Summary of Contents for Bush POCKET
- Page 2 Safety Instructions: Do not use this radio near water. Clean with a dry cloth. Do not block any ventilation openings. Do not use near hot objects or appliances. Use accessories provided by manufacturer. Unload the battery when the unit has not been used for long time.
- Page 3 Specifications: Model: POCKET Radio: Digital DAB+ & FM Radio Dimension: 89x52x17mm Weight(Net): Approx. 75g (Including battery) FM Frequency: 87.5-108MHz with RDS DAB+ Frequency: Band III (174.0-239.0MHz) Headphones: 32 ohm, in-ear style Output Power: 0.3W(Speaker), 5mW...
- Page 4 Power Source: Micro USB (5V,0.6A) Charging Time: Approx. 2.5 Hours Usage Time: Approx. 6 Hours(Speaker), 8 Hours(headphone) Approvals: CE, RoHS, C-tick...
- Page 5 (12) (4)(3)(2)(1) (11) (10)(9) Power / DAB+ or FM Mode Switch Volume Up (3) Volume Down Preset (5) Telescopic Antenna Color LCD Display (7) Speaker Scan Scroll Wheel (9) Key Lock/Unlock (10) Micro USB Socket (11) Li Battery Compartment (12) Earphone Jack...
- Page 6 Charging the radio: The POCKET features a 3.7V, 1000mAh rechargeable Lithium battery. The POCKET is supplied with one ‘USB to micro-USB’ cable for power charging. Before first time to operate, please fully charge the battery. Open battery cover and insert the Lithium rechargeable battery.
- Page 7 2.5 hours to fully charge the battery. The charging icon will flash during charging and stop charging when the radio is fully charged. Speaker: The POCKET features a high-quality 8 Ω 0.3W speaker. Headphones: The POCKET features a pair of high-quality...
- Page 8 earpieces which also act as radio antenna. The 3.5mm jack is located on the top of the radio, it is provided for use with stereo headphones or earpieces. Important: Excessive volume from earpieces or headphone may cause damage to your ears. Operating your radio: Make sure the battery is charged.
- Page 9 The display will show the BUSH logo and then enter DAB mode (FM mode if you selected FM before turning off), “DAB” logo will be shown on the middle top of the display in DAB mode whereas “FM” logo will be shown in FM mode.
- Page 10 When you turn off the radio, mode will be memorized. Search and select channels: DAB+ mode Make sure the radio is in DAB+ mode. Press and hold “SCAN” Scroll Wheel button, the radio will scan and memorize all the channels automatically. (Cancel auto-scan by pressing the Scroll Wheel button) Select channel by scrolling up and down the “SCAN”...
- Page 11 memorized until another scan is performed. Service Information: DAB+ mode The Service Information display - Technical information on the current status of the station being broadcasted. While listening to DAB+, the display will show the followings if applicable 1. Program type 2.
- Page 12 7. Signal Strength Presets: DAB+ mode Make sure you are in DAB+ mode. When you are listening the DAB+ station you would like to preset, press and hold the “PRESET” button for 3 seconds, a list with heading “MEMORY” will show on the display, you will see vacant 1, vacant 2...etc in the list.
- Page 13 preset station will be overwritten.) To play the preset stations, press once the “PRESET” button and select the preset station(the name of channel will be displayed) by scrolling up and down the “SCAN” Scrolling Wheel button, then press the “SCAN” Scrolling Wheel button to confirm.
- Page 14 the radio will scan all the channels automatically. (Cancel auto-scan by pressing once the “SCAN” Scroll Wheel button) All the channels will be memorized. Select channel by scrolling up and down the “SCAN” Scrolling Wheel button. Press and hold “SCAN” Scroll Wheel button to exit.
- Page 15 Scroll up and hold the “SCAN” Scrolling Wheel button to scan the next channel at higher frequency, vice versa. Service Information: FM mode While listening to FM radio, the display will show the followings if applicable 1. Program type 2. Frequency 3.
- Page 16 Presets: FM mode Make sure you are in FM mode. When you are listening the FM station you would like to preset, press and hold the “PRESET” button for 3 seconds, a list with heading “MEMORY” will show on the display, you will see vacant 1, vacant 2...etc in the list.
- Page 17 To play the preset stations, press once the “PRESET” button and select the preset station(the name of channel will be displayed) by scrolling up and down the “SCAN” Scrolling Wheel button, then press the “SCAN” Scrolling Wheel button to confirm. Max.
- Page 18 Headphone or earpieces as antenna when you plug in 3.5mm jack. Sleep mode: Press and hold both “SCAN” Scroll Wheel button and “Vol-“ button for 2 secs to enter sleep mode, you will see ‘0 min.’ flashing in red color. Scroll up and down to select the duration from 5 min.
- Page 19 confirm, you will see the selected duration in red color on the top of the display. Press and hold both “SCAN” Scroll Wheel button and “Vol-“ button for 2 secs to cancel the sleep mode. Key Lock Function: Key lock switch is located at the right-hand side of the radio.
- Page 20 To switch off the key lock function, switch the key lock button to off position. The key lock function will be disabled. Select Background Color: Set the key lock switch to “LOCK>” position. Press and hold both “Vol-” button and “SCAN” Scroll Wheel button for 2 seconds, color background options will be shown on the screen.
- Page 21 Power Off and Maintenance: Please shut down the power when not in use. Please do not wipe it with rough materials. Remove the battery from the product if it is not going to be used for a long period of time. Please do not attempt to open product or change inner parameter.
