Page 1: User Manual
USER MANUAL HDMI CONVERTER HDMI TO VGA+SPDIF/AUDIO （MODEL NO：ASK-C006） Enjoy the vivid world! REMARK Manufacturer does not make any commitment to update the information contained herein. - Page 2 Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The products are designed to make your A/V device use more convenient, comfortable, productive and cost-efficient.
-
Page 3: Package Contents
SPECIFICATIONS: ASK-C006 HDMI STANDARD…………………………………………………………………………………HDMI 1.4b HDCP STANDARD…………………………………………………………………………………HDCP 1.4 HDMI resolution………………………………………………………………… 1080P/720p/480P @60Hz Support up to VGA……………………………………………………………………… 1920×1080@60Hz Support audio format…………………………………………………………DTS/Dolby-AC3/PCM/LPCM Max bandwidth……………………………………………………………………………………… 165MHz Input/Output TMDS signal…………………………………………………………………0.5-1.5Vp-p(TTL) Input/Output DDC signal………………………………………………………………………… 5Vp-p(TTL) Input cable distance………………………………………………… ≤15m AWG26 HDMI standard cable Output cable distance……………………………………………………………≤15m VGA standard cable Max working current……………………………………………………………………………………360mA... - Page 4 FEATURES OF THE INTERFACE: ▲Front Panel View ▲Back Panel View DC IN：5V DC power supply jack（When the converter box connected to a non-standard HDMI interface or HMDI cable is required to access the 5V/500mA external power supply） POWER：Power on status light HDMI IN：HDMI input port（Connect to HDMI signal source device, DVD player,PS3,STB,D-VHS,e.g.）...
- Page 5 ▲Connection View Operation declaration： 1. Connect one cable from display (TV, monitor or projector) into the converter output port. 2. Connect one optical fiber or 3.5mm audio cable from amplifier into the converter SPIDF/AUDIO output port. 3. Connect one cable from HDMI source devices into the converter input port. 4.
- Page 6 1. To try again to connect the cable to be free from the Obscure Picture unsuccessful connection 2. HDMI cable quality 1. Check the system connection and cable quality No sound 2. Check the amplifier volume settings and mute 3. Check the signal source/amplifier audio options 1.
