Installation Instructions
Please note:
This product should only be installed by a qualified
electrician or competent heating installer, and should be
in accordance with the current edition of the IEEE wiring
regulations.
Product specification
Specification
Power supply
Switching action
Switch rating
Timing Accuracy
Power Reserve
Enclosure Rating
Max. Ambient Temperature
Dimensions, mm (W, H, D)
Design standard
Control Pollution Situation
Rated Impulse Voltage
Ball Pressure Test
230 Vac ± 15%, 50 Hz
1 x SPST, Type 1B
264 Vac, 50/60Hz, 3(1)A
±1 min./month
Minimum 14 days
IP30
45°C
102 x 136 x 47
EN 60730-2-7
Degree 2
2.5kV
75°C
3
