Summary of Contents for FUHR NB649N
- Page 1 WWW.FUHR.DE autotronic multitronic Radio Fingerprint Scanner NB649N Installation and operation instructions These instructions are to be passed on by the fi tter to the user. www.fuhr.de...
-
Page 2: Table Of Contents
Green LED fl ashes. Important information; Red LED fl ashes. please note. Green LED lights up, red LED fl ashes. For this manual in other languages see www.fuhr.de 2 sec. Green LED lights up for 2 sec. www.fuhr.de WWW.FUHR.DE... -
Page 3: Applications
fi nger print scanner can be used to control e.g. garage doors. We offer a mains-operated plug socket radio receiver and a universal radio receiver for this purpose. FUHR radio fi ngerprint scanner NB649N with fl at stainless steel cover Motor lock with control... -
Page 4: Important Advice
General advice on the reading capability of human fi ngerprints Humans’ fi ngerprints have by nature different distinct characteristic-curves. Despite the fact that the FUHR radio fi ngerprint scanner has been equipped with the most modern and safest detection methods, it cannot be ruled out, that some peoples’... -
Page 5: Maximum Number Of Tuned In Fi Ngerprints
Max. 200 pieces (100 per channel) Housing dimensions: 55 x 36 x 42 mm (H x W x D) Cover dimensions: 91 x 40 x 2.5 mm (H x W x D) 12 V DC cable length: 1600 mm WWW.FUHR.DE... -
Page 6: Installation Advice
Delivery scope Terminal connection diagrams • Radio fi ngerprint scanner with fl at stainless Radio fingerprint scanner NB649N steel cover and connection cable (1600 mm) on the outside of the door • 4 fi xing screws M3 x 8 mm for aluminium + steel •... -
Page 7: Routing Dimensions/Drilling Jig
Before fi tting, remove the protective fi lm from the adhesive surfaces. Press the cover fi rmly in place. Use the cleaning cloth provided to clean the areas to which the adhesive will be applied WWW.FUHR.DE... -
Page 8: Commissioning
As a result you have the possibility of controlling two different devices: Channel 1 for the multitronic/autotronic-main entrance door Channel 2 for another multitronic/autotronic door or, in conjunction with the FUHR radio receiver for a moto- rised garage door drive unit or e.g. an electrical yard gate. -
Page 9: Tuning In And Deleting
The master-fi ngers cannot be used to open doors; they serve only as programming fi ngerprints to tune in or delete user-fi ngers. Should you select other fi ngerprints as master- fi ngers, please make a note of this as a reminder on page 15, chapter 8 of the operating instructions. WWW.FUHR.DE... -
Page 10: Tuning In User-Fi Ngers To Open The Motor-Lock Door
Maximum 200 user-fi ngers (100 per channel) can be tuned in! You can also tune in the same user-fi nger several times to increase the detection rate. (We recommend tuning in every user-fi nger 3 times consecutively! To do so, simply repeat the described steps.) WWW.FUHR.DE... -
Page 11: Tuning In The Radio Fi Ngerprint Scanner To A Multitronic/Autotronic Control With Radio Receiver
Radio receiver modul and visual locking display NBFP490 A Tune-in button B Green LED C Red LED D Master radio key WWW.FUHR.DE... -
Page 12: Deleting Individual User-Fi Ngers
fi ngerprints via the software reset with the aid of the master-fi nger in compliance with the instructions on page 14, chapter 7.3! After this new master- and user-fi ngers are tuned in. WWW.FUHR.DE... -
Page 13: Tamper Protection
30 seconds while the reset button is depressed, the red and green LED fl ashes. After the expiration of the required 30 seconds, the green LED lights up for 10 seconds. Now release the button, if both LED’s light up permanently this indicates that the device is now back in its ex-works condition. WWW.FUHR.DE... -
Page 14: Resetting The Radio Fi Ngerprint Scanner With A Master-Fi Nger: Delete All Fi Ngers
fi ngerprint scanner. If this is not possible, use the reset button’s delete function (page 13, chapter 7.2). WWW.FUHR.DE... -
Page 15: Fingerprint Allocation For Master- And User-Fi Ngers
User Channel 2 Master Channel 1 User Channel 2 Master Channel 1 User Channel 2 Master Channel 1 User Channel 2 Master Channel 1 User Channel 2 Master Channel 1 User Channel 2 Master Channel 1 User Channel 2 WWW.FUHR.DE... - Page 16 CARL FUHR GmbH & Co. KG Carl-Fuhr-Straße 12 D-42579 Heiligenhaus Tel.: +49 2056 592-0 Fax: +49 2056 592-384 www.fuhr.de · info@fuhr.de...
