  • Page 1 W E B E D I T I O N O W N E R ' S M A N U A L...
  • Page 3 Volvo is one of the safest cars in mation contained in this owner's manual. the world. Your Volvo has also been designed to satisfy all current safety and environmental requirements.

  • Page 4: Table Of Contents

    Seatbelt tensioner........30 Two-stage booster seat* - lowering..52 the Internet..........20 Safety - warning symbol......31 Child seat - ISOFIX........53 Volvo ID............. 21 Airbag system........... 32 ISOFIX - size classes........ 53 Environmental philosophy......22 Driver airbag..........33 ISOFIX - types of child seat...... 55 The owner's manual and the environ- Passenger airbag........
  • Page 5 Approach lighting........101 Trip computer - trip statistics*....125 Symbols in the display......76 Headlamps - adjusting headlamp pat- tern............101 Volvo Sensus..........79 Wipers and washers....... 101 Key positions..........80 Power windows........104 Key positions - functions at different lev- els..............
  • Page 6 Table of contents 04 Climate control 05 Loading and storage General information on climate control... 127 Engine block heater and passenger com- Storage spaces........150 partment heater*........141 Actual temperature......... 128 Tunnel console........152 Engine block heater and passenger com- Sensors - climate control......
  • Page 7 Table of contents 06 Locks and alarm Remote control key......... 162 Keyless drive* - interference to remote Type approval - remote control key sys- control key function........ 175 tem............187 Remote control key - losing ....162 Keyless drive* - locking......175 Remote control key - personalisation*..
  • Page 8 Table of contents 07 Driver support Active chassis - Four C*......190 Adaptive cruise control - ACC*....204 City Safety™........... 222 Adjustable steering force*....... 190 Adaptive cruise control* - function..205 City Safety™ - function......222 Electronic stability control (ESC) - gen- Adaptive cruise control* - overview..
  • Page 9 Table of contents 08 Starting and driving Lane Departure Warning (LDW) - func- Park Assist Pilot (PAP)* - operation..260 Alcohol lock*........... 270 tion............243 Park Assist Pilot (PAP)* - limitations..261 Alcohol lock* - functions and operation.. 270 Lane Departure Warning (LDW) - opera- Park Assist Pilot (PAP)* - symbols and Alcohol lock* - storage......
  • Page 10 Table of contents 09 Wheels and tyres Start/Stop*..........291 Fuel filler flap - manual opening....312 Tyres - maintenance....... 332 Start/Stop* - function and operation..292 Filling up with fuel........312 Tyres - direction of rotation....333 Start/Stop* - the engine does not stop... 293 Fuel - handling........
  • Page 11 Table of contents 10 Maintenance and service Tyre pressure monitoring (TPMS)* - rec- Volvo service programme....... 366 Lamp replacement - location of rear ommendations........349 lamps............385 Book service and repair*......366 Tyre pressure monitoring (TPMS)* - recti- Lamp replacement - number plate light- Inspection and service of the system for fying low tyre pressure......
  • Page 12 Table of contents 11 Specifications 12 Alphabetical Index Polishing and waxing......411 Type designations........417 Alphabetical Index........442 Water and dirt-repellent coating..... 412 Dimensions..........420 Rustproofing........... 413 Weights........... 421 Cleaning the interior........ 413 Towing capacity and towball load..422 Paint damage.......... 414 Engine specifications......
  • Page 13 Table of contents...
  • Page 14 I N T R O D U C T I O N...

  • Page 15: 01 Introduction

    For cars with owner information in the screen, with Volvo's recommendations in the advice on how best to handle the car in differ- the printed owner's manual is a supplement owner's information.
  • Page 16 Media Sending location In the event of uncertainty over what is stand- Decals ard or an option/accessory, contact a Volvo The car contains different types of decal dealer. which are designed to convey important information in a simple and clear manner. The...
  • Page 17 01 Introduction Risk of property damage Information When there is a series of illustrations for step-by-step instructions each step is numbered in the same way as the corres- ponding illustration. Lists of letters appear adjacent to the ser- ies of illustrations where the order of the instructions is not significant.

  • Page 18: Digital Owner's Manual In The Car

    01 Introduction • Digital owner's manual in the car Related information Search - Search function for finding an article. Related information refers to other articles The owner's manual can be read on the • containing closely-associated information. Categories - All articles sorted into cate- screen in the car .
  • Page 19 01 Introduction Search Enter with the numerical keyboard 3. To change the input mode to numbers or special characters, or to perform a search, turn TUNE to one of the options (see explanation in the following table) in the list for changing the input mode (2), press OK/MENU.

  • Page 20: Recording Data

    OK/MENU to open an article. ing and maintenance and so that Volvo can Press EXIT to go back to the previous view. Favourite - adds/removes an article as a fulfil legal requirements and other regulations.

  • Page 21: Accessories And Extra Equipment

    This information may be stored by tively affect the car's electronic system. Volvo as long as it can help to further develop Certain accessories only function when asso- and further enhance safety and quality and as...

  • Page 22: Support And Information About The Car On The Internet

    My Volvo Web which is a the Internet via a mobile phone. personal Web page for you and your car. Create a personal Volvo ID, log in to My Volvo Web and get an overview of service, agree- Applies to certain markets.

  • Page 23: Volvo Id

    (e.g. My Volvo) Create a Volvo ID To create a Volvo ID you need to enter a per- sonal e-mail address. Then follow the instruc- tions in the e-mail message that is automati- cally sent to the specified address in order to complete the registration.

  • Page 24: Environmental Philosophy

    Clean air in the passenger Environmental care is one of Volvo Cars' core fuel consumption generally results in lower values, which influence all operations. We emission of the greenhouse gas, carbon diox-...

  • Page 25: The Owner's Manual And The Environment

    Warranty Booklet's recommended inter- Interior facility. vals. The interior of a Volvo is designed to be plea- • If the car is equipped with an engine Related information sant and comfortable, even for people with block heater*, use it before starting from •...

  • Page 26: Laminated Glass

    01 Introduction The owner's manual and the Laminated glass Bi-Fuel* - introduction to vehicle gas environment Cars with Bi-Fuel engines can be driven on The glass is reinforced which pro- The paper pulp in a printed owner's manual either vehicle gas or petrol. Vehicle gas can vides better protection against ®...
  • Page 27 In the event of an accident, the vehicle • Switch for gas operation* (p. 317) must be inspected and approved by an authorised Volvo workshop before it may • Inspection and service of the system for be used again. Always notify the emer- vehicle gas* (p.
  • Page 28 S A F E T Y...

  • Page 29: 02 Safety

    Never modify or repair the seatbelts your- The hip strap must be positioned low down (not self. Volvo recommends that you contact over the abdomen). an authorised Volvo workshop. It is important that the seatbelt lies against...

  • Page 30: Seatbelt - Putting On

    02 Safety Seatbelt - putting on Remember The seatbelt locks and cannot be withdrawn: Put on the seatbelt (p. 27) before driving starts. • if it is pulled out too quickly • during braking and acceleration Pull the belt out slowly and secure it by pressing its locking tab into the seatbelt •...

  • Page 31: Seatbelt - Loosening

    02 Safety Seatbelt - loosening Seatbelt - pregnancy The aim should be to position the seat with as large a distance as possible between abdo- Loosen the seatbelt (p. 27) when the car is Seatbelt (p. 27) must always be worn during men and steering wheel.

  • Page 32: Seatbelt Reminder

    02 Safety Seatbelt reminder Seatbelt tensioner matically after driving for approximately 30 seconds or after pressing the indicator Unbelted occupants will be reminded to fas- All the seatbelts (p. 27) are equipped with belt stalk OK button (p. 111). ten their (p. 28) seatbelt by means of an audio tensioners.

  • Page 33: Safety - Warning Symbol

    The symbol indicates a fault in the seatbelt ten- sioner system, SIPS, the IC system or some other fault in the system. Volvo rec- ommends that you contact an authorised Volvo workshop immediately. If the warning symbol malfunctions, the warn-...

  • Page 34: Airbag System

    The entire process, including inflation and deflation of the airbag, occurs within tenths of a second. WARNING Volvo recommends that you contact an authorised Volvo workshop for repair. Defective work in the airbag system could cause malfunction and result in serious personal injury.

  • Page 35: Driver Airbag

    02 Safety Driver airbag Passenger airbag To supplement the protection afforded by the To supplement the protection afforded by the seatbelt (p. 27) the car is equipped on the seatbelt (p. 27) on the passenger side, the car driver's side with an airbag (p. 32). is equipped with an airbag (p.

  • Page 36: Passenger Airbag - Activating/ Deactivating

    02 Safety Passenger airbag - activating/ WARNING deactivating* Do not put objects in front of or above the Front passenger airbag (p. 33) can be deacti- dashboard where the passenger airbag is vated if the car is equipped with a switch, located.
  • Page 37 (p. 31) for the airbag is shown in the com- Visit a workshop as soon as possible. bined instrument panel for Volvo recommends that you contact an approx. 6 seconds. authorised Volvo workshop. Following which, the indicator in the roof console is illuminated showing the correct status for the front passenger seat airbag.

  • Page 38: Side Airbag (Sips)

    02 Safety Side airbag (SIPS) WARNING In a side impact collision a large proportion of Failure to follow the advice given above the collision force is transferred by the SIPS can endanger the lives of passengers in (Side Impact Protection System) to beams, the car.

  • Page 39: Side Airbag (Sips) - Child Seat/Booster Cushion

    The protection provided by the car to children driver and passengers from striking their only carried out by an authorised Volvo heads on the inside of the car during a colli- seated in a child seat or on a booster cushion workshop.

  • Page 40: General Information On Whips (Whiplash Protection)

    This could compromise the intended protection. Volvo recommends that you only ever use Volvo genuine parts that are approved for placement in these areas. WARNING Do not load the car higher than 50 mm under the top edge of the windows in the doors.

  • Page 41: Whips - Child Seats

    (p. 43) restraint. Never modify or repair the seat or WHIPS system yourself. Volvo recommends that Function you contact an authorised Volvo work- shop. Related information • WHIPS - child seats (p. 39) •...

  • Page 42: When The Systems Deploy

    02 Safety When the systems deploy WARNING WARNING In the event of a collision Volvo's different Do not squeeze rigid objects between the If a seat has been subjected to extreme personal safety systems work together in rear seat cushion and the front seat's forces, such as due to a rear-end collision, order to minimise injury.

  • Page 43: General Information On Safety Mode

    Recovering the car. Volvo recommends that you have it con- Whiplash protec- In a rear-end collision veyed to an authorised Volvo workshop.

  • Page 44: Safety Mode - Attempting To Start The Car

    Volvo recommends that you ing. engage an authorised Volvo workshop to check and restore the car to normal status Safety mode See manual after has been displayed.

  • Page 45: Safety Mode - Moving The Car

    Regulations regarding the placement of children in cars vary from country to coun- try. Check what does apply. Volvo has child safety equipment (child seats, booster cushions & attachment devices) which is designed for your particular car. Using Volvo's child safety equipment pro- vides you with optimum conditions for your child to travel safely in the car.
  • Page 46 02 Safety NOTE In the event of questions when fitting child safety products, contact the manufacturer for clearer instructions. Child safety locks The rear doors and rear door windows* can be blocked manually (p. 183) or electronically (p. 184)* from opening from the inside. Related information •...

  • Page 47: Child Seats

    02 Safety Child seats NOTE Children should sit comfortably and safely. When using child safety products it is Make sure that the child seat is being used important to read the installation instruc- correctly. tions included. WARNING Do not secure the straps of the child seat to the seat's horizontal adjustment bar, springs or the rails and beams under the seat.
  • Page 48 Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat Group 0 Volvo infant seat (Volvo Infant Seat) - rear-facing child seat, secured with the ISOFIX fixture system. max 10 kg Type approval: E1 04301146 Group 0+ max 13 kg...
  • Page 49 Type approval: E5 04191 Type approval: E5 04191 Group 2/3 Volvo booster seat with backrest (Volvo Volvo booster seat with backrest (Volvo Booster Volvo booster seat with back- Booster Seat with backrest). Seat with backrest). rest (Volvo Booster Seat with 15-36 kg backrest).
  • Page 50 02 Safety Weight Front seat (with deactivated airbag) Outer rear seat Centre rear seat Group 2/3 Integrated booster cushion (Integrated Booster Cushion) - available as a factory fitted option. 15-36 kg Type approval: E5 04189 L: Suitable for specific child seats. These child seats may be intended for use in a special car model, limited or semi-universal categories. U: Suitable for universally approved child seats in this weight class.

  • Page 51: Child Seats - Location

    02 Safety Child seats - location WARNING Always fit child seats/booster cushions (p. 45) Never place a child in a child seat or on a in the rear seat if the passenger airbag is acti- booster cushion in the front seat if the air- vated (p.

  • Page 52: Child Seat - Two-Stage Booster Seat

    Volvo recommends that repair or replace- allow children to sit comfortably and safely. ment is only carried out by an authorised Volvo workshop. Do not make any modifi- The booster cushions are specially designed cations or additions to the booster cush- to provide optimum safety.

  • Page 53: Two-Stage Booster Seat* - Raising

    02 Safety Two-stage booster seat* - raising Stage 2 The integrated booster seat (p. 50) in the rear seat can be folded up into two stages. How many stages the cushion should be folded up depends on the child's weight. Stage 1 Stage 2 Weight...

  • Page 54: Two-Stage Booster Seat* - Lowering

    02 Safety Two-stage booster seat* - lowering The integrated booster seat (p. 50) in the rear seat can be folded down from the upper or lower stage to fully lowered position in the seat cushion. However, it is not possible to adjust the booster cushion from the upper stage to the lower stage.

  • Page 55: Child Seat - Isofix

    02 Safety • Child seat - ISOFIX ISOFIX - size classes General information on child safety (p. 43) ISOFIX is a fixture system for car child seats There is a size classification for child seats (p. 45) that is based on an international stand- using the ISOFIX (p.
  • Page 56 If an ISOFIX child seat has no size classifi- cation, the car model must be included on the vehicle list for the child seat. NOTE Volvo recommends that you contact an authorised Volvo dealer for recommenda- tions about which ISOFIX child seats Volvo recommends.

  • Page 57: Isofix - Types Of Child Seat

    02 Safety ISOFIX - types of child seat seats are suitable for all seats in all car mod- els. Child seats are in different sizes – cars are in different sizes. This means that not all child Type of child seat Weight Size class Passenger seats for ISOFIX installation of child seats...
  • Page 58 IL: Suitable for specific ISOFIX child seats. These child seats may be intended for a particular car model, limited or semi-universal categories. IUF: Suitable for front-facing ISOFIX child seats that are universally approved in this weight class. Volvo recommends rear-facing child seats for this group. Make sure you select the right size class (p.

  • Page 59: Child Seats - Upper Mounting Points

    General information on child safety (p. 43) intended for use with front-facing child seats. • Child seats - location (p. 49) Volvo recommends that small children should sit in rear-facing child seats to as late an age • Child seat - ISOFIX (p. 53) as possible.
  • Page 60 I N S T R U M E N T S A N D C O N T R O L S...

  • Page 61: 03 Instruments And Controls

    03 Instruments and controls Instruments and controls, left-hand drive car - overview The overview shows where the car's displays and controls are located.
  • Page 62 03 Instruments and controls Overview, left-hand drive cars...
  • Page 63 03 Instruments and controls Function Function Function Menus and mes- (p. 111), Door handle Seat adjustment* (p. 83). sages, direction (p. 113), Control panel (p. 179), Headlamp control, (p. 89), indicators, main/ (p. 98), (p. 184), opener for fuel filler (p.

