Page 1: Operating Instructions
Operating instructions Concept L 32 Concept L 32 Basic Concept L 26 Concept L 26 Basic... -
Page 2: Table Of Contents
Login and connect equipment Video playback Timer recording with video or DVD recorder Assignment of digital audio inputs and outputs Connecting Loewe DVD Preceiver Auro 16 PS and Individual Sound loudspeaker system Connecting other audio amplifiers or active speakers HDMI (DVI) connection... -
Page 3: Remote Control - Tv Functions
Remote control - TV functions Sound off/on Switch over to operate VCR Switch over to operate TV set Call timer list Menu "Additional functions" on/off Set picture format pqrs Electronic Programme Guide Now&Next Programme Info Show/hide menu Teletext on/off V– Red button: freeze picture on/off Green button:... -
Page 4: Control Unit
Control Unit Mains switch Call the menu, in the menu: up/down �� Station down, in the menu: left � in the menu: right � LOEWE. Open control panel – Station up, Headphones connection Display: red = standby green = operation... -
Page 5: Connections To Rear Panel
Connections to rear panel Common Interface (CI-Slot) Antenna/cable PIP tuner or satellite antenna Antenna/cable analogue/digital (tuner 1) Antenna output PIP tuner connect to tuner 1 Set-specific equipment and retrofitting options for CI-Slot, PIP and satellite tuners, see pages 41 and 42. ANT -S AT ANT-S AT AUDI O I N... -
Page 6: Welcome
Welcome Thank you! At Loewe, we combine the highest standards of technology, design and user friendliness. This applies equally for TV, video and accessories. Your new TV set is ideally equipped for the TV standard of the future - ”HDTV”... -
Page 7: Note On The Lcd Screen
Welcome Note on the LCD screen The TV set with an LCD screen you have purchased meets the highest quality requirements and has been tested for pixel errors. Despite the utmost caution in production of the displays, it cannot be totally ruled out that some of the pixels might be defective for technological reasons. -
Page 8: For Your Safety
• Place the TV set on a level, firm base. The set should not protrude at the front when installing in cabinets or shelves. Only use original accessories if possible, e.g. Loewe wall holders and stands. Never let children handle the TV unattended. -
Page 9: First Installation
First installation Remote control Batteries To insert or change the batteries, press on the arrow. Slide the battery compart- ment cover downwards and remove it. Insert LR 03 alkaline-manganese batter- ies (AAA) and ensure that the + and - ends are positioned correctly. Then push the cover back on from the bottom. -
Page 10: Handling The Fabric Hose (Optional)
(see illustration). This makes it easier for you to push through cables with plugs. You can obtain the fabric hose as an accessory from your Loewe dealer or Loewe Customer Service. - 10... -
Page 11: Automatic Programming
First installation Automatic programming Automatic programming of the TV set is started the first time you switch it on. Follow the menus. By pressing in one of the arrow directions, you can choose the settings ..and confirm your settings by pressing OK. You then go to the next menu. -
Page 12: Directing Dvb-T Antenna
First installation Directing DVB-T antenna Note: not with DVB-T stations in GB. If you use a room antenna to receive one or more DVB-T stations that have picture and sound interference, then you should change the location of where the antenna is set up. To help you direct your antenna or to help you determine the most suitable loca- tion to set up the antenna, your TV set has a display for the signal quality C/N and the signal strength Level. -
Page 13: Changing Stations
Daily operation Changing stations ... with the P+/P- buttons on the remote control Stations up/down V— P– When changing, the station display is visible for a few seconds. 41 ZDF Eifellandschaft Language/sound selection If additional languages are broadcast with DVB stations, then the set displays the language/sound selection under the station display. -
Page 14: Basics About The Menu Operation
Daily operation Basics about the menu operation Menus are called via the MENU button or via the button for special menus and can be hidden by using these buttons or by using the END button. The menu is displayed in the bottom section of the screen. At the top, you can see additional information for the menu point selected. -
Page 15: For The Info System
Daily operation For the info system ... For each menu point, an info text is displayed at the top of the picture to help you with the setting. This saves you from having to refer back to the operating instructions. We shall demonstrate this using the station search option as an example: Call the TV menu. -
Page 16: For The Index
Daily operation For the index ... Using the index, you can access many operational functions directly. You can also find a great deal of information on technical terms about television. Before the alphabetical sorting, you can find the menu language option, the list of features integrated into the TV set and the repeat initial installation option. -
Page 17: Setting The Sound
