Page 1: Table Of Contents
Overview IR Sensor Software Setting & Recalling Scenes Buttons For use with Lowel/ Fluo-Tec Studio Fluorescent System ® IR DMX Controller Instructions Buttons/Arrows Using The IR DMX Controller Replacing Batteries Preparing for Use Warranty, Problems, Repairs & Info Back Cover...
Page 2: Overview
The words “Scene Mode?” will be displayed on the LCD screen. Pressing the - LEVEL button once will scroll to the installed software version. number of the IR DMX Controller. It is important information in case technical support is needed. In addition, the Controller will allow storage of up to 10 “scenes”, with each scene containing...
Page 3: Preparing For Use
Note: In cases where no DMX console is connected, attaching the Sensor automatically gives control of the DMX chain to the IR DMX Controller, provid- ed the Controller has been ‘enabled’ (see pg. 4). If a DMX console is con-...
Page 4: Setting & Recalling Scenes
Press MODE again to store that number & exit mode. 5 Software Version Number. This selection gives the revision number of the software stored in the IR DMX Controller. It is important information in case technical support is needed.
Page 5: Buttons/Arrows
Controller and the IR Sensor unit), the dimmable fixture will be set to a different level than is displayed in the IR DMX Controller LCD. By pressing the SET button, all values will be retransmitted, “re-synchronizing” the dimming levels of the fixtures to the displayed level in the IR DMX Controller.
Page 6: Using The Ir Dmx Controller
Using The IR DMX Controller Important - To use the IR DMX Controller, fluorescent fixtures must first be ‘enabled’. See Sub-Menu Mode, pg 4. 2 line, 8 character Liquid Crystal Display. Buttons Familiarize yourself with the location of the control buttons. Some buttons control more than one function.
Page 7: Setting & Recalling Scenes
Values as the fixtures are set to the values of the scene. 3 Close the battery compartment. 4 After turning the IR DMX Controller back ON, point it at the IR Sensor and press the SET button a few times.
Page 8: Warranty, Problems, Repairs & Info
Call: 800 334-3426 or 718 921-0600 Fax: 718 921-0303 e-mail info@lowel.com www.lowel.com ® Lowel IR DMX Controller, Lowel IR Sensor, IR DMX Translator, and Lowel Fluo-Tec Studio Fluorescents are trademarks of Lowel-Light Manufacturing, Inc. Patent Pending version: 3.1 © Lowel-Light Mfg., Inc. 2006...