  • Page 64: Instruments And Controls, Right-Hand Drive Car - Overview

    03 Instruments and controls Instruments and controls, right-hand drive car - overview The overview shows where the car's displays and controls are located.
  • Page 65 03 Instruments and controls Overview, right-hand drive cars...
  • Page 66 03 Instruments and controls Function Function Function Screen for infotain- (p. 114) and Control panel (p. 179), Control panel for (p. 114) and ment system and the Sensus (p. 184), infotainment system the Sensus display of menus Infotainment (p. 104) and and menu naviga- Infotainment supplement.

  • Page 67: Combined Instrument Panel

    03 Instruments and controls Combined instrument panel Analogue combined instrument panel Gauges and indicators - overview The combined instrument panel's information display shows information on some of the The combined instrument panel's information car's functions, as well as messages. display shows information on some of the car's functions, as well as messages.

  • Page 68: Digital Combined Instrument Panel - Overview

    03 Instruments and controls Digital combined instrument panel - Functionality check Tachometer. The meter indicates engine overview speed in thousands of revolutions per All indicator and warning symbols, apart from minute (rpm). symbols in the centre of the information dis- The combined instrument panel's information play, illuminate in key position II or when the display shows information on some of the...
  • Page 69 03 Instruments and controls Gauges and indicators Geartronic* (p. 283) or Automatic gear- box -- Powershift* (p. 286). Alternative themes can be selected for the digital combined instrument panel. Possible themes are "Elegance", "Eco" and "Performance". A theme can only be selected when the engine is running.
  • Page 70 03 Instruments and controls Indicator and warning symbols Tachometer. The meter indicates engine Speedometer speed in thousands of revolutions per Tachometer. The meter indicates engine minute (rpm). speed in thousands of revolutions per Gear shift indicator /Gear position indica- minute (rpm). .

  • Page 71: Eco Guide & Power Guide

    03 Instruments and controls Eco guide & Power guide* Functionality check Instantaneous value All indicator and warning symbols, apart from The instantaneous value is shown here - the Eco guide and Power guide are two com- symbols in the centre of the information dis- higher the reading on the scale, the better.

  • Page 72: Combined Instrument Panel - Meaning Of Indicator Symbols

    Low level in fuel tank the car's emissions system. Drive to a work- shop for checking. Volvo recommends that you seek assistance from an authorised Volvo workshop. Power is dependent on engine speed. Option/accessory, for more information, see Introduction.
  • Page 73 The symbol illuminates in the event of low checked. Volvo recommends that you behave as intended, this information symbol tyre pressure, or if a fault arises in the tyre seek assistance from an authorised Volvo illuminates and a text appears on the informa- pressure system. workshop.

  • Page 74: Combined Instrument Cluster - Meaning

    SRS, SIPS, or Fault in brake system possible and close the tailgate. IC systems. Drive immediately to a workshop Related information to have the system checked. Volvo recom- Warning • Combined instrument panel (p. 65) mends that you seek assistance from an authorised Volvo workshop.
  • Page 75 Clear the message using the OK button. Visit a workshop. Volvo recommends that you ther before topping up the brake fluid. seek assistance from an authorised Volvo Reminder –...

  • Page 76: Outside Temperature Gauge

    03 Instruments and controls Outside temperature gauge Trip meter Related information • Combined instrument panel (p. 65) The display for the outside temperature gauge The trip meter display appears in the com- • appears in the combined instrument panel. bined instrument panel. Combined instrument panel - meaning of indicator symbols (p.

  • Page 77: Clock

    03 Instruments and controls Clock Fuel gauge for vehicle gas* Number of Colour of Fuel The clock display appears in the combined The Bi-Fuel model variant has a separate fuel LEDs LEDs level (%) instrument panel. gauge for vehicle gas. Green Orange When the vehicle gas tank is empty the...

  • Page 78: Combined Instrument Panel - License Agreement

    The Portions of this product uses software with Shown below are the most common symbols following text is Volvo's agreement with the Copyright © 1994–2013 Lua.org, PUC-Rio with their meanings and a reference to where manufacturer/developer.
  • Page 79 03 Instruments and controls Symbol Specification Symbol Specification Symbol Specification Parking brake (p. 72) Rear fog lamp on (p. 70), ECO function* (p. 70), applied, alterna- (p. 97) (p. 300) tive symbol Stability system, (p. 70), Tyre pressure (p. 70), Airbags –...
  • Page 80 03 Instruments and controls Symbol Specification Symbol Specification Symbol Specification Windscreen sen- (p. 93), Active high beam, (p. 93) Engine block (p. 145) sor*, Camera sen- (p. 228), AHB (Active High heater and pas- sor*, Laser sen- (p. 237), Beam)* senger compart- sor* (p.

  • Page 81: Volvo Sensus

    Car settings, Audio and Symbol Specification media, Climate control, etc. Volvo Sensus is the heart of the personal Measuring the oil (p. 374) Volvo experience and connects you with the With the centre console buttons and controls level car and outside world.

  • Page 82: Key Positions

    03 Instruments and controls Key positions Overview the remote control key in the ignition switch. The remote control key can be used to set the 2. Then press the remote control key in the vehicle's electrical system in different modes/ lock up to its end position.

  • Page 83: Key Positions - Functions At Different Levels

    03 Instruments and controls Key positions - functions at different Level Functions Level Functions levels • • Odometer, clock and tem- The headlamps come on. To enable the use of a limited number of perature gauge are illumi- • functions with the engine switched off, the Warning/indicator lamps illu- nated.

  • Page 84: Seats, Front

    03 Instruments and controls • Seats, front Key position I - With the remote control WARNING key fully inserted into the ignition switch The car's front seats have different setting Adjust the position of the driver's seat - Briefly press START/STOP ENGINE. options for optimum seating comfort.

  • Page 85: Seats, Front - Electrically Operated

    03 Instruments and controls Seats, front - electrically operated* electrical system in key position I or 0 and Lift the catches on the rear of the back- rest and fold it forward. wait a short time before adjusting the seat The car's front seats have different setting again.

  • Page 86: Seats, Rear

    03 Instruments and controls Seats, rear Store setting Emergency stop Memory button If the seat accidentally begins to move, press The rear seat backrest and the outer seat one of the setting buttons for the seat or head restraints can be folded. The centre seat Memory button memory buttons in order to stop the seat.
  • Page 87 03 Instruments and controls Lowering the rear seat backrest WARNING The centre seat head restraint must be in IMPORTANT its lowest position when the centre seat is not used. When the centre seat is used, There must be no objects on the rear seat the head restraint must be correctly when the backrest is to be folded down.
  • Page 88 03 Instruments and controls Electrical lowering of the rear seat's Related information NOTE • outer head restraints* Seats, front (p. 82) When the backrests have been lowered • Seats, front - electrically operated* (p. 83) the head restraints must be moved for- ward slightly so as not to make contact with the seat cushion.

  • Page 89: Steering Wheel

    03 Instruments and controls Steering wheel Keypads* and paddles* 3. Push back the lever to fix the steering wheel in place. If the lever is stiff, press The steering wheel can be adjusted in differ- the steering wheel lightly at the same time ent positions and has controls for horn and as you push the lever back.

  • Page 90: Heating* Of The Steering Wheel

    03 Instruments and controls Heating* of the steering wheel Horn approx. 10 °C. Activate/deactivate the func- tion in the menu system MY CAR (p. 114). The steering wheel can be heated with elec- tric heating. Function Horn. Press the centre of the steering wheel to sig- nal.

  • Page 91: Light Switches

    03 Instruments and controls Light switches Knob positions Posi- Specification The headlamp control activates and adjusts tion NOTE the external lighting. It is also used to adjust Daytime running lights, posi- display and instrument lighting and ambience The same lamps are used for daytime run- tion/parking lamps rear and lights (p.
  • Page 92 • Position/parking lamps (p. 91) beam if the car is heavily laden. • Daytime running lights (p. 91) Volvo recommends that mode is used 1. Leave the engine running, or have the • Main/dipped beam (p. 92) when the car is driven.

  • Page 93: Position/Parking Lamps

    03 Instruments and controls Position/parking lamps Daytime running lights Related information • Light switches (p. 89) Position/parking lamps are switched on with With the knob for headlamp control in the headlamp control's knob. position, and the car's electrical system in key position II or the engine running, the daytime running lights are activated automatically in daylight.

  • Page 94: Tunnel Detection

    03 Instruments and controls Tunnel detection* Main/dipped beam WARNING Tunnel detection changes the lighting from With the knob for headlamp control in posi- This system help to save energy - it cannot daytime running lights to dipped beam when tion and the car's electrical system in determine in all situations when daylight is the car is driven into a tunnel.

  • Page 95: Active Main Beam

    , see MY CAR (p. 114). When dipped beam is switched on. Auxiliary lamps must be connected to the electrical system by a workshop. Volvo recommends that you contact an authorised Volvo workshop. Option/accessory, for more information, see Introduction.
  • Page 96 03 Instruments and controls Activating/deactivating beam about a second after the camera sen- When AHB is activated the symbol illu- sor no longer detects the headlamp beams AHB can be activated when the headlamp minates in the instrument's information dis- from oncoming traffic the rear lights of vehi- play.
  • Page 97 03 Instruments and controls Manual operation WARNING IMPORTANT AHB is an aid for using the optimum beam Examples of when manual switching NOTE pattern when conditions are favourable. between main and dipped beam may be required: Keep the windscreen surface in front of the The driver always bears responsibility for camera sensor free from ice, snow, mist •...

  • Page 98: Active Xenon Headlamps

    Visit malfunc- a workshop if Related information the message tion Serv- • Main/dipped beam (p. 92) remains. Volvo • Active main beam* (p. 93) recommends required that you contact • Light switches (p. 89) an authorised Volvo workshop.

  • Page 99: Rear Fog Lamp

    03 Instruments and controls Rear fog lamp Brake lights NOTE When visibility is reduced by fog the rear fog The brake light automatically comes on during Regulations on the use of rear fog lamps lamp can be used so that other road users braking.

  • Page 100: Hazard Warning Flashers

    03 Instruments and controls Hazard warning flashers direction indicators vated automatically when the car is driven off again or the button is depressed. The hazard warning flashers warn other road The car's direction indicators are operated users by means of all of the car's direction with the left-hand stalk switch.

  • Page 101: Interior Lighting

    03 Instruments and controls Interior lighting Front roof lighting The stalk switch remains in its position and is moved back manually, or automatically by the The front reading lamps are switched on or The passenger compartment lighting is acti- steering wheel movement. off by pressing the relevant button in the roof vated/deactivated with the buttons in the con- console.

  • Page 102: Home Safe Light Duration

    03 Instruments and controls Home safe light duration Lighting in the cargo area Passenger compartment lighting is switched off when: The lighting in the cargo area is switched on Home safe lighting consists of dipped beam, and off respectively when the tailgate is •...

  • Page 103: Approach Lighting

    03 Instruments and controls Approach lighting Headlamps - adjusting headlamp Wipers and washers pattern Approach lighting consists of parking lamps, Wipers and washers clean the windscreen lamps in the door mirrors, number plate light- If the car is equipped with active Xenon head- and rear window.
  • Page 104 03 Instruments and controls Intermittent wiping the rain sensor can be adjusted using the IMPORTANT thumbwheel. Set the number of sweeps per time The windscreen wipers could start and be unit with the thumbwheel when When the rain sensor is activated a lamp in damaged in an automatic car wash.
  • Page 105 (30 seconds or longer, depending on the heat in the motor and the outside temperature). This function (intermittent wiping when reversing) can be deactivated. Visit a workshop. Volvo recommends an authorised Volvo workshop. Option/accessory, for more information, see Introduction.

  • Page 106: Power Windows

    03 Instruments and controls Power windows All power windows can be operated using the WARNING control panel for the driver's door - the con- All power windows can be operated using the Check that no children or other passen- trol panels for the other doors can only each control panel for the driver's door - the con- gers are trapped if/when the windows are operate their respective power window.

  • Page 107: Door Mirrors

    03 Instruments and controls Door mirrors Operating with auto WARNING Move one of the controls up/down to the end The door mirror positions are adjusted with Both mirrors are the wide-angle type to position and release it. The window runs the joystick in the driver's door controls.

  • Page 108: Windows And Rearview And Door Mirrors - Heating

    03 Instruments and controls Windows and rearview and door Retractable power door mirrors* The function can be activated/deactivated in mirrors - heating the menu system MY CAR, see MY CAR The mirrors can be retracted for parking/driv- (p. 114). ing in narrow spaces: The defroster is used to quickly remove mist- ing and ice from the windscreen, rear window 1.

  • Page 109: Rearview Mirror - Interior

    03 Instruments and controls Rearview mirror - interior ever, the function is switched off automati- for manual dimming is not available on mir- cally after a certain time. rors with automatic dimming. The interior rearview mirror can be dimmed with a control in the mirror's lower edge. See also Demisting and defrosting the wind- The rearview mirror contains two sensors - Alternatively, the rearview mirror dims auto-...

  • Page 110: Compass

    03 Instruments and controls Compass* Calibration The compass may need calibrating to show The upper right-hand corner of the rearview the correct compass direction. mirror contains a display that shows the com- pass direction in which the front of the car is The earth is divided into 15 magnetic zones.

  • Page 111: Sunroof

    03 Instruments and controls Sunroof* 7. Cars with heated windscreen*: If the Opening character is shown in the display when For maximum sunroof opening, move the The sunroof can be operated with a control in the heated windscreen is activated, per- control back to the position for automatic the roof panel.
  • Page 112 03 Instruments and controls Closing Vertical opening One long press on the lock button closes the sunroof and all the windows, see Remote Close manually by pushing the control for- control key - functions (p. 166) and Locking/ wards to the point of resistance for manual unlocking - from the inside (p.

  • Page 113: Menu Navigation - Combined Instrument Panel

    03 Instruments and controls Menu navigation - combined Wind deflector instrument panel The left-hand stalk controls the menus (p. 112) shown on the information display in the combined instrument panel (p. 65). Which menus are shown depends on the key posi- tion (p.

  • Page 114: Menu Overview - Combined Instrument Panel

    03 Instruments and controls Menu overview - combined Messages Parking heater * instrument panel When a warning, information or indicator Trip computer reset Which menus are shown in the combined symbol illuminates, a corresponding message appears on the information display. instrument panel's information display Related information depends on the key position (p.

  • Page 115: Messages - Handling

    An authorised Volvo workshop is recommended. possible. must be read (press OK) before the previ- For more information regarding the automatic gearbox, see ous activity can be resumed.

  • Page 116: My Car

    03 Instruments and controls MY CAR vary, depending on the equipment selected and the market. MY CAR is a menu source that handles many MY CAR - opens the menu system MY of the car's functions, e.g. City Safety™, locks CAR.

  • Page 117: Trip Computer

    03 Instruments and controls Trip computer Menu options and search paths Group menus For a description of the menu options and The trip computer has two different group The car's trip computer can record, calculate search paths in MY CAR, see the Sensus menus: and show information while driving.

  • Page 118: Trip Computer - Analogue Combined Instrument Panel

    03 Instruments and controls Trip computer - analogue combined Functions instrument panel Proceed as follows to open and check/adjust functions: The trip computer's menu is in a variable 1. To ensure that no control is in the middle loop. One of the alternatives is that the trip of a sequence - "Reset"...
  • Page 119 03 Instruments and controls Functions Information Digital speed Shows the car's speed digitally in the centre of the combined instrument panel: • • Open with OK, select with the thumbwheel, confirm with OK and back out with RESET. km/h • •...
  • Page 120 03 Instruments and controls Functions Information For more information, see Engine oil - checking and filling (p. 374). Oil level Messages (##) For more information, see Messages - handling (p. 113). Certain engines. Headings 1. To ensure that no control is in the middle 3.
  • Page 121 03 Instruments and controls Average speed - shown in the combined instrument panel: • Give a long press on RESET - selected heading is zeroed. Each heading must be zeroed individually. Related information • Trip computer (p. 115) • Trip computer - supplementary informa- tion (p.