Daily operation Setting the sound Volume and other frequently used sound settings Setting the volume Volume by using 5 or OK, you can call other sound settings ... Volume Sound adjustment and select using 34 ... Volume Sound adjustment Sound effects normal use 6 for the related selection/setting... -
Page 18: Operating Modes - Tv
Operating modes – TV In initial installation and daily operation, the TV set is in TV mode. This is also the case when none of the other modes of operation, such as EPG, Teletext, PIP or Radio, have been selected. Each of these operating modes has a separate menu with separate functions for the coloured keys. -
Page 19: Call Additional Functions
Operating modes – TV Call additional functions Select additional functions such as Teletext subtitles, Personal teletext pages, Headphone volume, Scan stations and to move the picture up and down. Additional functions Teletext subtitles Personal teletext pages Call timer overview If timer recordings have been programmed, you will see when which station is recorded here. -
Page 20: Dvb Subtitles 0
Operating modes – TV Under “Settings“ you will find the following functions: Stations Here you can search for and store new stations automatically or manually. With “Change stations“, you can rearrange and delete the stations and change sta- tion names (not for DVB-T stations in GB). •... -
Page 21: Removing The Ca Module 1
Operating modes – TV Removing the CA module (Only for sets with CI slot) 1. Switch the TV set off with the mains switch. . Remove the cover from the back of the set on the upper left. 3. Press the eject button at the module slot; the CA module is unlocked. -
Page 22: Operating Modes - Pip
Operating modes – PIP Picture in picture (PIP) Note: The coloured keys do not work as described below with DVB-T stations in GB, but they operate as described on page 7 (Digital Teletext). Picture in picture displays are possible if the set has an analogue PIP tuner or a digital satellite tuner in addition to the analogue TV cable tuner. -
Page 23: Functions In The Pip Menu 3
Operating modes – PIP Functions in the PIP menu In the PIP menu, you can set the PIP type (small picture or split screen) and the position of the small picture. Call the PIP menu (PIP must be active, green bar/frame). TV menu Settings Type... -
Page 24: Operating Modes - Epg
Operating modes – EPG EPG - Programme guide EPG is an electronic programme guide. With this system, you can easily find the programmes that interest you (sorted according to day, time, stations and topics). You can mark programmes and programme recordings. Depending on whether you are receiving analogue stations by cable/antenna or digital stations, you will have different programme guides. -
Page 25: Epg Menu 5
Operating modes – EPG In front of the programme’s title, the system places an switched later to this programme when the set is switched on. If the TV is off, it switches on again automatically at the beginning of the marked programme if this has been set in the EPG menu. -
Page 26: Operating Modes - Teletext
Operating modes – Teletext Analogue Teletext Teletext transmits information such as news, weather, sports, programme previews and subtitles. Teletext on/off 100 100 ARD-Text ARD TEXT Teletext im Ersten Bulmahn: Bildung statt Eigenheim ..Wird auch der Nahverkehr teurer? . -
Page 27: Programme Timer Recordings 7
Operating modes – Teletext Programme timer recordings A video and/or DVD recorder must be connected and logged in in the connec- tion wizard. Call the programme pages of the current station in teletext mode using the Direct recording button . Scroll to the teletext page in which the programme to be recorded is listed if necessary. -
Page 28: Operating Modes - Radio
Operating modes – Radio Radio You can only receive radio stations via DVB. If you do not have any DVB radio reception, you can play a sound signal from an external device using the TV set via the sound/AV inputs. Use the RADIO button on the remote control to switch the RADIO radio on or off. -
Page 29: Operating Additional Equipment
Operating additional equipment Login and connect equipment You have logged in and connected all connected equipment in the initial instal- lation. If you want to connect other equipment or disconnect equipment, call the connection wizard. Call up the TV menu Select “Connections”... -
Page 30: Video Playback
(e.g. in a rack). You can control the recorder with the TV set. If you have a Loewe recorder with both systems, you can use all the advantages. The advantages of Digital Link Plus are used for the timer recording; the advan- tages of Digital Link for concealed installation of the recorder. -
Page 31: Assignment Of Digital Audio Inputs And Outputs
Audio output “AUDIO DIGITAL OUT“ The digital audio signal is applied at the “AUDIO DIGITAL OUT” socket of the TV. For example, you can connect an external digital audio amplifier or the Loewe Auro system here. An analogue audio signal from the TV set or another sound source which is received at one of the Euro-AV sockets of the TV set is converted into a digital signal (PCM) and output at the “AUDIO DIGITAL OUT“... - Page 32 If you want to listen to the sound via the TV speakers temporarily, call the Sound menu, select “Sound via“ and then “TV“. If you want to listen to the sound via the Loewe Auro system, select “AURO“ under “Sound via“. Audio cable cinch -> SCART...
