Splendor 90
EC Declaration of Conformity
We declare that our products (lighting equipments) comply with the following
specification and bears CE mark in accordance with the provision of the
Electromagnetic Compatibility (EMC) Directive 89/336/EEC.
EN55103-1:199601-2; EN55103-2:1996;
EN61000-3-2:2000+A2:2005;
EN61000-3-3:1995+A1:2001+A2:2005.
&
Harmonized Standard
EN 60598-1: 2004
IEC 60598-1:2003+ corrigendum 2004
Part 1:General requirements and test
Following the provisions of the low voltage directive 73/23/EEC and 93/68/EEC
CM-90
User Guide
Innovation, Quality, Performance
Professional Entertainment Technology
15A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Solution Splendor 90 CM-90
- Page 1 Splendor 90 EC Declaration of Conformity We declare that our products (lighting equipments) comply with the following specification and bears CE mark in accordance with the provision of the Electromagnetic Compatibility (EMC) Directive 89/336/EEC. EN55103-1:199601-2; EN55103-2:1996; EN61000-3-2:2000+A2:2005; EN61000-3-3:1995+A1:2001+A2:2005. & Harmonized Standard EN 60598-1: 2004 IEC 60598-1:2003+ corrigendum 2004 Part 1:General requirements and test...
-
Page 2: Table Of Contents
of the unit or the previous one. 4. Try to use another DMX controller. 5. Check if the DMX cables run near or run alongside to high voltage cables that may cause damage or interference to DMX interface circuit. TABLE OF CONTENTS C. -
Page 3: Safety Instruction
1. If you using a controller with 5 pins DMX output, you need to use a 5 to 3 pin 1. Safety Instruction adapter-cable. 2. At last unit, the DMX cable has to be terminated with a terminator. Solder a Please read carefully the instruction, which includes important 120 ohm 1/4W resistor between pin 2(DMX-) and pin 3(DMX+) into a 3-pin information about the installation, usage and maintenance. -
Page 4: Technical Specification
Caution There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact your nearest dealer. Installation The unit should be mounted via its metal hole on the bracket. Always ensure that the unit is firmly fixed to avoid vibration and slipping while operating. -
Page 5: Change Beam Angle
5.3 DMX Controller 3. Change Beam Angle If you want to change the beam angle of the fixture, you can change lens of the Use universal DMX controller to control the units, you have to set DMX address from 1 to 512 channel so that the units can receive DMX signal. -
Page 6: Main Function
Button 5. How To Control The Unit You can operate the unit in three ways: MENU To select the programming functions 1. By master/slave built-in preprogram function DOWN To go backward in the selected functions 2. By easy controller To go forward in the selected functions 3. - Page 7 main functions without any change please press the MENU button. White Balance Press the MENU button up to when the White Balance is showing on the display. Press ENTER button and the Red will blink, press UP and Down button to adjust the value, press ENTER button to store and Green will blink on the display, press UP and Down button to adjust the value, press ENTER button to store and Blue will blink on the display, press UP and Down button to adjust the value, and press ENTER button to store.
- Page 8 DMX Address ENTER button and the display will blink. Use DOWN and UP button to select the yes (yes Press the MENU button up to when the DMX Address is showing on the display. Press blackout) or no (no blackout) mode. Once selected, press the ENTER button to store. Back ENTER button and the display will blink.