  • Page 122: Trip Computer - Digital Combined Instrument Panel

    03 Instruments and controls Trip computer - digital combined Functions instrument panel Proceed as follows to open and check/adjust functions: The trip computer's menu is in a variable 1. To ensure that no control is in the middle loop. One of the alternatives is that the trip of a sequence - "Reset"...
  • Page 123 03 Instruments and controls Functions Information Trip computer reset Note that this function does not reset both trip meters T1 and T2 - see table under next section "Headings" and section "Resetting - Average speed/consumption" for information on the proc- •...
  • Page 124 03 Instruments and controls Headings One of the heading combinations in the fol- lowing table can be selected for constant dis- play in the combined instrument panel. Pro- ceed as follows to determine which: 1. To ensure that no control is in the middle of a sequence - "Reset"...
  • Page 125 03 Instruments and controls Resetting - Average speed/ consumption Trip computer 1. Select function reset and activate with OK. 2. Select one of the following options with the thumbwheel and activate with OK: • l/100 km • km/h • Reset both 3.

  • Page 126: Trip Computer - Supplementary Information

    30 km and the Applies to Bi-Fuel* cars In addition to in the trip computer, these remaining driveable fuel quantity. units are also changed in Volvo's naviga- During gas operation the trip computer shows tion system*. the equivalent average consumption of gas.

  • Page 127: Trip Computer - Trip Statistics

    03 Instruments and controls Trip computer - trip statistics* Operation Different settings can be made in the menu Information is stored about completed trips system MY CAR, see MY CAR (p. 114) - containing average fuel consumption and Trip statistics there, find average speed, which can be viewed in the centre console's screen as a bar chart.
  • Page 128 C L I M A T E C O N T R O L...

  • Page 129: 04 Climate Control

    04 Climate control • General information on climate may then be a temporary increase in tem- Air distribution in the passenger compart- control perature in the passenger compartment. ment (p. 131) • • Remove misting on the insides of the win- Air quality (p.

  • Page 130: Actual Temperature

    04 Climate control Actual temperature Sensors - climate control Air quality The temperature you select in the passenger The climate control system has a number of The interior in a passenger compartment is compartment corresponds to the physical sensors to help control the temperature designed to be pleasant and comfortable, experience with reference to factors such as (p.

  • Page 131: Air Quality - Passenger Compartment Filter

    The filter must be replaced at regular inter- stances. 75 000 km over 5 years. In cars without vals. Follow the Volvo Service Programme for CZIP and where the customer does not the recommended replacement intervals. If The following is included: want to keep the CZIP standard the IAQS filter must be changed at a regular service.

  • Page 132: Air Quality - Iaqs

    MY CAR (p. 106). agents and car care products recommended (p. 114). • Interior air quality system* (p. 130). by Volvo to clean the interior (p. 413). • Automatic start of seat heating driver NOTE Related information (p. 134).

  • Page 133: Air Distribution In The Passenger Compartment

    04 Climate control Air distribution in the passenger Air vents in the dashboard Air vents in the door pillars compartment The incoming air is divided between a number of different vents in the passenger compart- ment. Open Closed Closed Open Lateral airflow Lateral airflow Air distribution is fully automatic in AUTO...
  • Page 134 04 Climate control Air distribution The selected air distribution is shown in the cen- tre console display screen. Air distribution - defroster windscreen Related information Air distribution - air vent instrument panel • General information on climate control (p. 127) Air distribution - ventilation floor •...

  • Page 135: Electronic Climate Control - Ecc

    04 Climate control Electronic climate control - ECC compartment and can be set separately for The auto function is used to automatically the driver's side and passenger side. control temperature, air conditioning, fan ECC (Electronic Climate Control) maintains speed, recirculation and air distribution. the temperature selected in the passenger Temperature control (p.

  • Page 136: Heated Front Seats

    04 Climate control • Heated front seats* Heated rear seat* Lowest heat level - one orange field illu- minates in the screen. The front seat heating has three positions for The heating for the rear seat's outer posi- • Switch off the heat - no field illuminates. increasing the comfort for driver and passen- tions has three positions for increasing the ger when it is cold.

  • Page 137: Fan

    04 Climate control Auto-regulation WARNING The fan should always be activated in order to The auto function automatically regulates Heated seats must not be used by people avoid misting on the windows. temperature (p. 136), air conditioning who find it difficult to perceive an increase (p.

  • Page 138: Temperature Control In The Passenger

    04 Climate control Temperature control in the passenger Air conditioning Related information compartment • General information on climate control The air conditioning cools and dehumidifies (p. 127) When the car is started, the most recent tem- incoming air as required. •...

  • Page 139: Demisting And Defrosting The Windscreen

    04 Climate control Demisting and defrosting the For cars without heated windscreen: NOTE windscreen • Air flows to the windows - symbol (2) illu- Electrically heated windscreen is not avail- Heated windscreen* and max. defroster are minates in the screen. able when the engine is auto-stopped used to quickly remove misting and ice from •...

  • Page 140: Air Distribution - Recirculation

    04 Climate control Air distribution - recirculation Related information • General information on climate control Select recirculation to shut out bad air, (p. 127) exhaust gases etc. from the passenger com- • partment, i.e. no outside air is taken into the Air distribution in the passenger compart- car when this function is activated.

  • Page 141: Air Distribution - Table

    04 Climate control Air distribution - table Three buttons are used to select the distribu- tion (p. 131) of the air. Air distribution Air to windows. Some air flows from the air vents. The air is not to remove ice and misting quickly. recirculated.
  • Page 142 04 Climate control Air distribution Air to the floor and windows. Some air flows from the dashboard to ensure comfortable conditions and good demisting in air vents. cold or humid weather. Air to floor and from dashboard air vents. in sunny weather with cool outside temperatures. Air to floor.

  • Page 143: Engine Block Heater And Passenger Compartment Heater

    04 Climate control Engine block heater and passenger Refuelling appears on the information display. Acknowl- compartment heater* edge the message by pressing the indicator stalk (p. 111) OK button once. Preconditioning prepares the heater, engine and passenger compartment before depar- IMPORTANT ture so that both wear and energy needs dur- ing the journey are reduced.

  • Page 144: Engine Block Heater And Passenger Compartment Heater* - Direct Start

    Indicator lamp on remote control key with PCC*. settings that can be managed from a mobile Heating of the passenger compartment will phone will be available via the Volvo On Call* begin as soon as the engine coolant has The engine block heater and passenger com- mobile app.

  • Page 145: Engine Block Heater And Passenger Compartment Heater* - Immediate Stop

    04 Climate control Engine block heater and passenger Engine block heater and passenger 6. Briefly press OK to move to the flashing compartment heater* - immediate compartment heater* - timer minutes setting. stop The timer of the engine block and passenger 7.
  • Page 146 04 Climate control Parking 2. Scroll with the thumbwheel to heater and select with OK. > If a timer is set but not activated then a clock icon is shown beside the set time. 3. Select one of the two timers using the thumbwheel and confirm with OK.

  • Page 147: Engine Block Heater And Passenger Compartment Heater* - Messages

    04 Climate control Engine block heater and passenger When one of the timers has been activated, Symbol for activated timer in digital compartment heater* - messages the symbol for activated timer illuminates in combined instrument panel. the display at the same time as the set time is Symbols and display messages regarding the shown next to the symbol.
  • Page 148 Low fuel level starting the engine as well as approx. 50 km driving. Fuel operated heater Service Heater not working. Contact a workshop for repair. Volvo recommends that you contact an required authorised Volvo workshop. A display text clears automatically after a time or after one press on the indicator stalk (p.

  • Page 149: Additional Heater

    1. Before starting the engine: Select key position I (p. 81). An authorised Volvo dealer has information regarding the geographical areas concerned. An authorised Volvo dealer has information regarding the engines concerned. Analogue combined instrument panel. Digital combined instrument panel.

  • Page 150: Electric Additional Heater

    04 Climate control Electric additional heater* The car is equipped with either a fuel-driven (p. 147) or an electric additional heater (p. 147). The heater cannot be controlled manually, but is instead activated automatically after the engine has been started in outside tempera- tures below 14 °C and is switched off after the set passenger compartment temperature has been reached.
  • Page 151 L O A D I N G A N D S T O R A G E...

  • Page 152: 05 Loading And Storage

    05 Loading and storage Storage spaces Overview of storage spaces in the passenger compartment.
  • Page 153 05 Loading and storage Storage compartment in door panel Storage pocket* on front edge of front seat cushions Ticket clip Glovebox (p. 152) Storage compartment Storage compartment, cup holder (p. 152) Cup holder* in armrest, rear seat Storage pocket WARNING Keep loose objects such as mobile phones, cameras, remote controls for accessories, etc.

  • Page 154: Tunnel Console

    05 Loading and storage Tunnel console Tunnel console - cigarette lighter and Glovebox ashtray* The tunnel console is located between the The glovebox is located on the passenger front seats. A detachable ashtray is fitted in the cup side. holder under the armrest. The cigarette lighter is fitted in the 12 V socket (p.

  • Page 155: Inlay Mats

    Inlay mats collect e.g. rubbish and slush. The vanity mirror is located on the rear of the The electrical sockets (12 V) are located next Volvo supplies specially manufactured inlay sun visor. to the cup holder and rear of the tunnel con- mats.

  • Page 156: Loading

    The compressor for emergency puncture tailgate (p. 181). repair (p. 352) has been tested and Optional equipment and accessories - e.g. approved by Volvo. display screens, music players and mobile WARNING phones - which are connected to one of the passenger compartment's 12V electri- The car’s driving properties change...

  • Page 157: Loading - Long Load

    05 Loading and storage • Loading - long load Cover sharp edges with something soft to Related information avoid damaging the upholstery. • Load retaining eyelets (p. 156) To simplify loading (p. 154) in the cargo area, • Secure all loads to the load retaining eye- •...

  • Page 158: Roof Load

    The folding load retaining eyelets are used to The bag holder keeps carrier bags in place are the ones developed by Volvo. This is in fasten straps in order to anchor items in the and prevents them from overturning and order to avoid damage to the car and in order cargo area.

  • Page 159: 12 V Electrical Socket - Cargo Area

    Volvo. For information on the use of Volvo's recommended temporary emergency puncture repair (TMK), see Emergency puncture repair (p. 352).
  • Page 160 05 Loading and storage Using the safety net Removing the net cassettes 1. Roll the safety nets into the cassettes in accordance with the procedure in the section entitled "Using the safety net", but in reverse. 2. Fold the whole backrest forward. 3.

  • Page 161: Safety Net* Combined With Cargo Cover

    05 Loading and storage Safety net* combined with cargo Safety grille desired, the safety grille can be dismantled cover and removed from the car. A safety grille prevents loads or pets from A safety net prevents loads from being thrown being thrown forward in the passenger com- For information about the tools required and partment in the event of sudden braking.

  • Page 162: Cargo Cover

    05 Loading and storage Cargo cover Removing the cargo cover 1. Press in one end piece button and lift it out. 2. Carefully angle the cover up/out and the other end piece loosens automatically. Lowering the cargo cover's rear sealing disc In its rolled-in position, the cargo cover's rear sealing disc protrudes horizontally into the...
  • Page 163 L O C K S A N D A L A R M...

  • Page 164: 06 Locks And Alarm

    The remaining remote control keys must be More remote control keys can be ordered - Remote control key in basic version and taken to the Volvo workshop. The code of the but not variants other than the one supplied Remote control key with PCC (Personal Car missing remote control key must be erased with the car.

  • Page 165: Remote Control Key - Personalisation

    06 Locks and alarm Remote control key - personalisation* Proceed as follows in order to store the set- WARNING tings and use the key memory in the remote The key memory in the remote control key Risk of crushing! Make sure that children control key: (p.

  • Page 166: Locking/Unlocking - Indicator

    06 Locks and alarm Locking/unlocking - indicator Lock indicator Seats, front - electrically operated* (p. 83). When the car is locked or unlocked using the A flashing LED by the windscreen verifies that • Adjust seat and door mirrors manually, remote control key (p.

  • Page 167: Immobiliser

    - an authorised Volvo work- shop is recommended. For starting the car, see Starting the engine (p. 275). Related information • Remote-controlled immobiliser with tracking system* (p. 165) Only certain markets and in combination with Volvo On Call*. Option/accessory, for more information, see Introduction.

  • Page 168: Remote Control Key - Functions

    06 Locks and alarm Remote control key - functions Press and hold to open all windows simulta- neously. For more information, see Global The remote control key in basic version has opening (p. 180). functions such as locking and unlocking the doors.

  • Page 169: Remote Control Key - Range

    06 Locks and alarm Remote control key - range Related information Related information • • Remote control key (p. 162) Remote control key (p. 162) Remote control key functions (in its basic ver- • • sion) have a range of approx. 20 metres from Remote control key with PCC* - unique Remote control key - functions (p.

  • Page 170: Remote Control Key With Pcc* - Unique Functions

    Red continuous light – the alarm has travelled around on the PCC), contact a been triggered since the car was locked. workshop - an authorised Volvo workshop is recommended. Remote control key with PCC. Red light flashing alternately in both indi- Information button cator lamps –...

  • Page 171: Remote Control Key With Pcc* - Range

    100 metres. The key blade's unique code is provided by If the car does not verify a button being authorised Volvo workshops, which are rec- pressed - move closer and try again. ommended when ordering new key blades.

  • Page 172: Detachable Key Blade - Detaching

    06 Locks and alarm Detachable key blade - detaching/ Detachable key blade - unlocking Related information attaching • doors Detachable key blade - unlocking doors (p. 170) Detaching/attaching the detachable key blade The detachable key blade (p. 169) can be •...

  • Page 173: Privacy Locking

    06 Locks and alarm Privacy locking* Activate/deactivate Privacy locking is intended for when the car is left for service, with a hotel parking valet or similar. The glovebox is then locked and the tailgate lock is disconnected from the central locking - the tailgate cannot be opened with either the central locking button in the front doors or the remote control key (p.

  • Page 174: Remote Control Key - Replacing The Bat

    06 Locks and alarm • Remote control key - replacing the Deactivation takes place in reverse order. battery For information on locking the glovebox only, see Locking/unlocking - glovebox (p. 180). The battery for the remote control key may need to be replaced. The battery for the remote control key should be replaced if: •...

  • Page 175: Keyless Drive

    Cars equipped with Keyless Drive have a star- Turn the remote control key over with the Volvo recommends that the batteries to be ting and locking system that can be operated buttons facing up, this is to avoid the bat- used in the remote control key/PCC fulfil keylessly.

  • Page 176: Keyless Drive* - Remote Control Key Range

    06 Locks and alarm Keyless Drive* - remote control key Keyless drive* - secure handling of are closed, then a warning message is shown range the remote control key in the information display in the combined instrument panel and an audio reminder sig- In order to unlock the doors or tailgate auto- It is important to handle the car's remote con- nal sounds at the same time.

  • Page 177: Keyless Drive* - Interference To Remote Control Key Function

    06 Locks and alarm Keyless drive* - interference to Keyless drive* - locking All doors and the tailgate must be closed remote control key function before the car can be locked - otherwise the Cars equipped with Keyless drive have a car is not locked.

  • Page 178: Keyless Drive* - Unlocking

    06 Locks and alarm Keyless drive* - unlocking Keyless drive* - unlocking with the 2. Then insert the key blade in the lock cyl- key blade inder and unlock the door. Unlocking takes place when a hand grasps a door handle or the tailgate's rubberised pres- If central locking cannot be unlocked with the 3.

