- Page 1 INSTALLATION MANUAL LED TV Please read this manual carefully before operating your set and retain it for future reference. 32LY340C-CA 42LY320C-CA 42LY540S-CA 42LY340C-CA 49LY320C-CA 47LY540S-CA 47LY340C-CA 55LY540S-CA 55LY340C-CA 60LY540S-CA 60LY340C-CA www.lg.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS DigiTAL SigNAgE MEDiA PLAyEr Digital Signage Media Player Overview iNSTALLATiON MENu Introduction LG Hotel Mode Setup TV Manager - 1. USB - 2. Diagnostics Password Change Set ID Setup Configuration Setup Multi Timer Lock Mode External Speaker... -
Page 3: Digital Signage Media Player
DigiTAL SigNAgE MEDiA PLAyEr Digital Signage Media Player Overview (* Only for LY540S series) The Digital Signage Media Player can play content produced and distributed by SuperSign Elite-W. Supported content types consist of photographs, videos, external inputs such as TV broadcasts, texts, and music. -
Page 4: Installation Menu
The abundant functions for Hotel TV linked with software installation can be projected on OSD as ‘Installation Menu’. The wide range of hotel features can be performed simply on additional window to enhance the LG hotel TV’s easy installation and convenient operation for Hotelier and System Integrators. -
Page 5: Lg Hotel Mode Setup
Previous S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the LG Hotel Mode Setup. Use the OK button and then button to select Hotel Mode Operation. *When 'Hotel Mode Operation' is set to Yes(Work), all functions of Hotel Mode apply. - Page 6 Operation’ and ‘Local Key Operation’ will be worked by below. (4-1) ir Operation Decide whether work the LG remote control or not. y Able to set Normal, Use PWR Only, Block All y When ‘IR Operation’ is set to Block All, all normal remote keys don’t work. Use PWR Only (Block except power) makes block all remote keys except power key.
- Page 7 (4-2) Local Key Operation Decide to operate 'Local/Front Key' working behavior by setting ‘Local Key Operation’ as Normal, Use PWR Only, Block All. y When 'Local Key Operation' is set to Block All, all local keys don’t work. If value is Use PWR Only, it blocks all local keys except power key.
- Page 8 Programme Change (5-3) Decide to change channel or not by setting ‘Program Change' as ‘Yes’(Change Possible) or ‘No’(Change Impossible) when present source is TV. y When ‘Programme Change' is set to No (Change Impossible) » Program Key, Numeral Key, List Key, Q.View Key don't work and entering 'Channel Menu' in the Main Menu OSD is impossible.
- Page 9 (6) Power Management The Power Management feature will turn off the television receiver if no input control command is received from either the Local or IR Key within a selected hours. y Activity on either of these inputs shall restart the ‘Power Management’ timer and check key time interval again.
- Page 10 (8-3) A/V Setting If ‘A/V Setting’ is changed from ‘No’ to ‘Yes’, parameters that are set before entering ‘Installation Menu’ are applied whenever turn on power. y Following Parameters are applied to basic. » Picture section - PSM mode, Picture Data (Contrast, Brightness, Color, Sharpness, Tint) »...
- Page 11 (11) radio Video Blank Manage video blank channel(sound only). This feature affects on analog channel (ATV) only. (11-1) Start Pr. No. y Start channel number to video blank. y Available programme to set are 0~199(For Taiwan : TV 2~69, CATV 1~199). (11-2) No.
- Page 12 Public Display Settings / Lg Hotel Mode Setup (Value range Table) item Enable Disable initial Hotel Mode Operation Power On Status *STD Volume Start Volume Off, Minimum Volume ~ Maximum Volume Maximum Volume Minimum Volume ~ 100 Minimum Volume 0 ~ Maximum Volume...
-
Page 13: Tv Manager
Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Set ID Setup... - Page 14 Select the EPK option (software update) and then use the green and yellow buttons to download either SPI Boot or LG Boot Logo. If you checked the LG Boot Logo checkbox, then the Splash image, if selected, will be unchecked. Also, if you select the LG Boot Logo and proceed with the download, the existing Splash image will be deleted.
- Page 15 USB Cloning An Installer can quickly set up and clone multiple TV sets at a property. These cloned TVs will all have the same Master TV Setup: Public Display Mode Installation Menu settings, User A/V settings and the Channel Map. This newer procedure significantly decreases the installation time that would be necessary if the standard RS-232C method were used instead.
