DMX-controlled operation

You can control the projectors individually via your DMX-controller. Every DMX-channel has a different
occupation with different features.

Addressing

The Control Board allows you to assign the DMX fixture address, which is defined as the first channel from
which the LED ARRAY Bar will respond to the controller.
For address setting, press the MODE button until the display shows "A001". The desired values can be
selected via the UP or DOWN buttons.
Controlling:
After having addressed the LED ARRAY DMX Lighting Controller, you may now start operating it via your
lighting controller.
Note:
After switching on, the LED ARRAY DMX Lighting Controller will automatically detect whether DMX 512 data
is received or not. If the data is received, the control LED flashes. If there is no data received at the DMX-
input, the control LED lights up permanently.
This situation can occur if:
- the 3 PIN XLR plug (cable with DMX signal from controller) is not connected with the input of LED ARRAY
DMX Lighting Controller.
- the controller is switched off or defective, if the cable or connector is defective or the signal wires are swap
in the input connector.
Note:
It's necessary to insert the XLR termination plug (with 120 Ohm) in the last device in the link in order to
ensure proper transmission on the DMX data link.

CLEANING AND MAINTENANCE

We recommend a frequent cleaning of the device. Please use a soft lint-free and moistened cloth. Never use
alcohol or solvents!
There are no servicable parts inside the device except for the fuse. Maintenance and service operations are
only to be carried out by authorized dealers.

Replacing the fuse

If the fine-wire fuse of the device fuses, only replace the fuse by a fuse of same type and rating.
Before replacing the fuse, unplug mains lead.
Procedure:
Step 1: Open the fuseholder on the rearpanel with a fitting screwdriver.
Step 2: Remove the old fuse from the fuseholder.
Step 3: Install the new fuse in the fuseholder.
Step 4: Replace the fuseholder in the housing.
Should you need any spare parts, please use genuine parts.
If the power supply cable of this device becomes damaged, it has to be replaced by a special power supply
cable available at your dealer.
DANGER TO LIFE!
Disconnect from mains before starting maintenance operation!
18/19 51913060_V_1_0.DOC