  • Page 179: Keyless Drive* - Lock Settings

    06 Locks and alarm Keyless Drive* - lock settings Keyless Drive* - antenna location WARNING Lock settings for cars equipped with Keyless Cars equipped with Keyless Drive have a People with pacemaker operations should Drive can be adapted by indicating in the number of built-in antennas positioned at dif- not come closer than 22 cm to the keyless menu system MY CAR which doors are to be...

  • Page 180: Locking/Unlocking - From The Outside

    06 Locks and alarm Locking/unlocking - from the outside Manual locking of the door NOTE Locking/unlocking from the outside is carried In certain situations the car must be lockable Remember that the alarm is triggered out using the remote control key (p. 162). The manually, e.g.

  • Page 181: Locking/Unlocking - From The Inside

    06 Locks and alarm • Locking/unlocking - from the inside Pull the door handle and open the door - The door is blocked against opening from the door is unlocked and opened in one the outside. All of the doors and the tailgate can be locked operation.

  • Page 182: Global Opening

    06 Locks and alarm Global opening Locking/unlocking - glovebox Lock button* rear doors The global opening function opens or closes The glovebox (p. 152) can only be locked/ all side windows simultaneously and can be unlocked using the remote control key's used for example to quickly air the car during detachable key blade.

  • Page 183: Locking/Unlocking - Tailgate

    06 Locks and alarm Locking/unlocking - tailgate Related information IMPORTANT • Remote control key (p. 162) The tailgate can be opened, locked and • Minimal force is required to release the unlocked in several ways. rear hatch lock - just gently press the rubberised panel.

  • Page 184: Deadlocks

    06 Locks and alarm Deadlocks* Locking with the remote control key The doors remain locked and armed. – Press the remote control key's button for • Deadlocks means that all door handles are The tailgate is unlocked, but remains locking , see Remote control key - mechanically disengaged, which prevents closed - press lightly on the rubberised...

  • Page 185: Child Safety Locks - Manual Activation

    06 Locks and alarm Child safety locks - manual activation Temporary deactivation NOTE The child safety locks prevent children from • Remember that the alarm is activated being able to open a rear door from the when the car is locked. inside.

  • Page 186: Child Safety Locks - Electrical Activation

    06 Locks and alarm Child safety locks - electrical 2. Press the button in the driver's door con- WARNING activation* trol panel. Each rear door has two knob controls - do Child safety locks with electrical activation > The combined instrument panel's not mix up the child safety locks with man- information display shows the mes- prevent children from opening the rear doors...

  • Page 187: Alarm

    NOTE ment panel shows a message. In which case, contact a workshop - an authorised Volvo Do not attempt to repair or alter compo- nents in the alarm system yourself. Any workshop is recommended.

  • Page 188: Alarm Indicator

    06 Locks and alarm Alarm indicator Alarm - automatic re-arming Alarm - remote control key not working The alarm indicator shows alarm system Automatic re-arming of the alarm (p. 185) pre- (p. 185) status. vents the car being left with the alarm dis- If the alarm (p.

  • Page 189: Alarm Signals

    06 Locks and alarm Alarm signals Reduced alarm level Type approval - remote control key system When the alarm (p. 185) is triggered a siren Reduced guard means that the movement sounds and all direction indicators flash. and tilt detectors can be temporarily deacti- Type approval for the remote control key sys- vated.
  • Page 190 06 Locks and alarm Country/Area China Hong Kong Related information • Remote control key (p. 162)
  • Page 191 D R I V E R S U P P O R T...

  • Page 192: 07 Driver Support

    07 Driver support Active chassis - Four C* Adjustable steering force* Operation Active chassis "Four-C" (Continously Speed related power steering causes the Controlled Chassis Concept), regulates the steering wheel force to increase with the characteristics of the shock absorbers so that speed of the car in order to give the driver the car's driving characteristics can be enhanced sensitivity.

  • Page 193: Electronic Stability Control (Esc) - General

    Engine drag control - EDC reach the prevailing traffic speed. • Corner Traction Control - CTC • Trailer Stability Assist - TSA Trailer Stability Assist is included in the installation of Volvo genuine towbar. Option/accessory, for more information, see Introduction.

  • Page 194: Electronic Stability Control (Esc) - Operation

    07 Driver support Electronic stability control (ESC) - Sport mode is indicated in the com- operation bined instrument panel by means of this symbol illuminating with a con- Selection of level - Sport mode stant glow until the driver deselects the function or until the engine is switched off The ESC system is always activated - it can- - after the next time the engine is started the...

  • Page 195: Electronic Stability Control (Esc) - Symbols And Messages

    Stop the car in a safe place, switch off the engine and start it again. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. "Message" There is a text message in the combined instrument panel (p. 65) - Read it! Constant glow for System check when the engine is started.
  • Page 196 07 Driver support Related information • Electronic stability control (ESC) - general (p. 191) • Electronic stability control (ESC) - opera- tion (p. 192)

  • Page 197: Road Sign Information (Rsi)

    07 Driver support Road Sign Information (RSI)* Road sign information (RSI)* - WARNING operation The road sign information function (RSI – RSI does not work in all situations but is Road Sign Information) helps the driver to The road sign information function (RSI – designed merely as a supplementary aid.
  • Page 198 07 Driver support End of restriction or motorway Additional signs A corresponding road sign is shown in the combined instrument panel for approx. 10 seconds in situations where RSI detects a sign that involves the end of a speed limit - or other speed-related informa- tion, e.g.

  • Page 199: Road Sign Information (Rsi)* - Limitations

    07 Driver support Road sign information (RSI)* - Road sign information On/Off exceeded. The function can be activated/ deactivated in the menu system MY CAR. For limitations a description of the menu system, see MY The road sign information function (RSI – CAR (p.

  • Page 200: Speed Limiter

    07 Driver support Speed limiter* Speed limiter* - getting started Related information • Speed limiter* - getting started (p. 198) A Speed Limiter (Speed Limiter) can be regar- Switch on and activate • ded as a reverse cruise control - the driver Speed limiter* - temporary deactivation When the speed limiter is active, its symbol regulates the speed using the accelerator...

  • Page 201: Speed Limiter* - Changing Speed

    07 Driver support Speed limiter* - changing speed Speed limiter* - temporary 2. Scroll with the button until the com- deactivation and standby mode bined instrument panel shows a mark (5) Changing the stored speed by the desired maximum speed. A Speed Limiter (Speed Limiter) can be regar- ded as a reverse cruise control - the driver >...

  • Page 202: Speed Limiter* - Alarm For Speed Exceeded

    07 Driver support Speed limiter* - alarm for speed Speed limiter* - deactivation – Depress the accelerator pedal fully. exceeded > The combined instrument panel shows A Speed Limiter (Speed Limiter) can be regar- the stored maximum speed with a col- A Speed Limiter (Speed Limiter) can be regar- ded as a reverse cruise control - the driver oured mark (5) and the driver can tem-...

  • Page 203: Cruise Control

    Selected speed (GREY = Standby mode). Cruise control active - WHITE symbol (GREY = Standby mode). A Volvo dealer has updated information about what applies in each respective market. Option/accessory, for more information, see Introduction.

  • Page 204: Cruise Control* - Managing Speed

    07 Driver support Cruise control* - managing speed Cruise control* temporary To adjust +/- 5 km/h: deactivation and standby mode It is possible to activate, set and change the • Use short presses - each press gives stored speed. The function can be temporarily deactivated +/- 5 km/h.

  • Page 205: Cruise Control* - Resume Set Speed

    07 Driver support • Cruise control* - resume set speed Standby mode due to driver intervention Cruise control* - resume set speed (p. 203) Cruise control is temporarily disengaged and The cruise control (CC – Cruise Control) helps • automatically set in standby mode if: Cruise control* - deactivate (p.

  • Page 206: Cruise Control* - Deactivate

    Maintenance of adaptive cruise control driver is warned instead by the Distance components must only be performed at a Warning (p. 219) function about the short workshop - an authorised Volvo workshop distance. is recommended. For a limited time after the service, the ACC function can have a somewhat lim- ited range.

  • Page 207: Adaptive Cruise Control* - Function

    07 Driver support Adaptive cruise control* - function Related information WARNING • Adaptive cruise control* - function It consists of a cruise control system and a Adaptive cruise control is not a collision (p. 205) coordinated spacing system. avoidance system. The driver must inter- •...
  • Page 208 07 Driver support Warning lamp - braking by driver The adaptive cruise control aims to follow the NOTE vehicle ahead in the same lane according to required The warning lamp may be difficult to see in what the driver set for time interval (p. 209). If Adaptive cruise control has a braking strong sunlight or when wearing sun- the radar sensor cannot see any vehicle in...

  • Page 209: Adaptive Cruise Control* - Overview

    Activate and adjust the speed. Green marking at stored speed (WHITE = standby mode). Green marking at stored speed (WHITE = standby mode). A Volvo dealer has updated information about what applies in each respective market. Option/accessory, for more information, see Introduction.

  • Page 210: Adaptive Cruise Control* - Managing Speed

    07 Driver support Adaptive cruise control* - managing At the same time a speed stored speed when the accelerator pedal is speed range is marked: released. To start the ACC: NOTE • Press the steering wheel button If any of the adaptive cruise control but- tons are held depressed for several similar WHITE symbol illuminates in the minutes then the function is blocked and...

  • Page 211: Adaptive Cruise Control* - Set Time Interval

    07 Driver support Adaptive cruise control* - set time Adaptive cruise control* - temporary NOTE interval deactivation, and standby mode Only use the time intervals permitted by The adaptive cruise control can be temporar- local traffic regulations. Different time intervals to the ily deactivated and set in standby mode.

  • Page 212: Adaptive Cruise Control* - Overtaking Another Vehicle

    07 Driver support • • Adaptive cruise control* - overtaking the gear selector is moved to N position wheels lose traction (automatic gearbox) another vehicle • brake temperature is high • the driver maintains speed higher than • the radar sensor is covered e.g. by wet When the car is following another vehicle and the stored speed for longer than snow or heavy rain (radar waves blocked).

  • Page 213: Adaptive Cruise Control* - Deactivate

    07 Driver support Adaptive cruise control* - deactivate Adaptive Cruise Control* - queue With an automatic gearbox, the adaptive assistance cruise control can follow another vehicle Keypad with Speed limiter within the range 0-200 km/h. Queue assistance also provides the adaptive The adaptive cruise control is switched off cruise control with enhanced functionality at NOTE...
  • Page 214 07 Driver support Queue assistance releases the foot brake and NOTE WARNING sets the adaptive cruise control in standby The Queue Assist function can hold the car When the adaptive cruise control is follow- mode in the following situations: stationary for a maximum of 4 minutes - ing another vehicle at speeds in excess of •...

  • Page 215: Adaptive Cruise Control* - Switch Cruise Control Functionality

    • Contact a workshop - an authorised lows the set/stored speed. Volvo workshop is recommended. • Give a long press on the steering wheel The function may completely or partially disappear - or malfunction - if the grille,...

  • Page 216: Radar Sensor - Limitations

    07 Driver support Radar sensor - limitations WARNING A radar sensor (p. 213) has certain limitations The driver must always be observant with - due to its limited field of vision for example. regard to the traffic conditions and inter- vene when the adaptive cruise control is The capacity of the adaptive cruise control to not maintaining a suitable speed or suita-...
  • Page 217 07 Driver support WARNING Adaptive cruise control is not a collision avoidance system. The driver must inter- vene if the system does not detect a vehi- cle in front. The adaptive cruise control does not brake for humans or animals, and not for small vehicles such as bicycles and motorcy- cles.

  • Page 218: Adaptive Cruise Control* - Fault Tracing And Action

    07 Driver support Adaptive cruise control* - fault tracing sensor (p. 213) cannot detect other vehicles sion Warning with Auto Brake (p. 229) are and action in front of the car. working. This message indicates that neither of the The following table presents examples of If the combined instrument panel shows the functions for Distance Alert (p.

  • Page 219: Adaptive Cruise Control* - Symbols And Messages

    07 Driver support Adaptive cruise control* - symbols are some examples - follow the recommenda- and messages tion given if appropriate: Sometimes the adaptive cruise control may display a symbol and/or text message. Here Symbol Message Specification The symbol is GREEN The car maintains the stored speed.
  • Page 220 The adaptive cruise control is disengaged. Service required • Contact a workshop - an authorised Volvo workshop is recommended. Press brake to hold The car is stationary and the cruise control will release the foot brake to allow the parking brake to take over and hold the car, but a fault in the parking brake means the car will shortly begin to roll.

  • Page 221: Distance Warning

    07 Driver support Distance Warning* tion is operated in the car's menu system MY NOTE CAR (p. 114) - there, search for and locate The Distance Warning function (Distance Distance warning is deactivated during the the function Distance Alert Alert) warns the driver if the time interval to time the adaptive cruise control is active.

  • Page 222: Distance Warning* - Limitations

    07 Driver support Distance Warning* - limitations The same symbol is also shown when Adap- tive cruise control (p. 205) is activated. This function, which uses the same radar sensor as Adaptive cruise control (p. 204) and NOTE Collision warning with auto brake (p. 229), The higher the speed the longer the calcu- has certain limitations.

  • Page 223: Distance Warning* - Symbols And Messages

    Distance Warning and Collision Warning with Auto Brake fully or partially disengaged. Service required Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Related information •...

  • Page 224: City Safety

    - an authorised in the traffic ahead, combined with a lapse in of collision, City Safety will automatically Volvo workshop is recommended. attention, could lead to an incident. brake the car, which may be experienced as heavy braking.

  • Page 225: City Safety™ - Operation

    07 Driver support City Safety™ - operation When the function is activated and brakes, the combined instrument panel shows a text City Safety™ is a function for helping the message to the effect that the function is/has driver to avoid a collision when driving in been active.

  • Page 226: City Safety™ - Limitations

    07 Driver support City Safety™ - limitations When your own car is reversing, City Safety is WARNING temporarily deactivated. The sensor in City Safety is designed to The laser sensor also transmits laser light detect cars and other large vehicles in front of City Safety is not activated at low speeds - when City Safety™...
  • Page 227 (see the illustration for sensor location The laser sensor field Remove the (p. 222)) - an authorised Volvo workshop is • Remove ice and snow from the bonnet of vision is blocked. blocking object.

  • Page 228: City Safety™ - Laser Sensor

    - an authorised tion) at a distance of 100 mm or closer Volvo workshop is recommended. It is abso- Radiation data for the laser sensor with magnifying optics such as a mag-...
  • Page 229 07 Driver support • The laser sensor must be fitted onto the windscreen before the sensor's connector is plugged in. • The laser sensor transmits a laser light when the remote control key is in key position II (p. 81) even if the engine is switched off.

  • Page 230: City Safety™ - Symbols And Messages

    Remove the object blocking the sensor and/or clean the windscreen in front of the sensor. Read about laser sensor limitations (p. 224). City Safety Service required City Safety™ is not operational. • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Related information • City Safety™ (p. 222) •...

  • Page 231: Collision Warning System

    "Collision Warning with Auto Brake and must only be performed at a workshop - Cyclist and Pedestrian Detection" can pre- an authorised Volvo workshop is recom- vent a collision or reduce collision speed. mended. "Collision Warning with Auto Brake and Cyclist and Pedestrian Detection"...

  • Page 232: Collision Warning System* - Function

    07 Driver support Collision warning system* - function 1 - Collision warning If in this situation the driver has not yet started to take evasive action and the risk of The driver is first warned of a potentially collision is imminent then the automatic brak- imminent collision.

  • Page 233: Cyclists

    07 Driver support Collision warning system* - detection tours, directly from behind and in the car's cen- WARNING tre line. of cyclists The collision warning system does not Optimal performance of the system requires engage in all driving situations or traffic, that the system function that detects a cyclist weather or road conditions.

