Windows PPTP stack.
Page 130: Pptp Server Configuration
Proroute GEM420 4G M2M Router The Business Security Gateway can behave as a PPTP server and a PPTP client at the same time. PPTP: Check the “Enable” box to activate PPTP client and server functions. Client/Server: Choose Server or Client to configure corresponding role of PPTP VPN tunnels for the Business Security Gateway beneath the choosing screen 3.2.3.2.2 PPTP Server Configuration...
Page 131: Pptp Server Status
Proroute GEM420 4G M2M Router Server Virtual IP: It is the virtual IP address of PPTP server used in PPTP tunneling. This IP address should be different from the gateway one and members of LAN subnet of Business Security Gateway.
Page 132: User Account Configuration
Proroute GEM420 4G M2M Router at the end of each user account list. 3.2.3.2.5 User Account Configuration Add or edit one user account will activate the “User Account Configuration” screen. User Name: Enter the user name of user account. Password: Enter the password of user account.
Page 133: Pptp Client Configuration
Proroute GEM420 4G M2M Router 3.2.3.2.8 PPTP Client Configuration PPTP Client Name: The name of this tunnel. Operation Mode: Default is “Always on” and other options depend on product models. Remote IP/FQDN: The IP address or Domain name of remote PPTP server.
Page 134: L2Tp
Proroute GEM420 4G M2M Router Business Security Gateway can go to access Internet via remote PPTP server. By default, it is enabled. However, if you want the remote PPTP Server to monitor the Intranet of local Business Security Gateway, the option can’t be enabled.
Page 135: L2Tp Server Status
Proroute GEM420 4G M2M Router 1. L2TP Server: Enable or disable L2TP server function. 2. L2TP over IPSec: L2TP over IPSec VPNs allow you to transport data over the Internet, while still maintaining a high level of security to protect data. Enter a Pre-shared key that system will use it in IPSec tunneling.
Page 136: User Account List
Proroute GEM420 4G M2M Router Refresh: To refresh the L2TP Server Status each 2 seconds by clicking on the “Refresh” button. Disconnect: To terminate the connection between L2TP server and remote dialing in L2TP clients by clicking on the “Disconnect” button.
Page 137: L2Tp Client List & Status
Proroute GEM420 4G M2M Router L2TP Client Configuration: Enable or disable L2TP client function. 3.2.3.3.6 L2TP Client List & Status You can add new up to 22 different L2TP client tunnels by clicking on the “Add” button, and modify each tunnel configuration by clicking on the corresponding “Edit” button at the end of each existed tunnel.
Page 138: Gre
Proroute GEM420 4G M2M Router Remote LNS Port: Port number of remote L2TP server. User Name: The user name which can be validated by remote L2TP server. Password: The password which can be validated by remote L2TP server. Tunneling Password: Enter tunneling password if remote L2TP server requests it.
Page 139: Gre Configuration
Proroute GEM420 4G M2M Router There is one common GRE VPN connection scenario as follows:  GRE Server / Client Application The Business Security Gateway acts as GRE Server or Client role in SMB Headquarters or Branch Office. 3.2.3.4.2 GRE Configuration GRE Tunnel: Check the “Enable”...
Page 140: Gre Rule Configuration
Proroute GEM420 4G M2M Router 3.2.3.4.4 GRE rule Configuration Tunnel Name: The name of this GRE tunnel. Interface: Choose WAN interface for GRE tunnel. Operation Mode: Default is “Always on” and other options depend on product models. Tunnel IP: The gateway IP address of Business Security Gateway.
Page 141: Redundancy
Proroute GEM420 4G M2M Router 11. IPSec Pre-shared Key: This option is only for DMVPN spoke function. If you enable DMVPN spoke feature, you need to enter same pre-shared key of your existed IPSec tunnel. 12. Tunnel: Enable or disable this GRE tunnel.
Page 142: System Management
Proroute GEM420 4G M2M Router 1. VRRP: Enable or disable the VRRP function. 2. Virtual Server ID: Means Group ID. Specify the ID number of the virtual server. Its value ranges from 1 to 255. 3. Priority of Virtual Server: Specify the priority to use in VRRP negotiations. Valid values are from 1 to 254, and a larger value has higher priority.
Page 143: Snmp
Proroute GEM420 4G M2M Router TR-069 is a customized feature for ISP; it is not recommend that you change the configuration for this. If you have any problem in using this feature for device management, please contact with your ISP or the ACS provider for help. At the right upper corner of TR-069 Setting screen, one “[Help]”...
Page 144 Proroute GEM420 4G M2M Router  Supported MIBs  MIB-II (RFC 1213, Include IPv6)  IF-MIB, IP-MIB, TCP-MIB, UDP-MIB  SMIv1 and SMIv2  SNMPv2-TM and SNMPv2-MIB  AMIB (PROROUTE Private MIB) 1. SNMP Enable: You can check “LAN”, “WAN” or both to enable SNMP function. If “LAN”...
Page 145: Telnet With Cli
Proroute GEM420 4G M2M Router 1. User Name: user name of this user profile. 2. Password: password of this user profile. 3. Authentication: MD5 or SHA-1 for authentication. 4. Encryption: DES is available for encryption. 5. Privacy Mode: Three options are available for authentication and encryption.
Page 146: Upnp
Proroute GEM420 4G M2M Router 3.2.5.4 UPnP UPnP Internet Gateway Device (IGD) Standardized Device Control Protocol is a NAT port mapping protocol and is supported by some NAT routers. It is a common communication protocol of automatically configuring port forwarding. Applications using peer-to-peer networks, multiplayer gaming, and remote assistance programs need a way to communicate through home and business gateways.
Page 147: Mobile Application
Proroute GEM420 4G M2M Router 3.3.1 Mobile Application 3.3.1.1 SMS You can compose new SMS message and check received SMS message on this gateway. 1. Physical Interface: Indicate which 3G/LTE modem is used for SMS feature. 2. SMS: Indicate which SIM card is used for SMS feature.
