JOY STICK JS-300(Ver2.0) User’s Manual CONTENTS For Your Safety： Ⅰ．Before You Begin 1-1．Overview： 1-2．Connecting Method： Ⅱ．Notes on Use 2-1．Parts of the JS-300： 2-2．Operating method： 2-3． Checking and Setting Memory Swithes 9 Ⅲ．Specifications 3-1．Specifications： 3-2．Exterior Dimensions：... - Page 2 ・ The prior written approval of SIGMAKOKI CO., LTD. is necessary to reprint or reproduce in whole or in part these materials. ・ If these products or technologies are subject to the Japanese export control restrictions, they must be exported under a license Japanese government and cannot be imported into a country other than the approved destination.
-
Page 3: For Your Safety
For Your Safety Before using this product, read this manual and all warnings or cautions in the documentation provided. Only Factory Authorized Personnel should be changes and/or adjust the parts of controller. The Symbols Used in This Manual WARNING CAUTION This symbol marks warnings that should be read This symbol indicates where caution should be and used to prevent serious injury or death. - Page 4 God, action by any third party, other accidents, and deliberate or accidental misuse. ④ If the equipment is used in a manner not specified by the SIGMAKOKI CO., LTD., the protection provided by the equipment may be impaired.
-
Page 5: Ⅰ．before You Begin
① Connect a standard cable (MDR14-CA-*) to the connector on the rear panel of the JS-300. ② Connect the cable from the JS-300 to the “JOYSTICK” connector on the front panel of the SHOT-30X series and SHOT-702 controller. (In the case of SHOT-702, it becomes the rear panel part.) -
Page 6: 2-1．Parts Of The Js-300
Chapter 2: Notes on Use 2-1. Parts of the JS-300 ①LCD panel MODE ②MODE button ⑩STOP button ③E-ORG button ⑨SPEED button ④ZERO button ⑧Third axis operation switch ⑤Axis select button ⑥Joystick ⑦M-ORG button... -
Page 7: 2-2．Operating Method
2-2. Operating method ①LCD panel Display the position coordinates for each axis and the operating mode. Display Digit : 16 digit × 4 lines ②MODE button Change an operation mode of the controller. HOST→MANUAL・・・ Refer to a User’s Manual of SHOT-302GS/SHOT-304GS for various modes. NOTE) IN SHOT-702, the MODE change is invalid. - Page 8 ⑦M-ORG button Moves the stage to its mechanical origin. The LED indicator lights up when the stage is moving and lights off when the stage is at mechanical origin position. ⑧Third axis operation switch Use the switch to operate third axis. Push the switch to Top : + direction Push the switch to Bottom : - direction NOTE) This button is only usable with SHOT-304GS.
-
Page 9: Checking And Setting Memory Swithes
(NOTE) This function is only usable with SHOT-302GS and SHOT-304GS. ○ Changing Memory switch settings To display the memory switch settings screen in MANUAL mode, press the “MODE” and “E-ORG” buttons simultaneously . Memory switch settings can be changed using the buttons on the JS-300. Button Function Cycle through items in descending order (No.2⇒... - Page 10 Chapter 3: Specifications 3-1. Specifications Power source DC5V ±10% ( from controller) Operating temperature 5～40℃ Storage temperature -20～60℃ Ambient humidity 20～80%RH (no condensation) External dimensions 120W×160D×50H (excluding projections) Weight 700g Electrical burst immunity EN61000-4-4(2004) Level 2 Electrostatic discharge EN61000-4-2(1995)+A1(1998)+A2(2001) Level 2 3-2.