  • Page 234: Pedestrians

    07 Driver support • • Collision warning system* - detection The function's capacity to detect cyclists In order for a pedestrian to be detected is deactivated when driving in darkness of pedestrians he/she must appear full-length and have and tunnels - even when streetlights are a height of at least 80 cm.

  • Page 235: Collision Warning System* - Operation

    07 Driver support • Collision warning system* - operation Search for Warning distance Settings for the collision warning system are Collision warning in the menu system made via the centre console's screen and the Warning signals On and Off MY CAR (p. 114) - and there select Long menu system MY CAR, see (p.

  • Page 236: Collision Warning System* - Limitations

    07 Driver support Collision warning system* - limitations Maintenance NOTE The function has certain limitations - for Even if the warning distance has been set example, it is not active until approx. 4 km/h. Long warnings could be perceived as being late in certain situations, e.g.

  • Page 237: Sor Limitations

    07 Driver support Collision warning system* - camera Collision Warning with Auto Brake is tempo- WARNING sensor limitations rarily deactivated with reverse gear engaged. Warnings and brake interventions could be "Collision Warning with Auto Brake and Collision Warning with Auto Brake is not acti- implemented late or not at all if the traffic Cyclist and Pedestrian Detection"...
  • Page 238 - an author- cles. Cause Action ised Volvo work- shop is recom- The field of vision of the camera sensor is lim- The windscreen Clean the wind- mended. ited, which is why pedestrians, cyclists and...

  • Page 239: Collision Warning System* - Symbols And Messages

    07 Driver support Collision warning system* - symbols assist the driver when there is a risk of collid- and messages ing with a pedestrian, bicycle or vehicle in front that are stationary or moving in the same "Collision Warning with Auto Brake and direction.
  • Page 240 Collision Warning with Auto Brake is fully or partially disengaged. ice required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Related information •...

  • Page 241: Driver Alert System

    07 Driver support Driver Alert System* Driver Alert Control (DAC)* Related information • Driver Alert Control (DAC)* (p. 239) The Driver Alert System is intended to assist The DAC function is intended to attract the • drivers whose driving ability is deteriorating or driver's attention when he/she starts to drive Lane Departure Warning (LDW)* (p.

  • Page 242: Driver Alert Control (Dac)* - Operation

    07 Driver support Driver Alert Control (DAC)* - operation driver fatigue, irrespective of whether or not WARNING DAC issues a warning. Settings are made from the centre console An alarm should be taken very seriously, display screen and its menu system. as a sleepy driver is often not aware of NOTE his/her own condition.

  • Page 243: Driver Alert Control (Dac)* - Symbols And Messages

    Driver Alert system Serv- The system is disengaged. ice required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Symbols are schematic - may vary by market and car model. Related information • Driver Alert System* (p. 239) •...

  • Page 244: Lane Departure Warning (Ldw)

    07 Driver support Lane Departure Warning (LDW)* Principle for LDW If the car crosses one of the side lines the driver is alerted with an acoustic signal or The purpose of Lane Departure Warning vibration in the steering wheel. Steering wheel (Lane Departure Warning) is to help the driver vibration varies - the longer the time for which to reduce the risk of the vehicle accidentally...

  • Page 245: Lane Departure Warning (Ldw) - Function

    07 Driver support • • Lane Departure Warning (LDW) - Lane Departure Warning (LDW) - symbols On at startup - The function is set in and messages (p. 245) function standby mode each time the engine is started. Otherwise the same value as •...

  • Page 246: Lane Departure Warning (Ldw) - Opera

    07 Driver support Lane Departure Warning (LDW) - Lane Departure Warning (LDW) - Related information operation • limitations Lane Departure Warning (LDW)* (p. 242) • Lane Departure Warning (Lane Departure Lane Departure Warning (Lane Departure Lane Keeping Aid (LKA)* (p. 246) Warning) is complemented in the combined Warning) camera sensor has limitations in a instrument panel with intuitive graphics in dif-...

  • Page 247: Lane Departure Warning (Ldw) - Sym

    Read about camera sensor limitations (p. 235). Driver Alert system Service The system is disengaged. required • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Related information • Lane Departure Warning (LDW)* (p. 242) •...

  • Page 248: Lane Keeping Aid (Lka)

    07 Driver support Lane Keeping Aid (LKA)* Principle for LKA Related information The purpose of Lane Departure Warning is to • Lane Keeping Aid (LKA) - function help the driver to reduce the risk of the vehi- (p. 247) cle accidentally leaving its own lane in certain •...

  • Page 249: Lane Keeping Aid (Lka) - Function

    07 Driver support Lane Keeping Aid (LKA) - function menu system MY CAR. For a description of activated, the car is steered back into the the menu system, see MY CAR (p. 114). lane. Certain settings can be made for the Lane Keeping Aid (Lane Keeping Aid) function.

  • Page 250: Lane Keeping Aid (Lka) - Operation

    07 Driver support Lane Keeping Aid (LKA) - operation Dynamic cornering Lane Keeping Aid (Lane Keeping Aid) is com- plemented in the combined instrument panel with intuitive graphics in different situations. Here are some examples: NOTE LKA is temporarily deactivated for as long as the direction indicator is switched on.

  • Page 251: Lane Keeping Aid (Lka) - Limitations

    07 Driver support Lane Keeping Aid (LKA) - limitations mode until the driver begins to steer the car again. Lane Keeping Aid (Lane Keeping Aid) camera sensor has limitations in a similar way to the Related information human eye. • Lane Keeping Aid (LKA)* (p.

  • Page 252: Lane Keeping Aid (Lka) - Symbols And Messages

    • Visit a workshop if the message remains - an authorised Volvo workshop is recommended. Lane Keeping Aid Inter- LKA has been set to standby mode. The lines of the LKA symbol indicate when the function is active rupted again.

  • Page 253: Park Assist

    07 Driver support Park Assist* Park assist syst* - function WARNING Parking assistance is used as an aid to park- The parking assistance system is automati- • Parking assistance does not relinquish ing. An acoustic signal as well as symbols on cally activated when the engine is started - the driver's own responsibility during the centre console's screen indicate the dis-...

  • Page 254: Park Assist Syst* - Backward

    07 Driver support Park assist syst* - backward IMPORTANT Parking assistance is used as an aid to park- Objects e.g. chains, thin glossy poles or ing. An acoustic signal as well as symbols on low barriers may be in the "signal shadow" the centre console's screen indicate the dis- and are then temporarily not detected by tance to the detected obstacle.

  • Page 255: Park Assist Syst* - Forward

    When reversing with e.g. a trailer or bike Front parking assistance is deactivated ing. An acoustic signal as well as symbols on carrier on the towbar - without Volvo genu- when the parking brake is applied or P the centre console's screen indicate the dis-...

  • Page 256: Park Assist Syst* - Fault Indication

    07 Driver support Park assist syst* - fault indication Park assist syst* - cleaning the sensors Parking assistance is used as an aid to park- ing. An acoustic signal as well as symbols on Parking assistance is used as an aid to park- the centre console's display screen indicate ing.

  • Page 257: Park Assist Camera

    07 Driver support Park assist camera* Function and operation where the car's rear wheels will roll with the current steering wheel angle - this facilitates Parking camera is an auxiliary system, which parallel parking, reversing into tight spaces is activated when the reverse gear is selected. and for hitching a trailer.
  • Page 258 The parking camera is deactivated The wide "wheel tracks" (2) between the side Orange 0,3–0,5 automatically when towing a trailer if a lines indicate where the wheels will roll and Volvo genuine trailer cable is used. 0–0.3 Option/accessory, for more information, see Introduction.

  • Page 259: Park Assist Camera - Settings

    07 Driver support Park assist camera - settings Related information 3. Highlight the option by pressing OK/ • MENU once and go back out with EXIT. Park assist camera - settings (p. 257) Activate switched-off camera • Park assist camera - limitations (p. 258) Towbar If the camera function is switched off when •...

  • Page 260: Park Assist Camera - Limitations

    07 Driver support Park assist camera - limitations Park Assist Pilot (PAP)* Automatic zoom In cars with Parking assistance (p. 251) and The Park Assist Pilot (PAP – Park Assist Pilot) Automatic zoom NOTE towbar, is also available as helps the driver to park by first checking an option in the camera menu.

  • Page 261: Park Assist Pilot (Pap)* - Function

    07 Driver support Park Assist Pilot (PAP)* - function WARNING PAP does not work in all situations but is NOTE designed merely as a supplementary aid. The PAP function measures the space and The driver always has the final responsibil- turns the steering wheel - the driver's task ity for driving the vehicle in a safe manner is to follow the combined instrument pan-...

  • Page 262: Park Assist Pilot (Pap)* - Operation

    07 Driver support Park Assist Pilot (PAP)* - operation 1. Check that the area behind the car is 2. Keep an eye on the combined instrument clear, then engage reverse gear. panel and be prepared to stop the car when the graphics and text so request. NOTE 2.

  • Page 263: Park Assist Pilot (Pap)* - Limitations

    07 Driver support Park Assist Pilot (PAP)* - limitations 3 - Straightening up IMPORTANT The warning distance is shorter when the The PAP sequence is stopped: sensors are used by PAP compared with when Park Assist uses the sensors. Related information •...
  • Page 264 Consult a workshop - park. ference with the sensors from external an authorised Volvo workshop is recom- • Bear in mind that the front of the car may sound sources which emit the same ultra- mended.

  • Page 265: Park Assist Pilot (Pap)* - Symbols And Messages

    If a message indicates that PAP is inoperative then contact with an authorised Volvo work- The BLIS function CTA (p. 266) (Cross Traffic shop is recommended. Alert) is a driver's aid intended to provide a...

  • Page 266: Blis* - Operation

    07 Driver support BLIS* - operation Overview BLIS (Blind Spot Information) is a function designed for providing support for the driver when driving in dense traffic on roads with several lanes in the same direction. Activate/deactivate BLIS BLIS is activated when the engine is started. This is confirmed by the indicator lamps in the door panels flashing once.
  • Page 267 The door panel by another vehicle. must only be performed by a workshop - indicator lamps flash once upon activation. an authorised Volvo workshop is recom- When BLIS detects a vehicle in zone 1 or a mended. To extinguish the message:...

  • Page 268: Cta

    07 Driver support CTA* CTA is only active during reversing and is WARNING activated automatically when the gearbox's The BLIS function CTA (Cross Traffic Alert) is CTA is a supplementary aid and does not reverse position is selected. a driver aid intended to warn about crossing work in all situations.
  • Page 269 • must only be performed by a workshop - To ensure optimal functionality the areas Sector where CTA can detect/"see". an authorised Volvo workshop is recom- in front of the sensors must be kept mended. clean. •...

  • Page 270: Blis - Symbols And Messages

    • Visit a workshop if the other relevant provisions of message remains - an Directive 1999/5/EC. This dec- authorised Volvo work- laration of conformity may, if shop is recommended. necessary, be consulted with Delphi Electronics & Safety / A text message can be acknowledged by...
  • Page 271 S T A R T I N G A N D D R I V I N G...

  • Page 272: 08 Starting And Driving

    08 Starting and driving Alcohol lock* Alcohol lock* - functions and Indicator Battery status operation The function of the alcohol lock is to prevent lamp (4) the car from being driven by individuals under Functions Flashing Charging in progress the influence of alcohol. Before the engine green can be started the driver must take a breath test that verifies that he/she is not under the...

  • Page 273: Alcohol Lock* - Storage

    08 Starting and driving • Alcohol lock* - storage Alcohol lock* - before starting the Alcohol lock* - symbols and text mes- sages (p. 274) engine Store the alcohol lock in its holder. Release the handheld unit by depressing it slightly in The alcohol lock is activated automatically its holder and releasing it - it then springs out and is then ready for use when the car is...

  • Page 274: Alcohol Lock* - Symbols And Text Mes

    08 Starting and driving • it is unlocked then it must first be acti- Result after breath test Alcohol lock* - storage (p. 271) vated with the switch (2). • Alcohol lock* - to bear in mind (p. 273) Indicator lamp Specification 3.

  • Page 275: Alcohol Lock* - To Bear In Mind

    "Emergency situation". indoors. approx. 5 seconds - the combined instru- Bypass activated ment panel first shows An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.

  • Page 276: Sages

    This function can be used once, after which a An authorised Volvo workshop is recommended. reset must be made at a workshop Alcoguard Contact a workshop Related information Service •...

  • Page 277: Starting The Engine

    08 Starting and driving Starting the engine 1. Insert the remote control key in the igni- WARNING tion switch and press it in to its end posi- The engine is started and switched off using Always remove the remote control key tion.

  • Page 278: Switching Off The Engine

    08 Starting and driving Switching off the engine Steering lock Related information • Switching off the engine (p. 276) The engine is switched off using the START/ The steering lock makes steering difficult if STOP ENGINE button. the car is e.g. taken unlawfully. A mechanical noise may be noticed when the steering lock To stop the engine: unlocks or locks.

  • Page 279: Remote Start (Ers)

    ERS is activated via key and/or via Volvo On Call*. WARNING The climate control starts with the same set-...
  • Page 280 08 Starting and driving 1. Briefly press on the key's button (2). Active functions When an ERS-started engine is switched off, the direction indicators illuminate with a con- The following functions are activated with a 2. Follow this immediately afterwards with a stant glow for 3 seconds.

  • Page 281: Remote Start (Ers) - Symbols And Messages

    Remote start ERS interrupted since the passenger compart- off Low bat- the battery voltage is ment. An authorised Volvo workshop is recommended. tery too low. No remote ERS unavailable due to start Low Remote start ERS interrupted since low battery voltage.

  • Page 282: Jump Starting With Battery

    08 Starting and driving Jump starting with battery Related information 4. Connect one of the red jump lead's • clamps to the donor battery's positive Remote start (ERS)* (p. 277) If the starter battery (p. 390) is discharged terminal (1). •...

  • Page 283: Gearboxes

    08 Starting and driving Gearboxes Manual gearbox 11. Start the engine in the car with the dis- charged battery. There are two main types of gearbox. Manual The function of the gearbox is to change the gearbox and automatic gearbox. gear ratio depending on speed and power IMPORTANT requirements.

  • Page 284: Gear Shift Indicator

    08 Starting and driving Gear shift indicator* Reverse gear inhibitor Automatic gearbox The reverse gear inhibitor hinders the possi- The gear shift indicator notifies the driver bility of mistakenly attempting to engage when it is appropriate to engage the next reverse gear during normal forward travel.

  • Page 285: Automatic Gearbox -- Geartronic

    08 Starting and driving Automatic gearbox -- Geartronic* Parking position - P Neutral position - N Select P position when starting the engine or No gear is engaged and the engine can be The Geartronic gearbox has two different gear when the car is parked.
  • Page 286 08 Starting and driving lever, which returns to its rest position To be able to change gear with the steering After each gear change the combined instru- between + and –. wheel paddles they must first be activated. ment panel changes figure to show the cur- This is by means of pulling one of the paddles rent gear.
  • Page 287 08 Starting and driving The gearbox "winter mode" means that the when the engine reaches its maximum speed Geartronic - Sport mode* (S) car moves off with a lower engine speed and in order to prevent damage to the engine. The Sport programme provides reduced engine power on the drive wheels.

  • Page 288: Automatic Gearbox -- Powershift

    08 Starting and driving Automatic gearbox -- Powershift* Towing can also overheat during slow driving in queues (10 km/h or slower) on an uphill gradi- The model with Powershift transmission The Powershift automatic gearbox transmits ent, or with a trailer hitched. The gearbox should not be towed as it is dependent on the the motive force from the engine to the drive cools down when the car is stationary, with...
  • Page 289 08 Starting and driving Symbol Message Driving characteristics Action Transmission hot Brake to Difficulty in maintaining even speed Transmission overheated. Keep the car stationary using the hold at constant engine speed. foot brake Transmission hot Park Significant pulling in the car's trac- Transmission overheated.

