Summary of Contents for Unifore VS-WJP1
- Page 1 Wireless keypad User manual Please read this user manual carefully before operate keypad. Please keep this user manual properly for accessible reference.
-
Page 2: Table Of Contents
Table of Contents Product Introduction Keypad usage Preface Away arm List of items Disarm Keypad Status instruction Home/Stay arm Product structure chart Doorbell Preparation before usage Precautions Power-on Cautions Coding keypad with alarm panel Maintenance Keypad installation Function setting Frequently asked questions Enter setting status Technical parameters Set arm delay... -
Page 3: Preface
Keypad Status instruction Preface Thanks for your purchase. This keypad can be installed at the 1.Normal working status: the LED will light on 3 seconds if user press entrance. By input password, users can easily operate the keypad to any numeric keys. After 3 seconds, the LED will light off automatically fulfill functions such as away arm, disarm, home arm, doorbell, RFID if there is no further operation. - Page 4 The keyboard structure RFID swiping tag zone Buzzer Home arm button Tamperproof Away arm button switch Disarm button Doorbell Positive and Negative electrode for battery RFID startup button Users can buy more RFID tag, one keypad can work with maximum 60pcs tags.
-
Page 5: Preparation Before Usage
Preparation before usage Power-on Default user password:1111 Keypad installation The keypad should be installed on the door or wall before usage. Unscrew the screws , open the base and put batteries in keypad. Assemble keypad well, tighten the screws Fix the setscrews on the door/window/wall 1.The keypad work with three AAA batteries. -
Page 6: Coding And Deleting The Rfid Tag
Coding and deleting the RFID tag Set RFID tag to disarm function setting Coding the RFID tag: Users can open and close the function of swipe RFID tag to disarm. Open the function of swipe RFID tag to disarm: Enter【 *+password+8+#】 into learning status→ 4-digits password, the default password is 1111. -
Page 7: Keypad Usage
Keypad usage Disarm Users can disarm via RFID tag and keypad. As a kind of accessory in alarm system, keypad is a terminal control tool Keypad disarm and it can replace remote controllers. Users need input users’ password Enter【 *+password + Disarm button】 → 4-digits password, the or Administrator password to use keypad control panel. -
Page 8: Home/Stay Arm
Stay arm Precautions Users can Stay Arm alarm panel when at home. Users need to follow below items in order to make the keypad have longer Enter【*+password + Stay Arm button】→ 4-digits password, the default working life, and also to prevent injury to users and others during password is 1111. -
Page 9: Frequently Asked Questions
Frequently asked questions Technical parameters Phenomenon Cause Solution Product name: wireless keypad Low voltage Change battery No reaction Work power: Install Batteries during operation Install batteries in right way wrongly in keypad Three AAA batteries Ensure panel has turned on Standby current: No action on alarm Coding failed... - Page 10 说明书 产品型号 部件名称 Component name Model User manual 设计 材料 克书写纸 Shell writing paper Design Material 印刷尺寸 成品尺寸 Print size Finished size 工艺 骑马钉-32P 版本 Crafts Saddle stitch -32P Version 注：双色、双面印刷 Note: bicolor and dual page print...
