Summary of Contents for Wetelecom WMR-100
- Page 1 WeTelecom WMR-100 Mini Hotspot Quick Set Up Guide...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Getting Started ……………………………………………………………………….…….3 1. Minimum Requirement ………………………………………………….………..3 2. About WMR-100 Mini Hotspot …………………………..…………….………..3 3. LED State ……………………………………………………………….…...……..4 4. Insert RUIM card and Battery, and charge the battery ...………….…………..5 5. Wi-Fi Mode Connection …………………………………………….…………….6 6. USB Modem Mode Connection…………………………………….……………9 Important Notice …………………………………………………………………………..10... - Page 3 Copyright © 2011 WeTelecom Co., Ltd. 1. Trademarks and WeTelecom are trademarks of WeTelecom Co., Ltd. All other trademarks mentioned in this manual are the property of their respective holders. 2. All Rights Reserved No part of this manual may be reproduced or transmitted in any form or by any means without prior written consent of WeTelecom Co., Ltd.
-
Page 4: Getting Started
Windows® 2000 with Service Pack 4 Windows® Vista / 7 32bits/64bits Mac OS 10.4 or higher 2. About WMR-100 Mini Hotspot ① Power Button and Status Indicators Turn the device power on and off Indicate power , battery and CDMA communication activities.(See page 9 for Power Button LED description) ②... -
Page 5: Led State
③ External Antenna Connector Enables you use external antenna for better antenna performance. ④ MicroUSB Connector Connects with MicroUSB data cable, AC Travel Adaptor. ⑤ Factory Reset button Resets device to replace factory setting ⑥ RUIM Card Slot ... -
Page 6: Insert Ruim Card And Battery, And Charge The Battery
LED Orange Blink Fully Charged 4. Insert RUIM card and Battery, and charge the battery Before powering your WMR-100 Mini Hotspot on for the first time, you must insert the RUIM card supplied by service provider, insert the battery and charge the battery. -
Page 7: Wi-Fi Mode Connection
(The Power LED will flash solid orange while the device charging and flash blink orange once charging is complete.) 5. Wi-Fi Mode Connection You can connect the WMR-100 Mini Hotspot to your computer in two modes. Wi-Fi Mode USB Modem Mode How to Connect WMR-100 via Wi-Fi 1. - Page 8 4. If multiple wireless networks are found, highlight the one that indicated as “WMR- 100AP_XXXXXX” in its name. 5. Click Connect. 6. If this is your first time connecting to the WMR-100, continue with these steps. 7. At computer’s Web browser, type http://192.168.0.254 into the address window and press Enter or Return key.
- Page 9 - Choose “Authentication” and “Preferred Mode”. - Press “Next” button. To secure your personal information/files and virus attack, it is a must to Important set “Security Mode” with password. - Change “Network Name(SSID)” as you desire. - It is strongly recommended to check “Enable” box and to write “Pass Phrase”. “Pass Phrase”...
-
Page 10: Usb Modem Mode Connection
How to connect WMR-100 via USB port with USB Cable 1. Press the Power button on WMR-100. The Power button LED and Wi-Fi LED will flash. 2. Insert USB data cable into WMR-100 and USB port on your computer. The Power button LED illuminates and The Wi-Fi status LED does not illuminate. -
Page 11: Important Notice
Skylink or its partners will not be held responsible for damages of any kind resulting from the delays or errors in data transmitted or received with the WMR- 100 device, or failure of the WMR-100 device to transmit or receive such data. -
Page 12: Battery Use And Removal
Users are advised not to operate the WMR-100 while at a refueling point or service station. Users are reminded to observe restrictions on the use of radio equipment in fuel depots (fuel storage and distribution areas), chemical plants or where blasting operations are in progress. -
Page 13: Product Specification
Many airline regulations state that you must suspend wireless operations before boarding an airplane. Please ensure that the host device is turned off and the WMR-100 is removed from the USB port prior to boarding aircraft in order to comply with these regulations. The WMR-100 can transmit signals that could interfere with various onboard systems and controls. - Page 14 Table 3 : Wi-Fi Technology Technology 802.11 b/g/n Operating Frequency 2.4–2.4835 GHz Europe Nominal Output Power 802.11 b +17dBm 802.11 g/n +14dBm Receiver Sensitivity Level 802.11 b @ 11Mbps Below -76dBm 802.11 g @ 54Mbps Below -65dBm 802.11 n @ 135Mbps Below -61dBm Table 4 : Environmental Specifications Operating Temperature...