  • Page 290: Gear Selector Inhibitor

    08 Starting and driving Gear selector inhibitor Parking position (P) Deactivate automatic gear selector Stationary car with engine running: inhibitor There are two different types of gear selector inhibitor - mechanical and automatic. • Keep your foot on the brake pedal when moving the gear selector to another posi- Mechanical gear selector inhibitor tion.

  • Page 291: Hill Start Assist (Hsa)

    08 Starting and driving All-wheel drive - (AWD)* Related information Hill start assist (HSA)* • Automatic gearbox -- Geartronic* (p. 283) Optimal traction is achieved with all-wheel The foot brake can be released before setting • drive. Automatic gearbox -- Powershift* (p. 286) off or reversing uphill - the HSA (Hill Start Assist) function means that the car does not All-wheel drive is always available...

  • Page 292: Hill Descent Control (Hdc)

    When HDC is operating, the combined trailer from a ramp. HDC is deactivated: instrument panel's symbol illuminates combined with the text message Hill descent control ON Only possible on the V60 Cross Country with AWD. Option/accessory, for more information, see Introduction.

  • Page 293: Start/Stop

    The function can be disengaged at any time. If it takes place on a steep downhill gradient Environmental care is one of Volvo Car Cor- Related information then the braking effect will not release poration's core values and it influences all of •...

  • Page 294: Start/Stop* - Function And Operation

    08 Starting and driving Start/Stop* - function and operation Auto-starting the engine Conditions The Start/Stop function is activated automati- Conditions cally when the engine is started with the key. Declutch, set the gear lever in neu- The Start/Stop function is tral position and release the clutch With the gear lever in neutral posi- activated automatically when...

  • Page 295: Start/Stop* - The Engine Does Not Stop

    08 Starting and driving Start/Stop* - the engine does not stop Deactivating the Start/Stop function Conditions In certain situations, it may Although the Start/Stop function is activated, advisable to temporarily the engine does not always stop automati- switch off the automatic cally.

  • Page 296: Start/Stop* - The Engine Auto-Starts

    08 Starting and driving • Start/Stop* - the engine auto-starts Battery - Start/Stop (p. 394) Conditions An auto-stopped engine may restart in certain cases without the driver having decided that the atmospheric air pressure is the journey should continue. less than equivalent to In the following cases the engine also starts 1500-2500 metres above sea level automatically if the driver has not depressed...

  • Page 297: Start

    08 Starting and driving • Start/Stop* - the engine does not Start/Stop* - settings (p. 296) Conditions auto-start • Start/Stop* - the engine does not auto- The driver's seatbelt buckle is start (p. 295) The engine does not always auto-start after opened with the gear selector in D having auto-stopped.

  • Page 298: Start/Stop* - Involuntary Stop Manual Gearbox

    DRIVe heading, contains information about If a start-up fails and the engine stops, pro- gearbox (p. 296) Volvo's Start/Stop system, as well as recom- ceed in accordance with the below: • mendations for energy-saving driving techni- Start/Stop* - symbols and messages ques.
  • Page 299 08 Starting and driving • Start/Stop* - symbols and messages (p. 298) • Battery - Start/Stop (p. 394) Option/accessory, for more information, see Introduction.

  • Page 300: Start/Stop* - Symbols And Messages

    Symbol Message Info/Action Auto Start/Stop Service Start/Stop is not operational. Contact a workshop - an authorised Volvo workshop is rec- M + A required ommended. Autostart Engine running Activated if the driver's door is opened with auto-stopped engine and the gear selector in D position.
  • Page 301 ENGINE button and the gear selector in P or N. M = Manual gearbox, A = Automatic gearbox. If a message does not go out following com- pletion of the action then a workshop should be contacted - an authorised Volvo workshop is recommended. Related information •...

  • Page 302: Eco

    ECO button lamp NOTE illuminating when the function is activated. is an innovative Volvo function for When the ECO function is activated, sev- automatic-gearbox cars, capable of reducing eral parameters in the climate control sys- ECO function On or Off...
  • Page 303 08 Starting and driving • on steep downhill gradients - to be able More information and settings tively contribute to reduced consumption. to use engine braking. Accordingly: • before an imminent overtaking manoeu- • Active Eco Coast: Long coasting without vre - in order to be able to complete it in engine braking = Low consumption the safest possible way.

  • Page 304: Foot Brake

    To keep the car as safe and reliable as possi- The foot brake is used to reduce the car's conditions (p. 426). ble, follow the Volvo service intervals as speed while driving. specified in the Service and Warranty Book- The car is equipped with two brake circuits. If Braking on wet roads let.

  • Page 305: Foot Brake - Anti-Lock Braking System

    Foot brake (p. 302) nearest workshop and have the brake sys- • Parking brake (p. 305) tem checked - an authorised Volvo work- • Foot brake - emergency brake lights and shop is recommended. automatic hazard warning flashers If the brake fluid is below the MIN level in (p.

  • Page 306: Foot Brake - Emergency Brake Assistance

    08 Starting and driving Foot brake - emergency brake lights Foot brake - emergency brake and automatic hazard warning assistance flashers Emergency brake assistance EBA (Emergency Emergency brake lights are activated in order Brake Assist) helps to increase the braking force and so reduce the braking distance.

  • Page 307: Parking Brake

    08 Starting and driving Parking brake Applying the parking brake trol. The braking procedure is stopped when the control is released. The parking brake holds the car stationary, when the driver's seat is empty, by mechani- NOTE cally locking/blocking two wheels. An acoustic signal sounds while emer- Function gency braking is active at high speeds.
  • Page 308 2. Start the engine. bol extinguishes. workshop due to the design of the electric 3. Depress the foot brake pedal firmly. parking brake - an authorised Volvo work- NOTE shop is recommended. The parking brake can also be released manually by depressing the clutch pedal instead of the brake pedal.
  • Page 309 Try to apply and release the brake. If the fault persists after a few attempts: • Visit a workshop - an authorised Volvo workshop is recommended. Note: A warning signal sounds if the journey is continued with this error message.
  • Page 310 If the fault persists after a few attempts: • Visit a workshop - an authorised Volvo workshop is recommended. The message is also illuminated on cars with manual gearbox when the car is driven at low speed with the door open in order to alert the driver that the parking brake may have been unintentionally disengaged.

  • Page 311: Driving In Water

    V60 Cross Country), water could enter the The car can be driven through water at a transmission. This reduces the lubricating maximum depth of 25 cm (30 cm with V60 For information about overheating when driv- ability of the oils and shortens the service...

  • Page 312: Driving With Open Tailgate/Boot Lid

    08 Starting and driving Driving with open tailgate/boot lid Overload - starter battery stop the car in a safe way and allow the engine to run at idling speed for a few When driving with the tailgate open, toxic The electrical functions in the car load the minutes in order to allow the gearbox to exhaust fumes can be sucked into the car starter battery (p.

  • Page 313: Before A Long Journey

    • Check that the engine is working normally To achieve optimum roadholding Volvo rec- and that fuel consumption (p. 435) is nor- Check the following in particular before the ommends using winter tyres on all wheels if mal.

  • Page 314: Fuel Filler Flap - Opening/Closing

    08 Starting and driving Fuel filler flap - Opening/closing Fuel filler flap - manual opening Filling up with fuel The fuel filler flap can be opened/closed as The fuel filler flap can be opened manually Important things to consider when refuelling. follows: when electric opening from the passenger compartment is not possible.

  • Page 315: Fuel - Handling

    When filling with a fuel can, use the funnel Mixtures of various fuel types or use of mended by Volvo must not be used as engine located under the floor hatch in the cargo fuels which are not recommended will power and fuel consumption is negatively area.

  • Page 316: Fuel - Petrol

    Fuel tank - volume (p. 433) not be used. filler pipe is clean. Avoid spilling fuel onto the • paintwork. Wash off any spillage with deter- Do not use any additives which have gent and water. not been recommended by Volvo.
  • Page 317 Volvo recommendations and generate increased wear and engine possible - if the car is tilting there is a damage that is not covered by the Volvo risk of air pockets in the fuel supply. warranty. Draining condensation from the fuel...

  • Page 318: Diesel Particle Filter (Dpf)

    08 Starting and driving Diesel particle filter (DPF) Filling vehicle gas* motorway. The car should then be driven for approximately 20 minutes more. Diesel cars are equipped with a particle filter, Points to remember when filling vehicle gas which results in more efficient emission con- (CNG - Compressed Natural Gas) for cars NOTE trol.

  • Page 319: Switch For Gas Operation

    (p. 368) visit the nearest workshop - an authorised • Fuel filler flap - manual opening (p. 312) Volvo workshop is recommended. Related information • Bi-Fuel* - introduction to vehicle gas (p. 24) Press the switch to change between gas •...

  • Page 320: Catalytic Converters

    08 Starting and driving • Catalytic converters Economical driving Fuel - diesel (p. 314) The purpose of the catalytic converters is to Driving economically means driving smoothly purify exhaust gases. They are located close while thinking ahead and adjusting your driv- to the engine so that operating temperature is ing style and speed to the prevailing condi- reached quickly.

  • Page 321: Driving With A Trailer

    Weights (p. 421). • Avoid sudden unnecessary acceleration For more information about fuel consumption, If the towing bracket is mounted by Volvo, and heavy braking. see Fuel consumption and CO2 emissions then the car is delivered with the necessary •...
  • Page 322 Towbars has 7 pin electrics. Use an adapter cable may be certified for higher or lower towing approved by Volvo. Make sure the cable does weights than the car can actually tow. not drag on the ground.

  • Page 323: Driving With A Trailer* - Manual Gearbox

    08 Starting and driving Driving with a trailer* - manual Driving with a trailer* - automatic IMPORTANT gearbox gearbox See also the specific information on slow When driving with a trailer in hilly terrain in a When driving with a trailer in hilly terrain in a driving with a trailer for cars with the hot climate there may be a risk of overheating.

  • Page 324: Towing Bracket/Towbar

    Detachable towbar* - attach- ment/removal (p. 323). WARNING If the car is fitted with a Volvo detachable towbar: • Follow the installation instructions The towbar is stored together with the tools carefully.

  • Page 325: Detachable Towbar* - Specifications

    08 Starting and driving Detachable towbar* - specifications Detachable towbar* - attachment/ removal Specifications for detachable towbar. The attachment/removal of the detachable Specifications towbar is performed in the following way: Attaching Dimensions, mounting points (mm) Remove the protective cover by first pressing in the catch and then pulling the cover straight back...
  • Page 326 08 Starting and driving The indicator window must show red. Turn the key anticlockwise to locked Check that the towbar is secure by pull- position. Remove the key from the lock. ing it up, down and back. WARNING If the towbar is not fitted correctly then it must be detached and reattached in accordance with the previous instructions.
  • Page 327 08 Starting and driving Safety cable. Push the protective cover until it snaps Push in the locking wheel and turn it tight. anticlockwise until you hear a click. WARNING Related information • Detachable towbar* - storage (p. 322) Take care to secure the trailer's safety cable in the intended bracket.

  • Page 328: Trailer Stability Assist - Tsa

    Included in the installation of Volvo genuine towbar. (Electronic Stability Control) - Electronic stability control.

  • Page 329: Towing

    08 Starting and driving Towing In the event of uncertainty as to whether or WARNING not the car is equipped with Powershift trans- During towing, one vehicle is towed by The brake servo and power steering do not mission, this can be verified by checking the another vehicle using a tow rope.

  • Page 330: Towing Eye

    08 Starting and driving Towing eye discharged and the engine does not start, see Take out the towing eye that is located Jump starting with battery (p. 280). under the floor hatch in the cargo area. The towing eye is screwed into a threaded socket behind a cover on the right-hand side Applies to Bi-Fuel* cars: the towing eye is IMPORTANT...

  • Page 331: Recovery

    08 Starting and driving Recovery The cover for the towing eye's attach- WARNING ment point is available in two variants Recovery means that the vehicle is transpor- No one/nothing is allowed to remain which must be opened in different ways: ted away by means of another vehicle.
  • Page 332 08 Starting and driving IMPORTANT Note that the car must always be transpor- ted with the wheels rolling forward. • An All Wheel Drive car (AWD) with raised front suspension must not be towed at speeds above 70 km/h. It should not be towed further than 50 Related information •...
  • Page 333 W H E E L S A N D T Y R E S...

  • Page 334: 09 Wheels And Tyres

    5000 km and then at 10000 km inter- how the car performs. vals. Tyre age Volvo recommends that an authorised Volvo All tyres older than 6 years old should be workshop is contacted for checking if you are checked by an expert even if they seem Tyres are perishable.

  • Page 335: Tyres - Direction Of Rotation

    09 Wheels and tyres Tyres - direction of rotation Storage NOTE Wheels with tyres fitted must be stored lying Tyres with a tread pattern which are designed Make sure that both pairs of wheels have down or hanging up - never standing up. to only turn in one direction have the direction the same type and dimension, and also the of rotation marked with an arrow.

  • Page 336: Tyres - Tread Wear Indicators

    09 Wheels and tyres • Tyres - tread wear indicators Tyres - air pressure Tyres - maintenance (p. 332) Tread wear indicators show the status of the Tyres can have different air pressures which tyre's tread depth. are measured in bar. Check the air pressure in the tyres The tyre pressures must be checked every month.
  • Page 337 09 Wheels and tyres • • Tyre pressure for the car's recommended Tyre pressure label Tyres - maintenance (p. 332) tyre dimension. • Tyres - tread wear indicators (p. 334) • ECO pressure Check the tyre pressure on cold tyres. "Cold tyres"...

  • Page 338: Wheel And Wheel Rim Dimensions

    09 Wheels and tyres Wheel and wheel rim dimensions Tyres - dimensions Related information • Tyres - speed ratings (p. 337) Wheel and rim dimensions are designated in The car's tyres have a certain dimension, see • accordance with the examples in the table the examples in the table below.

  • Page 339: Tyres - Load Index

    09 Wheels and tyres Tyres - load index Tyres - speed ratings 270 km/h Load index indicates a tyre's ability to carry a Each tyre can withstand a certain maximum 300 km/h certain load. speed and therefore belongs to a particular speed rating (SS - Speed Symbol).

  • Page 340: Wheel Bolts

    Only use rims that are tested and approved NOTE of uncertainty Volvo recommends that you by Volvo and which are Volvo genuine acces- consult an authorised Volvo workshop. Volvo recommends that you consult a sories. Check the torque with a torque...

  • Page 341: Changing Wheels - Removing Wheels

    09 Wheels and tyres Changing wheels - removing wheels load retaining eyelets, run the strap diagonally IMPORTANT over the spare wheel and through the upper The car's wheels can be changed for e.g. win- • Never drive faster than 80 km/h with a handle.
  • Page 342 NOTE wheel covers. Use the removal tool to hook in and pull off any full-wheel wheel Volvo recommends only using the jack* that belongs to the car model in question, covers. Alternatively, the wheel covers which is indicated on the jack's label.

  • Page 343: Changing Wheels - Fitting

    09 Wheels and tyres Changing wheels - fitting WARNING WARNING It is important that the procedure for fitting Never position anything between the Never crawl under the car when it is raised the wheel is carried out correctly. ground and the jack, nor between the jack on the jack.

  • Page 344: Warning Triangle

    When changing to another tyre dimension Applies to cars with tyre pressure monitor- : Contact an authorised Volvo workshop for updating the software at each change of tyre dimension. A software download may be necessary both when changing to larger and smaller dimensions, and also when switching between summer and winter wheels.

