PROFESSIONAL WEATHER STATION
Model no.: VSPWS1070
1. Introduction.........................................................................2
2. Inventory of contents............................................................2
Feature of the base station................................................. ....2
Feature of wind sensor................................................ ..........2
Feature of rain sensor................................................ ...........2
3. Set up guide........................................................................3
3.1 Battery install......................................................... .........3
3.2 Mounting............................................................ ............4
4. LCD overview.......................................................................5
4.1 LCD overview..................................................................5
4.2 Weather forecasting..........................................................6
4.3 Weather forecast tendency indicator......................................7
4.4 Storm warning indicator....................................
5.1 Quick display mode............................................................7
5.2 Setting mode.....................................................................8
5.3 History mode.....................................................................8
5.4 Alarm mode......................................................................8
5.5 Min/Max mode..................................................................10
6. Problems and interference with operation...............................10
7. Specification............................................................. ...........11
This Operation Manual is part of this product and should be kept in a safe place for future
reference. It contains important notes on setup and operation.
INSTRUCTION MANUAL
1
www.invisua.co.uk
Page
....................7
Advertisement
Table of Contents
Summary of Contents for Invisua VSPWS1070
-
Page 1: Table Of Contents
PROFESSIONAL WEATHER STATION INSTRUCTION MANUAL Model no.: VSPWS1070 Page 1. Introduction……………………………………………………………….2 2. Inventory of contents…………………………………………..……….2 Feature of the base station………………………….……………… .…2 Feature of wind sensor………………………………………… ….……2 Feature of rain sensor………………………………………… ….….…2 3. Set up guide………………………………………………………………3 3.1 Battery install………………………………………………… ……...3 3.2 Mounting……………………………………………………... -
Page 2: Introduction
1. Introduction Thank you for purchasing this Professional Weather Center Designed for everyday use, the weather station will prove to be an asset of great value for your personal use in the home or office. Please read this instruction manual thoroughly to fully understand the correct operation of your weather station and benefit from its unique features. -
Page 3: Set Up Guide
the data to the base station. Feature of rain sensor The rain sensor measures the rainfall and sends the data to thermo-hygro sensor, which in turn transmits the data to the base station. Operating power is taken from the thermo-hygro sensor by a cable connection 3. -
Page 4: Mounting
temperature reading in the indoor station, make sure the units are within range of each other or repeat the battery installation procedure. If a key is pressed before the weather station receives the temperature signal, you will need to follow the battery installation procedure again. Please wait minimum 10seconds before re-insert the battery again to make a proper reset for both transmitter and receiver. -
Page 5: Lcd Overview
c.)Mounting the thermo-hygro sensor same as rain sensor d.) Fix the whole set to a pole with the two adjustable hoops. Once the wind sensor and rain sensor are fixed onto the mast, connect the cable to the corresponding thermo-hygro sensor socket. 4. -
Page 6: Weather Forecasting
1. Time 17. Weather tendency indicator 2. Alarm on indicator 18. Pressure unit (relative or absolute) 3. Day of week/ time zone / history 19. Pressure with 24 hour history graph 4. Date 20. Pressure low alarm and high alarm 5. -
Page 7: Weather Forecast Tendency Indicator
The four weather icons Sunny, partly Cloudy, Cloudy and Rainy represent the weather forecasting. For every sudden or significant change in air pressure, the weather icons will update accordingly to represent the change in weather. 4.3 Weather forecast tendency indicator The weather tendency indicators arrow is located between the weather icons to show the air pressure tendency and provide a forecast of the weather to be expected by the decreasing or increasing air pressure. -
Page 8: Setting Mode
3. Wind speed / Gust speed (press the + key or MIN/MAX key shifts the display between the wind speed and gust speed) 4. 1 hour/ 24 hour / week/ month / total rainfall quantity (press the + key or MIN/MAX key shifts the display between the selectable rainfall quantities), while display the rainfall total quantity, pressing the SET key for two seconds will reset the rainfall total value to zero and the time recording to current time. - Page 9 4. Outdoor humidity high alarm 5. Outdoor temperature high alarm 6. Wind chill high alarm 7. Dew point high alarm 8. Pressure high alarm 9. Wind speed high alarm 10. Gust speed high alarm 11. 1Hour rain high alarm 12. 24 hour rain high alarm In the Low Alarm Mode press the SET key to select the following alarm modes: 1.
-
Page 10: Min/Max Mode
5.5 Min/Max Mode While in Normal Mode, press the MIN/MAX key to enter the maximum mode, Press MIN/MAX key again to enter the minimum mode Press MIN/MAX key again to return the Normal Mode In the maximum reading Mode, press the + key to display the following maximum values together with the time and date stamp when these values were recorded, if press SET key in the following individual maximum value will be reset to current reading together with the current time and date. -
Page 11: Specification
This handbook may contain mistakes and printing errors. The information in this handbook is regularly checked and corrections made in the next issue. We accept no liability for technical mistakes or printing errors, or their consequences. All trademarks and patents are acknowledged. www.invisua.co.uk - 11 -...
