aquilar Fuzzistor User Manual

Silicone transistor distortion

FUZZISTOR

The Fuzzistor™ provides classic silicone transistor distortion with

complete control over the BLEND of the clean and Fuzz sound, amount

of FUZZ from subtle to crushing, LEVEL for gain matching, and TILT EQ

that changes the harmonic structure of the Fuzz from booming to

gnarly.

Features:

• Silicone transistor distortion

• Intuitive four knob control layout

• Gig-saver bypass (signal passes even if your battery dies)

• Powered by a nine-volt battery or optional universal power

supply

• Heavy duty steel construction

• Three-year limited warranty

Table of Contents

Need help?

Do you have a question about the Fuzzistor and is the answer not in the manual?

Page 1 FUZZISTOR The Fuzzistor™ provides classic silicone transistor distortion with complete control over the BLEND of the clean and Fuzz sound, amount of FUZZ from subtle to crushing, LEVEL for gain matching, and TILT EQ that changes the harmonic structure of the Fuzz from booming to gnarly.
Page 2 Owner’s Manual Manual Version 1.1 I. Functions A. Top Panel: BLEND: Controls the mix ratio between clean and distorted signals. When the knob is set to the 12:00 position, the two signals are mixed at a 50:50 ratio. When the BLEND knob is turned counterclockwise the mix ratio favors the clean signal.
Page 3 C. Specifications: Current consumption:………………………..4.5mA Input impedance: ..........1MΩ (Effect On) Output impedance: .........1 KΩ External DC Power: ………………………..9-10VDC, center terminal negative II. Sample Settings Please visit our website, www.aguilaramp.com, for sample settings. III. How to change the battery This operation can be done quickly and easily with a standard #2 Philips screw driver! The battery is easily accessible by loosening the screw on the bottom of the unit.
Page 4 IV. Warranty Information The Fuzzistor is covered under limited warranty against defects in materials and workmanship for a period of 3 years. This warranty is non-transferable. The warranty period starts from the date of purchase from an authorized Aguilar dealer. Please retain your sales receipt as it is necessary to obtain warranty service.