  • Page 345: Tools

    09 Wheels and tyres Tools NOTE Amongst other things, the car contains towing If the car has been locked with privacy eye, jack* and wheel wrench*. locking then the boot lid/tailgate and floor hatch cannot be opened, see Privacy lock- ing* (p.

  • Page 346: Jack

    09 Wheels and tyres Jack* Applies to Bi-Fuel* cars The tools and jack* must be returned to their correct places after use. The jack needs to be A jack is used to raise the car, e.g. when cranked together to the correct position in changing the tyres.

  • Page 347: First Aid Kit

    09 Wheels and tyres First aid kit* Applies to Bi-Fuel* cars Tyre pressure monitoring* The first aid box contains first aid equipment. Tyre pressure monitoring warns the driver when the pressure is too low in one or more of the car's tyres. For certain markets the tyre pressure monitoring is standard in accord- ance with legal requirements.

  • Page 348: Tyre Pressure Monitoring System (Tpms)* - General

    09 Wheels and tyres • • Tyre pressure monitoring system Tyre pressure monitoring (TPMS)* - acti- Tyre pressure system Service vate/deactivate (p. 349) required (TPMS)* - general • Tyre pressure monitoring (TPMS)* - rec- Both factory-fitted and optional wheels can Tyre pressure monitoring (TPMS) (Tyre ommendations (p.

  • Page 349: Tyre Pressure Monitoring (Tpms)

    09 Wheels and tyres • Tyre pressure monitoring (TPMS)* - acti- Tyre pressure monitoring (TPMS)* 5. Drive for at least 10 minutes at a speed of vate/deactivate (p. 349) at least 30 km/h. adjust (recalibration) • Tyre pressure monitoring (TPMS)* - rec- >...

  • Page 350: Tyre Pressure Monitoring System (Tpms)* - Status

    09 Wheels and tyres Tyre pressure monitoring system error has occurred in the system. Contact NOTE a Volvo dealer or workshop. (TPMS)* - status • The TPMS system uses a so-called Tyre pressure monitoring (TPMS) (Tyre Clearing warning messages compensated pressure value, based...

  • Page 351: Tyre Pressure Monitoring (Tpms)* Activate/Deactivate

    The car must be stationary when the tyre ing winter wheels. refit the dust cap in order to avoid pressure monitoring is activated/deacti- • Volvo recommends that sensors are not damage to the valve from gravel, dirt, vated. moved between different wheels. etc.

  • Page 352: Tyre Pressure Monitoring (Tpms)* Rectifying Low Tyre Pressure

    09 Wheels and tyres Tyre pressure monitoring (TPMS)* Tyre pressure monitoring (TM)* IMPORTANT rectifying low tyre pressure The TM (Tyre Monitor) system senses the If a fault occurs in the TM system the rotation speed of the tyres in order to deter- The tyre pressure monitoring system TPMS warning lamp in the combined instru-...
  • Page 353 : an damage to the valve from gravel, dirt, error has occurred in the system. Contact 3. Select the menu system MY CAR to open a Volvo dealer or workshop. etc. the menus for tyre monitoring. • Only use plastic dust caps. Metal dust 4.

  • Page 354: Emergency Puncture Repair

    The compressor for temporary emergency The sealing fluid bottle must be replaced puncture repair has been tested and before its expiration date and after use. The approved by Volvo. WARNING sealing fluid effectively seals tyres punctured • in the tread.

  • Page 355: Emergency Puncture Repair Kit - Location

    (p. 153) in the tunnel console then no other current consumer may be connected to the other one. NOTE The compressor for temporary emergency puncture repair has been tested and approved by Volvo. Option/accessory, for more information, see Introduction.

  • Page 356: Emergency Puncture Repair Kit - Overview

    09 Wheels and tyres Emergency puncture repair kit - Emergency puncture repair - Related information overview • operation Emergency puncture repair kit - location (p. 353) Overview of the component parts of the Sealing a puncture with the emergency punc- •...
  • Page 357 30 seconds. 6. Connect the hose from the compressor to been used. Volvo recommends that you the valve. visit an authorised Volvo workshop for inspection of the sealed tyre (maximum 9.

  • Page 358: Emergency Puncture Repair - Rechecking

    09 Wheels and tyres Emergency puncture repair - 10. Switch off the compressor to check the 13. As soon as possible, drive approximately rechecking pressure on the pressure gauge. Mini- 3 km at a maximum speed of 80 km/h so mum pressure is 1.8 bar and maximum that the sealing fluid can seal the tyre.

  • Page 359: Emergency Puncture Repair Kit - Inflating The Tyres

    12 V sockets and start the car. Check the tyre pressure regularly. 4. Start the compressor by flicking the switch to position I. Volvo recommends that the car is driven to the nearest authorised Volvo workshop for the replacement/repair of the damaged tyre.

  • Page 360: Emergency Puncture Repair Kit - Sealant

    09 Wheels and tyres Emergency puncture repair kit - IMPORTANT sealant Risk of overheating. The compressor must The container (bottle) with the emergency not run for more than 10 minutes. puncture repair kit (p. 354) contains sealant and it can be replaced. 5.

  • Page 361: Type Approval - Tyre Pressure Monitoring (Tpms)

    09 Wheels and tyres Type approval - tyre pressure monitoring (TPMS) Type approval of the sensors in tyre pressure monitoring - TPMS (Tyre Pressure Monitoring System)* can be read in the table. Option/accessory, for more information, see Introduction.
  • Page 362 09 Wheels and tyres Country/Area Brazil Ukraine...
  • Page 363 09 Wheels and tyres Country/Area Israel...
  • Page 364 09 Wheels and tyres Declaration of Conformity (Declaration of Conformity) Country/ Area Countries in the EU: Exporting country: Germany Manufacturer: Continental Automotive GmbH Type of equipment: TPMS unit...
  • Page 365 09 Wheels and tyres Country/ Area Czech Repub- Continental tímto prohlašuje, že tento Radio Transmitter je ve shodě se základními požadavky a dalšími příslušnými lic: ustanoveními směrnice 1999/5/ES. Denmark: Undertegnede Continental erklærer herved, at følgende udstyr Radio Transmitter overholder de væsentlige krav og øvrige relevante krav i direktiv 1999/5/EF.
  • Page 366 09 Wheels and tyres Country/ Area Malta: Hawnhekk, Continental, jiddikjara li dan Radio Transmitter jikkonforma mal-ħtiġijiet essenzjali u ma provvedimenti oħrajn relevanti li hemm fid-Dirrettiva 1999/5/EC. Hungary: Alulírott, Continental nyilatkozom, hogy a Radio Transmitter megfelel a vonatkozó alapvetõ követelményeknek és az 1999/5/EC irányelv egyéb elõírásainak.
  • Page 367 M A I N T E N A N C E A N D S E R V I C E...

  • Page 368: 10 Maintenance And Service

    Register a Volvo ID. For more information tem to communicate via the car's screen, repair (p. 380) and how to create a Volvo ID, see Volvo notifications/pop-up messages must be ID (p. 21). accepted. In the normal view for the MY •...
  • Page 369 • - A booking enquiry is sent to your Vehicle data are sent to a central Volvo data- dealer who then comes back with a You can also book a workshop visit via My base (not your dealer) from which Volvo deal- booking proposal.

  • Page 370: Inspection And Service Of The System For Vehicle Gas

    The system for vehicle gas must be inspected will be sent. Vehicle data information consists regularly by an authorised workshop - an of information within the following areas: authorised Volvo workshop is recommended. • service requirement WARNING •...

  • Page 371: Raising The Car

    NOTE Volvo recommends only using the jack that belongs to the car model in question. If a jack is selected other than the one recom- mended by Volvo, follow the instructions...
  • Page 372 10 Maintenance and service Jacking points (arrows) for the jack that belongs to the car and lifting points (marked in red). If the car is raised with a front workshop jack then this must be positioned under one of the four lifting points furthest in under the car.

  • Page 373: Bonnet - Opening And Closing

    10 Maintenance and service Bonnet - opening and closing Engine compartment - overview Move the catch to the left and open the bonnet. (The catch hook is located The bonnet can be opened when the handle The overview shows some service-related between the headlamp and radiator grille, in the passenger compartment has been components.

  • Page 374: Engine Compartment - Checking

    (p. 81). Always have the engine cleaned by a Do not touch the spark plugs or ignition workshop - an authorised Volvo workshop coil when the car's electrical system is in is recommended. There is a risk of fire if key position II or when the engine is hot.

  • Page 375: Engine Oil - General

    Volvo recommends that oil changes are carried out at an authorised Volvo work- shop. Volvo uses different systems for warning of low/high oil level or low oil pressure. Certain...

  • Page 376: Engine Oil - Checking And Filling

    Using oil of a higher than specified grade is Engine with oil dipstick permitted. If the car is driven in adverse con- ditions, Volvo recommends using an oil of a higher grade; see Engine oil - adverse driving conditions (p. 426).
  • Page 377 Oil service required If the message fold due to the risk of fire. shown, visit a workshop - an authorised Volvo workshop is recommended. The oil level may be too high. Engines with electronic oil level sensor do not have a dipstick.
  • Page 378 10 Maintenance and service Engine with electronic oil level sensor, 2. Rotate the thumbwheel on the left-hand IMPORTANT Oil level stalk switch to position 5-cyl. diesel If notified of low oil level, only fill with the > You will then see information displayed volume specified, for example, 0.5 litres.
  • Page 379 - an authorised • Engine oil - general (p. 373) If the oil level needs to be checked then it Volvo workshop is recommended. The oil level may be too high. should be carried out in accordance with the following sequence.

  • Page 380: Coolant - Level

    Check the coolant regularly about water quality, used ready-mixed The level must be between the MIN and MAX coolant in accordance with Volvo rec- ommendations. marks on the expansion tank. If the system is not filled sufficiently, high temperatures could •...

  • Page 381: Brake And Clutch Fluid - Level

    Volvo recommends that the reason for the loss of brake fluid is investigated by an Check the level frequently. The fluid does not authorised Volvo workshop.

  • Page 382: Climate Control System - Fault Tracing And Repair

    Use ultraviolet light when looking for leaks. for some other reason, except at a work- shop Volvo recommends that you contact an • authorised Volvo workshop. Active Xenon headlamps - ABL (Xenon lamps) WARNING •...

  • Page 383: Lamp Replacement - Headlamps

    NOTE IMPORTANT If an error message remains after the bro- ken bulb has been replaced then we rec- Do not pull the electrical cable, only the ommend that you visit an authorised Volvo connector. workshop.

  • Page 384: Lamp Replacement - Cover For Main/ Dipped Beam Bulbs

    10 Maintenance and service Lamp replacement - cover for main/ 1. Plug in the connector, a clicking sound dipped beam bulbs should be heard. Main/dipped beam bulbs are accessed by 2. Reinstall the headlamp and locking pins. releasing the headlamp's larger cover. The short pin is fitted closest to the radia- tor grille.

  • Page 385: Lamp Replacement - Dipped Beam

    10 Maintenance and service • Lamp replacement - dipped beam Lamp replacement - main beam Lamp replacement - main beam (p. 383) • The dipped beam bulb is fitted inside the The main beam bulb is fitted inside the head- Lamp replacement - extra main beam (p.

  • Page 386: Lamp Replacement - Extra Main Beam

    10 Maintenance and service Lamp replacement - extra main beam Lamp replacement - direction Lamp replacement - rear lamp indicators front The extra main beam bulb is fitted inside the Rear direction indicators, rear fog lamp and headlamp's larger cover. The direction indicator lamp is fitted inside reversing lamp are replaced from inside the cargo area.

  • Page 387: Lamp Replacement - Location Of Rear Lamps

    10 Maintenance and service Lamp replacement - location of rear Lamp replacement - number plate 6. Press down the catch when the bulb lamps lighting holder is refitted. The overview shows the location of the lamps The number plate lighting is located under the 7.

  • Page 388: Lamp Replacement - Lighting In Cargo Area

    10 Maintenance and service Lamp replacement - lighting in cargo Lamp replacement - vanity mirror Related information area lighting • Lamps - specifications (p. 387) The cargo area lighting is located in the tail- The vanity mirror's lamps are fitted inside the gate.

  • Page 389: Lamps - Specifications

    10 Maintenance and service Lamps - specifications Wiper blades Lighting Type The specifications apply to bulbs. When The wiper blades sweep water away from the replacing LED and Xenon lamps, please refer windscreen and rear window. Together with to a workshop. the washer fluid they clean the windows and Reversing lamp P21W LL...
  • Page 390 10 Maintenance and service Replacing the wiper blades 1. Insert the remote control key in the igni- Fold up the wiper arm when it is in serv- ice position. Press the button located on tion switch and briefly press the the wiper blade mounting and pull START/STOP ENGINE button to set the straight out parallel with the wiper arm.

  • Page 391: Washer Fluid - Filling

    10 Maintenance and service Washer fluid - filling Cleaning NOTE For cleaning wiper blades and windscreen, Washer fluid is used for cleaning the head- The wiper blades are different lengths. The see Car wash (p. 410). lamps and windows. Washer fluid with anti- blade on the driver's side is longer than on freeze must be used when the temperature is the passenger side.

  • Page 392: Starter Battery - General

    Starter battery - general Prescribed grade: Washer fluid recom- IMPORTANT mended by Volvo - with frost protection dur- The starter battery is used to drive the starter When replacing the starter battery, in cars ing cold weather and below freezing point.
  • Page 393 10 Maintenance and service WARNING IMPORTANT NOTE • The battery can generate oxyhydrogen If the following instruction is not observed The life of the battery is shortened if it then the energy saving function for info- becomes discharged repeatedly. gas, which is highly explosive. A spark tainment system may be temporarily dis- can be formed if a jump lead is con- The life of the battery is affected by several...

  • Page 394: Battery - Symbols

    10 Maintenance and service Battery - symbols Starter battery - replacement Avoid sparks and naked There are information and warning symbols The starter battery in the car can be replaced flames. on the batteries. without the help of a workshop. Symbols on the batteries The starter battery is a traditional 12 V bat- tery.
  • Page 395 10 Maintenance and service Cross-stay on the R-Design* Remove the rear cover by screwing one quarter turn and lifting it away. WARNING Connect and remove the positive and neg- ative cables in the correct order. Detach the black negative cable. Detach the red positive cable.

  • Page 396: Battery - Start/Stop

    10 Maintenance and service Battery - Start/Stop For more information on the car's starter bat- NOTE tery, see Jump starting with battery (p. 280). Cars with the Start/Stop function are equip- Tighten the screws to 30 Nm. Check the ped with a support battery in addition to the torque with a torque wrench.
  • Page 397 10 Maintenance and service NOTE Battery Battery • The higher the current take-off in the Start, 12 V Support, 12 Start, 12 V Support, 12 car, the more the alternator must be working and the batteries charging = Increased fuel consumption. Left-hand Left-hand •...
  • Page 398 - an authorised nal battery charger. Volvo workshop is recommended. If this is not possible then the recommen- dation is to temporarily deactivate the Start/Stop function until the battery has been adequately recharged.

