- Page 1 PoE Splitter Power over Ethernet Splitter 802.3af POE-22001T SER’S ANUAL...
-
Page 2: Table Of Contents
Content Overview ............1 Features ............1 Hardware Description ........2 Package Contents ..........2 Installation ............5 Technical Specification ........6... -
Page 3: Overview
Ethernet data and DC power to a network device that is not compliant with the IEEE802.3af standard (non-PoE). This adapter effectively provides Ethernet data and DC power to a non-PoE device with a single cable and allows it to operate within a PoE network. PoE is an efficient and convenient solution for remote applications where available space is limited and/or no power source is readily available. -
Page 4: Package Contents
Package Contents (1) Power over Ethernet Splitter (2) DC Power Cables – 5.5x2.0mm and 5.5x2.5mm User's Manual PoE Splitter DC Power Cables User's Manual With adjustable output Figure 1-1. Package Contents Compare the contents of your Power over Ethernet Splitter package with the standard checklist above. -
Page 5: Hardware Description
The Data In port Data Out port: This is an RJ-45 Ethernet port and has a detachable RJ-45 cable for connecting with a PoE device such as a camera. Power Out port: The adapter supports and includes two types of power cables –... - Page 6 System Power LED indicator DIPswitch: The DIPswitch changes the splitter voltage allowing for it to operate with a variety of products. It provides four voltage values – 5V, 7.5V, 9V and 12V. The default is 5V. Before adjusting the DIPswitch, disconnect the power from Splitter Adapter. DIPswitch...
-
Page 7: Installation
PoE function, you'll need to install a PoE Injector (pn: POE-32001T) between the hub and splitter. 2. Use an RJ-45 cable to connect the Data Out port on the PoE Splitter Adapter to a remote device (Such as a router, access point, camera, etc.). -
Page 8: Technical Specification
Technical Specification IEEE802.3 10BASE-T Standard IEEE802.3u 100BASE-TX IEEE802.3af Power over Ethernet (2) Power Cables, Power jack each with straight and a right angle plugs diameter Plug dimension: 5.5 x 2.0mm, 5.5 x 2.5mm DIPswitch Four-segment output voltage switch Data / Power In: 1 x RJ-45.Data pin 1,2,3,6 Power pin: 4,5(V+), 7,8(V-) and 1,2(V+), 3,6(V-) Connector... - Page 9 908 Canada Court City of Industry, CA 91748 U.S.A. Phone: 626.964.7873 or 800.346.6668 Fax: 626.964.7880 www.unicomlink.com e-mail: info@unicomlink.com UNIDOC020905...
