- Page 1 4324MN0011-V1636 REV A OPERATION AND MAINTENANCE MANUAL FOR THE ORE OFFSHORE MODEL 4324C-V1636 MULTIBEACON BATTERY CHARGER ORE Offshore, 4 Little Brook Road, West Wareham, MA 02576 USA Phone: 508-291-0960 Fax: 508-291-0975 http://www.ore.com Copyright ©2001 ORE Offshore All Rights Reserved...
-
Page 2: Table Of Contents
4324C-V1636 MULTIBEACON CHARGER TABLE OF CONTENTS Specifications Operation And Maintenance Operation Overview Configuring Charger For Single Internal Battery Pack Beacons (See Table 1) Configuring Charger For Dual Internal Battery Pack Beacons (See Table 1) Maintenance Current Switch Position Figures Battery Charger Outline... -
Page 3: Specifications
-10° to 55° c OPERATION AND MAINTENANCE The Model 4324C-V1636 is a desk top NiCad battery charger. It is designed to work at 110/120/220 volts AC 50/60Hz This is manually selected (see Figure 1). This charger is compatible with both the 4370 series Multibeacons. -
Page 4: Maintenance
17V then battery is close to fully charged, if under 12V then cells will require a full 14-16 hour charge. 2.4.3 The 4324C has two internal in-line fuses. If there is no output as tested in 2.41, check to see if the fuses are open, reference Figure 1. -
Page 5: Current Switch Position
4324C-V1636 MULTIBEACON CHARGER CURRENT SWITCH POSITION CHART BEACON INTERNAL BATTERY PIGTAIL REQUIRED SWITCH POSITION TIME FOR FULL TYPE PACKS CHARGE 4370A 4324-0010 150mA 14-16hrs 4376A 4324-0010 150mA 14-16hrs 4377A 4324-0010 300mA 14-16hrs 4378A 4324-0010 300mA 14-16hrs *NOTE: Any two multibeacons can be charged with one charger if each beacon has only 1 Internal Battery Pack. -
Page 6: Figures
4324C-V1636 MULTIBEACON CHARGER Current Selector Switch 150mA 300mA Remove From Outer Module the Inner Module and Position the Proper AC Voltage Setting to Appear in the Modules W indow Squeeze Tabs and Pull Out Module to Select Input Voltage Ranges... -
Page 7: Battery Charger Outline
4324C-V1636 MULTIBEACON CHARGER REVISIO NS THIS DRAW ING IS LOANED W ITHOUT OTHER CONSIDERATION THAN THE AGREEMENT AND CONDITION THAT DESCRIPTIO N DATE APPROVED IT IS NOT TO BE REPRODUCED, COPIED, OR OTHERW ISE DISPOSED OF, DIRECTLY OR INDIRECTLY AND IS NOT TO BE USED IN W HOLE OR IN PART ANY TO ASSIST IN M AKING OR TO FURNISH ANY INFORMATION FOR THE MAKING OF DRAW INGS, PRINTS, APPARATUS, OR PARTS THEREOF.