-
Page 33: Connecting Other Audio Amplifiers Or Active Speakers
Operating additional equipment Connecting other audio amplifiers or active speakers In the connection wizard, select “HiFi/AV amplifier” under “Equipment selec- tion: audio component”. The connection wizard allows configuration of different audio amplifiers (stereo amplifiers, surround amplifiers, analogue or digital) with different sound formats (Dolby Digital, dts, MPEG and Stereo/PCM). -
Page 34: Hdmi (Dvi) Connection
The HDMI connection (High Definition Multimedia Interface) allows digital picture and sound transmission via a connecting cable, e.g. from Loewe DVD Recorder Centros 10/17 HD. The digital picture and sound data are transmitted without data compression and therefore lose none of their quality. In the equipment con- nected, no analogue/digital conversion is necessary, which might also have lead to losses in quality. -
Page 35: Component Video Connection
Operating additional equipment Sound from PC or Set Top Box Feed the analogue audio signal from the PC or the STB to the sockets AUDIO IN L/R on the TV via a cinch cable. The sound is reproduced via the TV speakers. If you have connected a digital external audio amplifier, you can select the digital audio signal in the connection wizard (TV menu - Connections - New devices/modifications) and assign it to the VGA/XGA socket. -
Page 36: Operating Loewe Video Recorders And Loewe Dvd Players Directly
Operating additional equipment Operating Loewe video recorders and Loewe DVD players directly You can switch over the remote control of the TV set to operate Loewe video recorders and Loewe DVD players. These devices can be operated directly. Select the device to be operated: press the VCR button, the indicator above lights for about 5 seconds. -
Page 37: What To Do, If
TV menu. “Connections” cannot be called in the TV menu (deactivated). The control of the Loewe video recorder and the timer do not work or do not work properly. General problems with connecting external equip- ment via an AV input. - Page 38 What to do, if ... Problem Digital Link Plus does not function. Various characters are displayed incorrectly in the teletext. No sound via external digital audio amplifier. - 38 Possible cause a) Euro-AV cable is not fully wired (pin 10 not wired).
-
Page 39: Technical Data
Technical data General data Type Item no. Versions TV terr. (analogue) Versions DVB-T/C Versions DVB-T CI (MHEG-5) Versions DVB-T/C CI Set dimensions without stand (ca. cm WxHxD) Dimensions with stand (ca. cm WxHxD) Set weight without stand (ca. kg) Set weight with stand (ca. kg) Display Picture diagonal (cm)/picture format Resolution... -
Page 40: Electrical Data
CVBS (VHS/8 mm) CVBS (VHS/8 mm) Y/C, (only with SVHS Link Plus) Digital video and audio PC/STB video signal Subject to modifcations! © by Loewe Opta 006 Y/C (S-VHS/Hi 8) /DVB-T/C ANT-SAT Y/C (S-VHS/Hi 8) Y/C (S-VHS/Hi 8) Y/C (S-VHS/Hi 8) -
Page 41: Accessories
Loewe audio system Auro and the active speaker system Individual Sound The interplay of a Loewe TV with a Loewe audio system and a Loewe speaker system creates an excellently coordinated home cinema system. Advantages are high operating comfort, attractive design and adapted technology. - Page 42 Accessories Retrofitting options The following table shows the equipment and retrofitting options for the individual device versions. Device version / Equipment Concept L 6 Basic Concept L 6 DVB-T CI Concept L 6 DVB-T/C CI Concept L 3 Basic Concept L 3 DVB-T CI Concept L 3 DVB-T/C ● available / installed ○ retrofittable / optionally available...
-
Page 43: Service
