Summary of Contents for BlueChip iT7x2
- Page 1 USER MANUAL By IAN TAYLOR...
- Page 3 ® Premier League Bluetooth Wireless Audio Product By Ian Taylor Not content with kicking off his boots and taking it easy, former English Premier League footballer, Ian Taylor, has been working alongside Bluechipworld to launch this range of wireless audio accessories. Ian played for Aston Villa, Derby County, Sheffield Wednesday and Port Vale with a total of 478 appearances and 79 career goals.
-
Page 4: Product Introduction
Product Introduction The iT7x2 combines style with new wireless technology. The iT7x2 supports the latest standard of Bluetooth v4.0 and is compatible with all Bluetooth-enabled mobile phones, PCs and other Bluetooth enabled device’s. (Please check your devices user manual for more information). - Page 5 Functions Left Right Multi-function button NFC logo & & LED light contact point Skip back button Volume + key Volume - key Skip forward button Micro USB charging port Microphone 3.5mm jack port...
-
Page 6: Basic Specifications
Basic Specifications Primary features Product type Bluetooth stereo headset Model No. iT7x2 Pairing name iT7x2 Bluetooth version Bluetooth 4.0 +Class 2 Distance 20 metres in open space Dimensions L 200mm x W 170mm Weight (Headphones only) 172g ¢40- Speaker specifications Battery specifications 3.7V/562438/400mAH... - Page 7 Hardware specification definition Solution CSR 8640 Transmit power Class 2, Max4 dBm Reception sensitivity -88dbm(typical) Working Band 2.4G ISM Band, 2.402- 2.480GHz Modulation system GFSK π/4 DQPSK 8DPSK Buttons Multi-function button, VOL+, VOL-, Skip forward, Skip back LED lights Blue LED and red LED Software memory 256K EPROM Antenna...
-
Page 8: Headphone Functions
Software specification definition HFP Profile HSP Profile A2DP Profile AVRCP Profile 4-7-2 Audio decoder SBC, AAC Headphone Functions: Switching on Whilst the headphones are switched off, press and hold the multi-function button for 3 seconds until the blue LED flashes and there is a voice prompt “Power on”. Switching off Whilst the headphones are switched on, press and hold the multi-function button for 3 seconds until the red LED light... - Page 9 Pairing Make sure the headphones are switched off. Press and hold the multi-function button for about 7 seconds until the red and blue LED lights flash alternately and there is a voice prompt. Turn on your phones Bluetooth function. There will be a second voice prompt when pairing is successful.
- Page 10 Voice dialling In standby mode, whilst the phone is set up for hands-free operation, double click the multi-function button to start voice dialling, there will be an audio prompt. Say the name of the contact to make the call. (Your phone needs to support this function and corresponding voice clips need to have been recorded.
- Page 11 VOL + The VOL + button lets you increase the volume of calls, dialling tone and music. Press once to increase the volume level by one. When you reach maximum volume you will hear an indication tone. VOL - The VOL - button lets you decrease the volume of calls, dialling tone and music.
- Page 12 Voice Transfer During a call, hold the multi-function button for 2 seconds until you hear a audio prompt and the call will then be transferred from headphones your phone. transfer a call from your phone to the headphones, press the multi-function button for 2 seconds until you hear a audio prompt and the call will be transferred from your phone to the headphones.
- Page 13 Bluetooth pairing mode and search for Bluetooth devices, select the desired Bluetooth device, enter the PIN password (0000) if needed and they will connect wirelessly. iT7x2 headphones pairing guide: 1. Ensure the headphones are switched off. (Turn off by holding the multi-function button for 3 seconds).
- Page 14 Bluetooth function on and search for Bluetooth devices. 4. The phone will find the headphones (shown as iT7x2 in the menu), select the headphones and confirm. 5. If requested enter the PIN No: 0000 and confirm.
- Page 15 devices (rendering the current manual Bluetooth pairing process obsolete). 1. Refer to your phone’s user manual to confirm your phone supports this function and guidance on how to turn your phone’s NFC function on. 2. Ensure the headphones are turned on. (Turn on by holding the multi-function button for 3 seconds) 3.
- Page 16 The headphones can also be used wired with the supplied 3.5mm line in cable. Troubleshooting If you are unable to connect the headphones to the phone, please do the following: • Make sure the headphones are fully charged, turned on and paired with the phone.
- Page 17 For all technical issues please contact Bluechipworld on 01543 495 243...
- Page 20 www.bluechipworld.biz...
