- Page 1 AC-DC Portable Power Supply OUTDO Electronics Co., Ltd. User’ s Manual Manufacturer: OUTDO Electronics Co., Ltd. Place of origin: Xiamen, China Tel.: 0086-0592-5790791 URL: www.oemdn.com...
- Page 2 Table of Content Introduction Product Structure Charging Operation and Charging Time Operating Principle Electrical Parameters Certifications Notes...
- Page 3 INTRODUCTION AC-DC Portable Power Supply is the lightest, slimmest, with largest capacity under the same size, the most convenient AC-DC back-up power supply. Adopt the unique intelligent CPU management and the most advanced powerful lithium ion battery technology, supplying varied output such as AC/DC 5V, 12V to meet the needs of different devices. It’s the best choice for travelling, outdoor emergency, mining, expedition, army medical, scientific research, media, earthquake relief, first-aid etc.
- Page 4 PRODUCT STRUCTURE BACK FRONT Indicator for DC Output DC 5V Output Port LCD Screen Input Port for Power Supply and Solar Panel DC 12V Output Port Radiator for AC Output Power Switch LED Indicator for Charging AC Output Port DC Output Button red--charging AC Output Button green-- power full...
- Page 5 LED lights on. 3. Press the AC output button, if the AC output is in need, make sure the output is working and use the product after the LED lights on. 4. The charge time for devices: PC-2000 PC-5000 PC-8000 To-be-charged Devices...
- Page 6 AC PURE SINE WAVE OUTPUT OPERATING PRINCIPLE LCD display panel, button of Master 220Ｖ Control Panel (MCP) Specialized DC 5V 12V for lithium ion battery, Main-control AC outlet main-board 0Ｖ －220Ｖ High capacity lithium ion battery...
- Page 7 MODEL MODEL Ｐ Ｃ 2000 Ｐ Ｃ 5000 12V 26Ah, Samsung cells, Power: 300W. 12V 48Ah, Samsung cells, Power: 550W. Capacity Capacity 25.2V ~4A 25.2V~4A Input Input 5Ｖ～3A 220V---50HZ 550W 5Ｖ～3A 220V---50HZ 300W (USB) (USB) Output Output 12Ｖ～5A 110V---60HZ 550W 12Ｖ～5A 110V---60HZ 300W 600W...
- Page 8 MODEL Ｐ Ｃ 8000 Capacity 12V 62Ah, Samsung cells, Power: 800W. Input 25.2V~4A 5Ｖ～3A 220V---50HZ 800W (USB) Output 12Ｖ～5A 110V---60HZ 800W Max load power 1000W Over-charge for cells 25.2±0.025V Over-discharge for cells 2.75±0.025V 2.75±0.025V Over-current Temperature protection ＜75℃ ＜75℃ Voltage protection ＜18.6V、＞28V ＜18.6V、＞28V Net weight...
- Page 9 We are not responsible for extended warranty, or without invoice of receipt. RoHS We are not responsible for any unauthorized disassembling or repairing by OUTDO Electronics Company Limited. All of the products have been tested and verified. If it occurs to be over-hot, out of shape, breakage or other abnormal cases, please stop using it and contact the local agent or us immediately.
