Morton MCWF Installation And Operation Manual

Whole home water filtration system
Hide thumbs Also See for MCWF:

Advertisement

Model MCWF
How to install, operate and
maintain your Whole Home
Water Filtration System
Do not return unit to store
If you have any questions or concerns when in-
stalling, operating or maintaining your Whole Home
Water Filtration System, call our toll free number:
1-888-64 WATER
(1-888-649-2837)
Monday - Friday, 8 AM - 7 PM EST
or visit www.systemsaver.com
When you call, please be prepared to provide
the model and serial number of your product,
located on the rating decal on back of the cover.
System tested and certified by NSF International
against NSF/ANSI Standard 42
for the reduction of chlorine taste and odor,
and certified to NSF/ANSI Standard 372.
7339955 (Rev. C 4/11/14)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MCWF and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Morton MCWF

  • Page 1 Model MCWF How to install, operate and maintain your Whole Home Water Filtration System Do not return unit to store If you have any questions or concerns when in- stalling, operating or maintaining your Whole Home Water Filtration System, call our toll free number:...
  • Page 2: Table Of Contents

    If, during such respective period, a part proves to be defective, Morton will ship a replacement part, directly to your home, without charge. Labor necessary to maintain this product is not covered by the product warranty.
  • Page 3: Specifications & Performance Claims

    NSF/ANSI 42. While testing was performed under standard laboratory conditions, actual performance of the system may vary based on local water conditions. SPECIFICATIONS Model MCWF Rated Service Flow Rate 6.0 gpm (22.7 L/min.) Pressure Drop at Rated Service Flow 10 psig (68.9 kPa)
  • Page 4: Dimensions

    Dimensions 12-1/8” 12-1/8" 3-3/8” 13-1/2” 3-3/8" 13-1/2" TOP VIEW TOP VIEW IN – OUT IN - OUT 36-1/8” 36-1/8" 27-5/8” 27-5/8" FIG. 1 SIDE VIEW FRONT VIEW SIDE VIEW FRONT VIEW Morton Installation & Operation Manual ®...
  • Page 5: Inspect Shipment

    (1-888-649-2837) Monday - Friday, 8 am - 7 pm EST. When you call, please be prepared to provide the model and serial number, found on the rating decal on back of the cover. For more installation or service information, visit www.systemsaver.com. Morton Installation & Operation Manual ®...
  • Page 6: Before You Start

    Water Filtration System down the drain. treatment equipment. Although the Whole Home Water Filtration System has sediment filter capabilities, additional sediment filtration may be needed in problem water applica- tions. Morton Installation & Operation Manual ®...
  • Page 7: Installation Requirements

    Untreated Water to Outside Faucets Cold Water to House Hot Water Pressure to House Optional Tank Sediment Filter Well Water Supply Water Whole Home Water Heater Water Softener Well Filtration Pump FIG. 3B System Morton Installation & Operation Manual ®...
  • Page 8 Tie or wire 1-1/2” tubing in air gap place LAUNDRY TUB STANDPIPE Drain grate with 1” dia. hole in center FLOOR DRAIN FIG. 4 Morton Installation & Operation Manual ®...
  • Page 9 Water from Untreated Valve Water to 1” NPT Sweat OUTLET Valve Adapter (2) INLET (not included) Clip (2) 1” NPT Adapter (2) Included Valve To Whole Home Inlet FIG. 5 FIG. 7 Water Filtration System Morton Installation & Operation Manual ®...
  • Page 10: Installation Instructions

    The installation must conform to them. In use a plastic bypass valve at the unit, Massachusetts, plumbing codes of Massachusetts shall be conformed to. continuity is broken. To restore the Consult with your licensed plumber. ground, do the following: Morton Installation & Operation Manual ®...
  • Page 11 2. In the display, the words “PRESENT TIME” appear and 12:00 PM begins to flash. Set the clock accord- ing to the “Set Time of Day” section on Page 12. 3. Run the start up procedure, as detailed on Page 13. Morton Installation & Operation Manual ®...
  • Page 12: Programming The Whole Home Water Filtration System

    Monday- Friday, 8 AM - 7 PM EST or visit www.systemsaver.com When you call, please be prepared to provide the model and serial number, located on the rating decal on back of the cover. Morton Installation & Operation Manual ®...
  • Page 13: Start Up Procedure

    Monday- Friday, 8 AM - 7 PM EST or visit www.systemsaver.com When you call, please be prepared to provide the model and serial number, located on the rating decal on back of the cover. Morton Installation & Operation Manual ®...
  • Page 14: Customizing Features / Options

    UP or DOWN buttons to set the Clean Rinse time. Be sure AM or PM is correct. 4. Press the PROGRAM button again when com- plete. 3. Press the PROGRAM button again when com- plete. Morton Installation & Operation Manual ®...
  • Page 15: Customizing Features / Options

    Clean Rinse cycle when power was 2. When the Clean Rinse cycle is complete, the lost, it will now finish the cycle. Whole Home Water Filtration System will remain in the manual Clean Rinse mode. Morton Installation & Operation Manual ®...
  • Page 16: Care Of Your Whole Home Water Filtration System

    Leave the unit laying like this until you are ready to use it. Plug the inlet and outlet with clean rags to keep dirt, bugs, etc. out. Drain all Water from Whole Home Water Filtration System Wood Block Floor Drain FIG. 22 Morton Installation & Operation Manual ®...
  • Page 17: Troubleshooting

    Monday- Friday, 8 AM - 7 PM EST When you call, please be prepared to provide the model and serial number, located on the rating decal on back of the cover. Morton Installation & Operation Manual ®...
  • Page 18 Monday- Friday, 8 AM - 7 PM EST When you call, please be prepared to provide the model and serial number, located on the rating decal on back of the cover. Morton Installation & Operation Manual ®...
  • Page 19 Notes Morton Installation & Operation Manual ®...
  • Page 20: Whole Home Water Filtration System Components

    Whole Home Water Filtration System Exploded View Valve Assembly See Pages 22 & 23 for parts Morton Installation & Operation Manual ®...
  • Page 21 Mineral Tank, 8” x 25” Ù Ù Activated Carbon, 10 lbs. Filter Sand, 5 lbs. Ù Ù Gravel, 6 lbs. Outer Shroud Tank, with Morton Badge Ù 7310781 Faceplate Decal 7310773 Cover (order decal above) 7311020 Repl. Electronic Control Board (PWA)
  • Page 22 Valve Assembly Exploded View Wear Strip Seal Cross-section View Morton Installation & Operation Manual ®...
  • Page 23 Monday- Friday, 8 AM - 7 PM EST or visit www.systemsaver.com When you call, please be prepared to provide the model and serial number, located on the rating decal on back of the cover. Morton Installation & Operation Manual ®...
