Summary of Contents for Magewell XI104XUSB
- Page 1 XI104XUSB HD+ Quad A/V USB3.0 Capture Box User’s Guide Rev 1.0 2012/9/10...
-
Page 2: Table Of Contents
SD Capture Device” Advanced Video Settings” Instruction ........... 13 e) Instruction of “Color Adjustment” ..................14 Settings for Video Format ......................14 Instruction of “Video Formats” ................... 15 2 / 18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all rights... - Page 3 Windows XP, Windows 2003 ....................... 15 Windows Vista, Windows 7, Windows 2008, Windows 2008 R2 ........16 Software Compatibility ........................17 Important Notice ..........................18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights 3 / 18...
-
Page 4: Preface
Thank you for choosing XI104XUSB easy-to-carry USB 3.0 HD/SD video capture box! XI104XUSB USB3.0 capture box has a small size and is easy to carry. It can simultaneously capture 1 HD video signal and quad SD video signals and dual analog stereo audio signal. -
Page 5: Connection Of Hd Input
6. Connection of HD Input a) DVI-D/DVI-I signals Figure 1 DVI connection b) HDMI signals Figure 2 HDMI connection Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights 5 / 18... -
Page 6: C) Vga Signals (Rgb-Hv)
VGA signals (RGB-HV) Figure 3 VGA connection d) Component signal (YPbPr) Figure 4 Component connection e) CVBS Figure 5 CVBS connection 6 / 18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all rights... -
Page 7: Connection Of Sd Input
"microphone amplifier" or " mixer "output is connected to the interface. 9. Video Capture Devices Instruction XI104XUSB is based on Microsoft DirectShow interface, and after the installation, 5 video Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights... - Page 8 Video 4 (XI104XUSB Adapter x) SD capture device The HD Video (XI104XUSB Adapter x) is corresponding to DVI-I input interface; Video 1 / 2 /3/4 (XI104XUSB Adapter x) is corresponding to four yellow video BNC interface in SD breakout cable. The breakout cable will connect to the “Quad A/V” interface on the capture box.
-
Page 9: B) Instruction Of "Properties
Meanwhile, please ensure the power during the upgrade or it will lead to failed upgrade and USB 3.0 capture box may not be able to work and have to be Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights 9 / 18... -
Page 10: C) Instructions For Advanced Settings Of Hd Capture Device
“Auto Select Input Interface” is selected, if HDMI and YPbPr input interfaces both have signal access, then HDMI input is preferred. You must select CVBS 10 / 18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all rights... -
Page 11: Signal Status
Skills of image clipping as follows: Set scale “fill output image” to confirm whether clipping adjustment is appropriate. Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights 11 / 18... -
Page 12: Image Output
De-interlacing: vertical blend, motion adaptive. Motion adaptive is better, but it takes up high CPU usage, also you can select “disabled”. Image Flip: Provides two kinds of flip methods, vertical and horizontal. 12 / 18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all rights... -
Page 13: D) Sd Capture Device" Advanced Video Settings" Instruction
The SD capture device “Advanced Video Settings” page is the same as the HD capture device, only that the “input interface” have the CVBS input. Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights 13 / 18... -
Page 14: E) Instruction Of "Color Adjustment
Driver is redefined "Filter Output Pin" interface and unified standard for SD and HD. Output resolution can be any size, even special resolution which is cut. a) The Display "Filter Output Pin" In Common Software 14 / 18 Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all rights... -
Page 15: B) Instruction Of "Video Formats
11. Audio Capture Device Instruction XI104XUSB is based on Microsoft DirectShow interface. After installation, the relevant audio device will be added in the operating system. Any software which is compatible with DirectSound, DirectShow can use the recording device for capturing sound. -
Page 16: B) Windows Vista, Windows 7, Windows 2008, Windows 2008 R2
Open Volume Control" window. Open "Options" menu, select "Properties" menu item. In "Mixer", select "Audio (XI104XUSB Adapter x)", click "OK" button. Corresponding volume control project will be displayed, this time you can operate volume and "mute" according to your requirement. -
Page 17: Software Compatibility
"Mute" according to your requirement. Figure 15，Windows Vista/7 Recording Device Properties Dialogue 12. Software Compatibility XI104XUSB is compatible with any software that is based on DirectShow interface and DirectSound interface, such as: Copyright © 2008-2011 Nanjing Magewell Electronics Co., Ltd. reserves all the rights... -
Page 18: Important Notice
If your USB 3.0 interface is “Intel USB 3.0 Extensible host controller”, when you use the capture box for some while, the XI104XUSB capture box may disappear and recover again, which may lead to the pause of capture. In order to solve the problem, you can run the application or you can download from the website to disable the USB 3.0 power...