-
Page 16: Receive From Usb
Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Set ID Setup... -
Page 17: Send To Usb
Plug USB memory card into the USB port of the TV. Use the button to select the TV Manager option and then press the OK button. Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Set ID Setup... - Page 18 CABLE IN Use the button to select the TV Manager option and then press the OK button. RS-232C IN Installation Menu (V 3.0) (CONTROL & SERVICE) LG Hotel Mode Setup TV Manager Password Change Set ID Setup Configuration Setup Multi Timer...
-
Page 19: Diagnostics
It checks and records good and bad channel signals, and then provides the signal information to a USB storage device in XML file format. Installation Menu (V 3.0) TV Manager LG Hotel Mode Setup TV Manager Diagnostics Setup Password Change... - Page 20 (3) Saving signal status information of digital channels through SignalTrace in XML format y Go to Installation menu -> TV Manager -> Diagnostics -> Diagnostics Setup y Set the level value in Signal Tracer Set. (Disable, 10 to 90) TV Manager Diagnostics Setup Diagnostics Setup Signal Tracer Set...
-
Page 21: Password Change
Password Change y Image shown may differ from your TV. - To ensure more security, Password can be changed by installers’ own design. Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Password Change Password Change Set ID Setup... -
Page 22: Set Id Setup
Set ID Setup Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Set ID Setup Password Change Set ID Lock ◄ ► Set ID Setup Set ID setup Set ID Configuration Setup Previous Multi Timer Lock Mode External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84... -
Page 23: Configuration Setup
Configuration Setup y Image shown may differ from your TV. Installation Menu (V 3.0) Configuration Setup Number of RCU LG Hotel Mode Setup TV Manager Splash Offset Time ◄ ► Password Change USB Auto Playback Photo Set ID Setup 15Min Auto Off... - Page 24 For the audio signal, the priority order is the RGB -> AV -> Audio In component ports. (7) Screen Saver Cube y When ‘Screen Saver Cube’ is set to ‘No’, TV will do not display LG Screen Cube.
-
Page 25: Multi Timer
Multi Timer Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Multi Timer Set ID Setup Multi Timer ◄ ► Configuration Setup On Timer Multi Timer Multi Timer Off Timer Lock Mode External Speaker Previous HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84... -
Page 26: Lock Mode
Lock Mode Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change Lock Mode Set ID Setup Enable Data Service ◄ ► Configuration Setup Enable Multi Timer Previous Lock Mode Lock Mode External Speaker HCEC Setup S/W : 02.00.00.01 Micom : 0.00.84 Use the button to select the Lock Mode. -
Page 27: External Speaker
External Speaker (For LY340C, LY540S series) Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change External Speaker Set ID Setup Fixed ◄ ► Volume Control Configuration Setup 1 Watt Output Multi Timer Lock Mode Previous External Speaker... - Page 28 Speaker output SETUP (For LY340C, LY540S series) Connect the external speaker to the external speaker out jack on the TV. EXTERNAL SPEAKER OUT RIGHT LEFT NOTE y External speaker must be used three plug(SE : Single Ended, Stereo) as shown in the drawings and external speaker fully inserted with external Speaker Jack.
-
Page 29: Hcec Setup
HCEC Setup Installation Menu (V 3.0) LG Hotel Mode Setup TV Manager Password Change HCEC Setup Set ID Setup CEC Mode Default ◄ ► Configuration Setup IR Decoding Multi Timer Device ID Lock Mode StandBy External Speaker HTNG HotelMode HCEC Setup... - Page 30 (c) Stand By y Sets the sending and receiving scenario of the operation about [CEC Op standBy(0x0c) Command(Device Power)]. y The detailed scenario is described on the table below. Send receive Send Only Receive Only (2) HTNg HotelMode y If the following options are selected because of the HTNG command: *Power On Default, Start Volume, Maximum Volume, Minimum Volume, or Start Volume, then the value for the HTNG HotelMode changes automatically to Yes and, even if the HotelMode is set to No, the above options are still affected.
-
Page 31: Supersign Server Setup
SuperSign Server Setup (* Only for LY540S series) Installation Menu (V 3.0) Public Display Settings TV Manager SuperSign Server Setup Password Change Play Name Press OK Set ID Setup Server IP Setting Press OK Configuration Setup Server IP Status Multi Timer Not connected Lock Mode Previous...