  • Page 399: Electrical System

    If function. the same fuse fails repeatedly then there is a fault in the circuit. Volvo recommends that IMPORTANT you visit an authorised Volvo workshop for checking.
  • Page 400 10 Maintenance and service • Fuses - in cargo area (p. 407) • Fuses - in the engine compartment's cold zone (p. 408)

  • Page 401: Fuses - In Engine Compartment

    10 Maintenance and service Fuses - in engine compartment Fuses in the engine compartment protect engine and brake functions, amongst other things.
  • Page 402 • Fuses 16-33 and 35-41 are of the "Mini Fuse" type. Windscreen wipers Headlamp control Parking heater* Ventilation fan Heated windscreen* , right- hand side An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 403 10 Maintenance and service Function Function Function Glow control module (5-cyl. Solenoid clutch A/C (5, 6-cyl.); diesel) Valves (5, 6-cyl.); Engine con- Relay coils trol module (6-cyl.); Mass air Engine control module (4-cyl.); flow sensor (5-cyl. petrol); Oil Ignition coils (5, 6-cyl. petrol); Auxiliary lamps* level sensor Capacitor (6-cyl.)
  • Page 404 10 Maintenance and service Function Control module, radiator roller cover (5-cyl. petrol) Solenoid clutch A/C (4-cyl.); Glow control module (4-cyl. diesel); Oil pump (4-cyl. diesel) Crankcase ventilation heater (5-cyl. diesel); Oil pump auto- matic gearbox (5-cyl. diesel Start/Stop) Coolant pump (4-cyl. petrol) Glow plugs (diesel) Cooling fan (4 - 5-cyl.

  • Page 405: Fuses - Under Glovebox

    10 Maintenance and service Fuses - under glovebox Fuses under the glovebox protect the info- tainment system and seat functions, amongst other things. Positions Function Function Function Control panel, rear passenger door, right Primary fuse for audio control Door handle (Keyless*) module*;...
  • Page 406 10 Maintenance and service Function Function Parking assistance*; Parking camera*; BLIS* Infotainment Control Module AWD control module* or Screen Active chassis Four-C* Audio control unit (amplifier)*; TV*; Digital radio* Ampere Certain model variants. Audio control module or Con- trol module Sensus Related information •...

  • Page 407: Fuses - In The Control Module Under The Glovebox

    10 Maintenance and service Fuses - in the control module under the glovebox Fuses in the control module under the glove- box protect airbag and collision warning sys- tem functions, amongst other things. Positions Function Function Function Adaptive cruise control, ACC*; Heated steering wheel* collision warning system* Rear window wiper...
  • Page 408 10 Maintenance and service • Fuses - in the engine compartment's cold Function zone (p. 408) Movement detector alarm*; Climate panel Steering lock Siren*; Data link connector OBDII Airbags Collision warning system* Accelerator pedal sensor; Dimming interior rearview mir- ror*; Seat heating, rear* Infotainment control module (Performance);...

  • Page 409: Fuses - In Cargo Area

    10 Maintenance and service Fuses - in cargo area Fuses in the cargo area protect the electric parking brake, amongst other things. Positions Related information Function • Fuses - in engine compartment (p. 399) Function • Fuses - under glovebox (p. 403) Electric parking brake, left •...

  • Page 410: Fuses - In The Engine Compartment's Cold Zone

    • Fuse 12 is of the "Mini Fuse" type. For more information on Start/Stop - see Electric additional heater* Start/Stop* (p. 291). An authorised Volvo workshop is recommended. Option/accessory, for more information, see Introduction.
  • Page 411 10 Maintenance and service • Fuses - in the control module under the Function glovebox (p. 405) • Primary fuse for the central Fuses - in cargo area (p. 407) electronic module (CEM) under the glovebox Primary fuse for relay/fuse box under the glovebox Heated windscreen* Primary fuse for central elec-...

  • Page 412: Car Wash

    An authorised nozzle does not come closer than 30 cm to for example. Volvo workshop is recommended for the the surface of the car (the distance applies to Do not use any corrosive cleaning agents removal of any discoloration.

  • Page 413: Polishing And Waxing

    Only use rim cleaning agent recommended components Polish first with a polish and then wax with by Volvo. A special cleaning agent available from Volvo liquid or solid wax. Follow the instructions on dealers is recommended for the cleaning and the packaging carefully. Many preparations...

  • Page 414: Water And Dirt-Repellent Coating

    Water and dirt-repellent coating* paintwork. Paintwork damage caused by There is natural wear of the water- such treatments is not covered by Volvo warranty. repellent coating. Maintenance: Related information •...

  • Page 415: Rustproofing

    Inspection and maintenance ours of the leather shall be preserved. Volvo stain the upholstery. If this occurs, it is The car's anti-corrosion protection does not offers a comprehensive product, Volvo...

  • Page 416: Paint Damage

    A special cleaning agent Car wash (p. 410) Paint is an important part of the car's rust- available from Volvo dealers can be used for proofing and should therefore be checked more difficult cleaning. regularly. The most common types of paint-...
  • Page 417 10 Maintenance and service • Repairing minor paint damage such as Primer - a special adhesive primer in a 2. Before painting, gentle polishing using a spray can is available for e.g. plastic- very fine polishing agent may be carried stone chips and scratches coated bumpers.
  • Page 418 S P E C I F I C A T I O N S...

  • Page 419: 11 Specifications

    11 Specifications Type designations Type designation, vehicle identification num- ber, etc., i.e. information unique to the car, can be read on a label in the car.
  • Page 420 Knowing the car's type designation, vehicle dealer regarding the car and when ordering Type designation, vehicle identification identification and engine numbers can facili- spare parts and accessories. number, permissible maximum weights tate all contact with an authorised Volvo and code designation for exterior colour...
  • Page 421 11 Specifications and type approval number. The decal is positioned on the door pillar, and will be visible when the right-hand rear door is opened. Label for A/C system. Label for parking heater. Engine code and engine serial number. Label for engine oil. Gearbox type designation and serial num- ber.

  • Page 422: Dimensions

    11 Specifications Dimensions Measurement of car length, height, etc. can be read in the table. Dimensions Dimensions Dimensions Wheelbase 2776 Front track Width including door mirrors 2097 1588 1578 Length 4635 Width including folded-in door mirrors 1899 Rear track Load length, floor, folded rear 1585 seat 1749...

  • Page 423: Weights

    11 Specifications Weights WARNING Max. gross vehicle weight, etc. can be read The car's driving characteristics change on a label in the car. depending on how heavily it is loaded and how the load is distributed. Kerb weight includes the driver, the fuel tank 90% full and all fluids.

  • Page 424: Towing Capacity And Towball Load

    11 Specifications Towing capacity and towball load Max. weight braked trailer Towing capacity and towball load for driving NOTE with a trailer can be read in the tables. Not all engines are available in all markets. Gearbox Max. weight braked trailer (kg) Max.
  • Page 425 11 Specifications Gearbox Max. weight braked trailer (kg) Max. towball load (kg) Engine code Engine D4 AWD D5244T21 Automatic, TF-80SD 1800 D4204T11 Automatic, TG-81SC 1800 Engine code, component and serial number can be read on the engine; see Type designations (p. 417). Max.

  • Page 426: Engine Specifications

    11 Specifications Engine specifications NOTE Engine specifications (output etc.) for each Not all engines are available in all markets. respective engine alternative can be read in the table. Output Output Torque No. of cyl- Bore Stroke Swept vol- Compres- Engine code inders sion ratio Engine...
  • Page 427 11 Specifications Related information • Coolant - grade and volume (p. 429) • Engine oil - grade and volume (p. 427)

  • Page 428: Engine Oil - Adverse Driving Conditions

    Volvo Car Corporation disclaims all war- ranty liability if engine oil of the prescribed grade and viscosity is not used. Volvo recommends that oil changes are carried out at an authorised Volvo work- shop.

  • Page 429: Engine Oil - Grade And Volume

    Engine oil - grade and volume NOTE Engine oil grade and volume for each respec- Not all engines are available in all markets. tive engine alternative can be read in the table. Volvo recommends: Oil grade Volume, incl. oil filter Engine code Engine (litres)
  • Page 430 11 Specifications Oil grade Volume, incl. oil filter Engine code Engine (litres) D4204T8 Castrol Edge Professional V 0W-20 or VCC RBS0-2AE 0w20 approx 5.2 D4204T20 approx 5.2 D4204T9 approx 5.2 D4204T14 approx 5.2 D4204T11 approx 5.2 D4 AWD D5244T21 Oil grade: ACEA A5/B5 approx.

  • Page 431: Coolant - Grade And Volume

    Approved coolant volume for each respective (litres) Engine engine alternative can be read in the table. D4204T8 8,9 (9,2 Prescribed grade: Coolant recommended by Volvo mixed with 50% water , see the pack- D4204T20 aging. D4204T9 NOTE D4204T14 Not all engines are available in all markets.

  • Page 432: Transmission Fluid - Grade And Volume

    11 Specifications Transmission fluid - grade and volume The prescribed transmission fluid and volume for each respective gearbox alternative can be read in the table. Manual gearbox Manual gearbox Volume (litres) Prescribed transmission fluid approx. 1.45 BOT 350M3 NOTE The gearbox oil does not need to be changed under normal driving conditions.
  • Page 433 11 Specifications NOTE The gearbox oil does not need to be changed under normal driving conditions. However, it may be necessary under adverse driving conditions. Related information • Engine oil - adverse driving conditions (p. 426) • Type designations (p. 417)

  • Page 434: Brake Fluid - Grade And Volume

    Prescribed grade: Power steering fluid rec- which in turn act on a mechanical brake. ommended by Volvo. Prescribed grade: DOT 4 Related information Volume: 0.6 litres •...

  • Page 435: Fuel Tank - Volume

    11 Specifications Fuel tank - volume Fuel tank volume for each respective engine alternative can be read in the table. Engine Volume (litres) Prescribed grade Petrol engine approx 67 Fuel - petrol (p. 314) Diesel engine approx 67 Fuel - diesel (p. 314) Vehicle gas tank (CNG) - applies to Bi- Fuel Tank volume...

  • Page 436: Specifications For Air Conditioning

    11 Specifications Specifications for air conditioning Compressor oil Prescribed grades and volumes of fluids and Engine Volume Prescribed lubricants in the air conditioning system can grade be read in the tables below. 4-cylinder 60 ml PAG SP-A2 A/C decal 5-cylinder 110 ml PAG SP-10 Related information...

  • Page 437: Fuel Consumption And Co2 Emissions

    11 Specifications Fuel consumption and CO2 emissions Urban driving manual gearbox Fuel consumption in a vehicle is measured in litres per 100 km and CO2 emissions in grams Extra-urban driving Automatic gearbox per km. Combined driving Explanation NOTE gram/km If the consumption and emission data is missing then it is included in the enclosed supplement.
  • Page 438 11 Specifications T5 (B4204T11) T6 (B4204T9) (D4204T8) (D4204T8) (D4204T20) (D4204T20) (D4204T9) (D4204T9) (D4204T9) (D4204T9) (D4204T14)
  • Page 439 11 Specifications (D4204T14) (D4204T14) (D4204T14) D4 AWD (D5244T21) D5 (D4204T11) Does not apply to the low-emissions variant. This only applies to the low-emissions variant. • Fuel consumption and emission values in the There are several reasons for increased fuel High speed results in increased wind resistance.
  • Page 440 11 Specifications CO2 emissions and fuel consumption consumption. For further information, please NOTE refer to the regulations referred to (vehicle gas - CNG) - for Bi-Fuel • There are many different qualities of Large deviations in fuel consumption may gas, as well as gases with lower arise in a comparison with the EU driving energy content and range.

  • Page 441: Tyres - Approved Tyre Pressures

    11 Specifications Tyres - approved tyre pressures NOTE Approved tyre pressures for each respective All engines, tyres or combinations of these engine alternative can be read in the table. are not always available in all markets. Tyre size Speed Load, 1-3 persons Max.
  • Page 442 11 Specifications Tyre size Speed Load, 1-3 persons Max. load ECO pressure Engine (km/h) Front Rear Front Rear Front/rear (kPa) (kPa) (kPa) (kPa) (kPa) 0 - 160 215/55 R 16 235/45 R 17 160 + T6 (B4204T9) 205/60 R 16 0 - 160 D5 (D4204T11) 215/50 R 17...
  • Page 443 11 Specifications...

  • Page 444: 12 Alphabetical Index

    12 Alphabetical Index Additional heater checking the alarm......168 electric........147, 148 reduced alarm level......187 ACC – Adaptive cruise control....204 fuel-driven........... 147 remote control key not working..186 Active Bending Lights (ABL)...... 96 Adjusting the steering wheel...... 87 Alcohol lock..........
  • Page 445 12 Alphabetical Index remote control key/PCC..... 172 Bulbs, see Lighting........381 Child safety locks......183, 184 symbols on the battery....... 392 Child seat warning symbols......... 392 integrated two-stage booster seat..50 Bi-fuel Child seats..........43 introduction........... 24 ISOFIX fixture system for child seats... 53 Camera sensor........
  • Page 446 12 Alphabetical Index Collision warning......229, 230 managing speed......... 202 Display lighting.......... 90 resume set speed....... 203 Collision warning system Distance Warning........219 temporary deactivation....... 202 function..........230 Limitations.......... 220 general limitations....... 234 CTA............266 Symbols and messages..... 221 operation..........233 Cyclist detection........
  • Page 447 12 Alphabetical Index Electrical socket........153 Engine block heater and passenger com- cargo area........... 157 partment heater direct start.......... 142 Electrical system........397 immediate stop........143 ECC............ 135 Electric parking brake Engine braking, automatic....... 290 Fault tracing for the camera sensor..225 low battery voltage......
  • Page 448 12 Alphabetical Index Fuel tank Glovebox..........152 Heat-reflecting windscreen......19 volume..........433 locking..........180 High engine temperature......309 Fuse box..........397 Gross vehicle weight....... 421 High-pressure headlamp washing... 103 Fuses............397 GSI - Gear selector assistance....282 Hill Descent Control......... 290 cargo area...........
  • Page 449 12 Alphabetical Index Interior rearview mirror......107 in the passenger compartment..... 99 automatic dimming......107 main/dipped beam....... 92 Labels............417 position/parking lamps......91 Intermittent wiping........102 rear fog lamp........97 Laminated glass......... 24 Internet-connected car tunnel detection........92 book service and repair...... 366 Lamps, see Lighting........
  • Page 450 12 Alphabetical Index Lock indicator.......... 164 Driver Alert Control......241 Engine block heater and passenger Locking/unlocking compartment heater......145 PACOS............34 glovebox..........180 Lane Departure Warning..... 245 inside..........179 Paddle on the steering wheel....87 LKA............. 250 tailgate..........181 Paintwork Messages in BLIS........
  • Page 451 12 Alphabetical Index Pinch protection, sunroof......110 Rear bulbs Remote control key system, type appro- location..........385 val............187 Pocket park assist - PAP......258 Rear seat Remote Start - ERS......... 277 Polishing..........411 Heating..........134 Resetting, trip meter......118, 122 Position/parking lamps......
  • Page 452 12 Alphabetical Index putting on..........28 Speed limiter..........198 Storage spaces in the passenger com- rear seat..........30 alarm for speed exceeded....200 partment..........150 seatbelt reminder........30 deactivation........200 Sunroof seatbelt tensioner......... 30 getting started......198, 199 opening and closing......109 temporary deactivation.......
  • Page 453 12 Alphabetical Index Trailer............319 Type designations........417 cable........... 319, 320 Tyre dimension........336 Tailgate driving with a trailer......319 Tyre load index........337 Locking/unlocking......181 snaking..........326 Tyre pressure label........334 Temperature Trailer stability assist....... 191 Tyre pressure monitoring. 345, 346, 348, 350 actual temperature......
  • Page 454 103 Ventilation..........131 washer fluid, filling......389 Winter driving........... 311 Vibration damper........322 windscreen......... 102 Winter tyres..........338 Volvo ID............. 21 Water and dirt-repellent coating....412 Wiper blades..........387 Volvo Sensus..........79 Water-repellent surface, cleaning.... 412 changing..........388 Cleaning..........389 Waxing.............
  • Page 456 TP 18918 (English), AT 1517, MY16, Printed in Sweden, Göteborg 2015, Copyright © 2000-2015 Volvo Car Corporation...

Table of Contents
