Thank you for choosing the WG300 3G wireless router products! This user manual will be Win7
operating system, for example, to guide you through how to use a router to share Internet access.
Checking the Package Contents
1、WG300 802.11n/2.4GHz 3GWireless Router
2、Warranty card
3、Quick Installation Guide
Hardware connection
A. WG300 access power outlet When the power will see the panel power indicator light.
B. Will connect the DSL / Cable Modem or residential broadband network cable to the WG300 Ethernet port or the
3G network card to connect to the WG300 USB port.
C. Wireless connection to the router.
Hardware Interface Description
1 / 6
Product Type：WG300
3G Wireless Router
Advertisement
Table of Contents
Summary of Contents for Cotell WG300
-
Page 1: Checking The Package Contents
A. WG300 access power outlet When the power will see the panel power indicator light. B. Will connect the DSL / Cable Modem or residential broadband network cable to the WG300 Ethernet port or the 3G network card to connect to the WG300 USB port. - Page 2 Default mode is AP mode, if you want to access web page, Pls set up your PC by fixed IP(10.10.10.x) If you Already Set WG300 in Routing Mode, pls Set the PC byObtain an IP address automatically. 1． Win 7 operating system, for example 1.1 Click“Start→Control Panel→Network and Internet→Network Connections→Wireless Network...
- Page 3 Connect to a wireless network NIC installation is successful, the lower right corner of the desktop will appear icon , click the icon Select in the pop-up list of network to be connected to the wireless network, click on "Connect" button When the screen displays "Connected", the computer has successfully joined the wireless netw Login the router management interface Open the browser, the URL in the address bar, type http:// 10.10.10.254 and press Enter.
-
Page 4: Routing Mode
Set up the router Router operation mode including AP mode and routing mode. AP mode: AP mode Plug and Play (cable network), without any configuration. Of course, we recommend that you refer to the wireless network settings to create your secure online environment. Routing mode: 1．... - Page 5 If the network service providers use dynamic IP address Internet connection, select the "dynamic IP" If the network service provider to use the 3G network, connection type, select "3G mode". Insert the USB 3G card can automatically dial- up, no configuration. (Support of the mainstream 3G network card brand) 2．Wireless network settings The wireless network default settings, the wireless network name (SSID): 3Grouter + MAC ,...
-
Page 6: Faq Frequently Asked Questions
Appendix FAQ Frequently Asked Questions FAQ1：Charged in the case of the router, reset the router, using a stylus to hold down the network port next to the reset button for 5 seconds, then release the can. FAQ2：IE browser address bar enter 10.10.10.254 not eject the user name and password dialog box.