Page 148 Proroute GEM420 4G M2M Router “SIM Card Only” for SMS storage. This gateway can forward received SMS message automatically. Press “Add” to add new rule. 1. From Phone Number: Indicate phone number of sender. 2. Alert Approach: Decide the way to forward message. You can forward this message to another phone number, or to a mail address, or to a syslog server.
Page 149: Ussd
Proroute GEM420 4G M2M Router Read New SMS Message You can read, delete, reply, and forward messages in this inbox section. 1. Refresh: You can press “Refresh” button to renew SMS lists. 2. Delete, Reply, Forward Messages: After reading message, you can check the checkbox on the right of each message to delete, reply, or forward this message.
Page 150: Network Scan
Proroute GEM420 4G M2M Router USSD Configuration You can compose a USSD message, and sends it to the service provider, where it is received by a computer dedicated to USSD. The answer from this computer is sent back to this device, but it is usually with a very basic presentation.
Page 151: Remote Management
Proroute GEM420 4G M2M Router This part is for 3G/LTE cellular network scan. Usually, this part would be done automatically. Manual scan is used for problem diagnosis. 1. Physical Interface: Indicate which 3G/LTE modem is used for network scan. And SIM Status indicates which SIM card is used to Network Scan.
Page 152 Proroute GEM420 4G M2M Router Management Settings 1. Remote Management via SMS: Check this to enable this function. 2. Delete SMS for Remote Management: This device will delete received SMS message that is for remote management purpose if enabling this option. This option can prevent storage space of SIM card from being occupied continuously.
Page 153 Proroute GEM420 4G M2M Router 1. Status: Enable it, and you can send command “status” to query WAN connection status. For 3G/LTE WAN, router will send back WAN IP address, network name, network type, and connection time via SMS. For Ethernet WAN, router will send back WAN IP address and connection time via SMS.
Page 154: Captive Portal
Proroute GEM420 4G M2M Router 1. Access Control: Users can decide which phone number can send commands to this gateway or receive notifications when enable this option. 2. Phone 1~5: For security concern, this gateway won’t deal with the command if that phone number is not in the list even the security key is correct.
Page 155 Proroute GEM420 4G M2M Router NOTE: All Internet Packets will forward to Captive Portal Web site of the gateway when enabled this feature. Please make sure that you had one account and password. GEM420 User Manual...
Page 156: System
Proroute GEM420 4G M2M Router 3.4 System In the System section you can see system related information and system logs, use system tools for system update and do some network tests. Besides, you can also define some time scheduling rules here to be applied at various applications in the device system.
Page 157: System Information
Proroute GEM420 4G M2M Router the system password for security reason. Click on “Save” to store your settings or click “Undo” to give up the changes. 1. Old Password: Input the old password of administrator. 2. New Password: Input the new password of administrator for future logging in.
Page 158: System Tools
Proroute GEM420 4G M2M Router 1. Web Log: You can select the log types to be collected in the web log area. There are “System”, “Attacks”, “Drop”, and “Debug” types for you to select. 2. Email Alert: This device can also export system logs via sending emails to specific recipients.
Page 159 Proroute GEM420 4G M2M Router System Time There are three approaches to setup the system time. Before the process, some basic information must be filled by clicking on the “Configure” command button. Basic information includes following items: 1. Time Zone: Select a time zone where this device locates.
Page 160 Proroute GEM420 4G M2M Router “Sync with my PC”. Click on the button to let system synchronizes its date and time to the ones of the configuration PC. FW Upgrade If new firmware is available, you can upgrade router firmware through the WEB GUI here.
Page 161 Proroute GEM420 4G M2M Router Tracert Test Traceroute is a network diagnostic tool for displaying the route (path) and measuring transit delays of packets across an IP network. Traceroute proceeds unless all (three) sent packets are lost more than twice, then the connection is lost and the route cannot be evaluated.
Page 162: Scheduling
Proroute GEM420 4G M2M Router Reset to Default You can reset this device to factory default settings by clicking the “Reset” button. Wake on LAN Wake on LAN (WOL) is an Ethernet networking standard that allows a computer to be turned on or awakened by a network message.
Page 163: External Servers
Proroute GEM420 4G M2M Router Afterwards, click “save” to store your settings or click “Undo” to give up the changes. 3.4.3 External Servers This device supports six types of external server objects to be created. They are Email Server objects, Syslog Server objects, RADIUS Server objects, Active Directory Server objects, LDAP Server objects and UAM Server objects.
Page 164: External Server List
Proroute GEM420 4G M2M Router 3.4.3.1 External Server List External Server List can show the list of all defined external server objects and their attributes in this window. You can add one new external server object by clicking on the “Add” command button. But also you can modify some existed external server objects by clicking corresponding “Edit”...
Page 165: Mmi
Proroute GEM420 4G M2M Router 2. Server IP/FQDN: Specify the IP address or domain name of external server. 3. Server Port: Specify the service port of external server. 4. Server Type: Select one server type from the option list of “Email Server”, “Syslog Server”, “RADIUS Server”, “Active Directory Server”, “LDAP Server”...
Page 166 Proroute GEM420 4G M2M Router Additional Information For support please contact your supplier in the first instance. GEM420 User Manual...

Proroute GEM420 User Manual

Chapter 1 Introduction

Chapter 2 Getting Started

Chapter 3 Making Configurations

Quick Links

User Manual

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Proroute GEM420

Table of Contents
