Autoadapt Turny Evo User Manual

Seat lift
Hide thumbs
Table of Contents

Advertisement

Quick Links

Turny Evo
Autoadapt
Seat lift
EN
User manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Turny Evo and is the answer not in the manual?

Questions and answers

Related Manuals for Autoadapt Turny Evo

Summary of Contents for Autoadapt Turny Evo

  • Page 1 Turny Evo Autoadapt Seat lift User manual...
  • Page 2 If you have any questions about your adaptation, please contact your installation engineer. If you want to share your opinions about the product or the company with us, you can register them on www.autoadapt.com/register. That way, you will be helping us to become a better supplier.
  • Page 3 Getting seated Turny Evo Operation Presentation Hand held control Operating Turny Evo Using the hand held control Using the emergency operation kit Care instructions Troubleshooting Technical specification Servicing information and “Declaration of conformity” at the end of the manual.
  • Page 4 In this event ,Turny Evo loses its position and must be reset through an emergency operation. Should this occur, follow the instructions for “Emer- gency operation by hand held control”.
  • Page 5 Hold the selected button down. When the seat reaches its preprogrammed end position, it will stop automati- cally. To stop movement, release the button. Turny Evo's location in the vehicle on the right or left side determines the functions of buttons 2 and 4. COMFORT...
  • Page 6 Turny Evo Getting seated Operating Turny Evo Swivel in and out A door icon is displayed Turny Evo will follow its on the right of the screen preprogrammed path. when the door is open.
  • Page 7 Getting seated Turny Evo Adjusting comfort This function will also work while driving with a closed door. Foldable footrest...
  • Page 8 Getting seated Emergency-mode operation Using the hand held control 0° 45° Lift OK Crash safety 113° The illustration on the left shows a fully swivelled in Turny Evo where the crash safety pin has locked the seat in the correct position.
  • Page 9 “up” and ”in” symbols have greyed out. Hold down the yellow button until Note that the symbol for ”in” is laterally inverse in a left-side Turny Evo. the picture ”enter code” is displayed. Then enter the code1, 1, 1, 2...
  • Page 10 Exit Press 1 or 3 and select “exit”. Press 2 to confirm “exit”. Turny Evo is now back in its normal operating mode. If this screen is displayed the criteria to exit the system has not been achieved. Go back and do 9.1 again and then step 9.2.
  • Page 11 Getting seated Turny Evo Using the emergency operation kit 0° 45° Lift OK Crash safety 113° The illustration on the left shows a fully swivelled in Turny Evo where the crash safety pin has locked the seat in the correct position.
  • Page 12 Turny Evo Getting seated Swivel the seat in The seat must be lifted all the way up and swiveld all the way in. Begin by releasing the turning mechanism if these manoeuvres must be combined and cannot be done separately. Adjust lengthwise as necessary.
  • Page 13 Getting seated Turny Evo LIFT / Alt. 2 - Strenuous but fast Remove the yellow lock plate in front of the safety curtain. Raise the seat manually. Keep the lock plate for the visit to the workshop.
  • Page 14 Turny Evo Getting seated SWIVEL Pull out the yellow lock plate at the front of the base plate to release the turning mechanism. Swivel the seat all the way in and then slide the lock plate back to lock the seat in...
  • Page 15 Getting seated Turny Evo LENGTHWISE ADJUSTMENT Insert the socket in the hole in the lower rear cover. Crank the ratchet counterclockwise to move the seat backwards.
  • Page 16 Turny Evo Getting seated Care instructions As necessary .............. Carefully vacuum clean Turny Evo. Use no liquids. • The product documentation must always be taken along to vehicle inspections. • Always contact your installation technician when dismantling.

  • Page 17: Troubleshooting

    - Follow the instructions for “Emergency operation by hand held control”. - Follow the instructions for “Emergency operation using the emergency kit”. Unusual noises heard during operation ..- Do not use the Turny Evo. Contact your installation technician for an overhaul.
  • Page 18 Raise the backrest. Raise the seat again if it is difficult out is stopped. Lift up is still possible. to get to the knob. Incomplete seat swiveld-in. Turny Evo is not in a Swivel the seat all the way in. crash-safe position. The symbol is laterally inverse on a left-side Turny Evo.
  • Page 19 Getting seated Turny Evo Warnings/error messages Recommended action Swivel motor pinch protection activated. Lift motor pinch protection activated. When encountering an obstruction, Turny Evo will stop and back a little. Remove the obstruction and try again. Lengthwise adjustment motor pinch protection activated.
  • Page 20 Swivel motor switch activated in wrong position. Follow the “Emergency operation with hand held Lift motor switch activated in wrong position. control” instructions to reset Turny Evo's start position. Contact your installation technician if the fault persists. Lengthwise adjustment motor switch activated in wrong position.
  • Page 21 Getting seated Turny Evo Please contact your installation technician if you require further assistance or need to ask ques- tions about warranty. We recommend keeping the following information to hand at all times / Contact details for the installation engineer /...

  • Page 22: Technical Specification

    Turny Evo Getting seated Technical specification From above, swiveld out to the right From behind, swiveld out to the right and lowered 54.2 cm 16.3 cm 113° Length with upfolded foot rest ..........70.3 cm Product weight..................84 kg Width ...................... 54.2 cm Weight capacity* ..................
  • Page 23 Getting seated Turny Evo Introduction for users Autoadapt would like you, as a user, to feel secure and comfortable with your new prod- uct. For that reason, it is your installer’s duty to go through the following with you / •...

  • Page 26: Declaration Of Conformity

    Declares that the product / F924532, FX 0024441, FX 002441A, FX 006316, P100001, P100002, P100003, PX 00726A, PX 00726B. LCA 5106 730011,51067300211,51067300311 Turny Evo, including mounting console The original anchor points of the OEM-seat must be used. made by Autoadapt Autoadapt AB, Stenkullen 2015-02-01 Håkan Sandberg...
  • Page 27 Accredited by SWEDAC as testing laboratory in accordance with ISO/IEC 17025:2005 Quality system certified in accordance with ISO 9001:2008 Illustrations, descriptions and specifications in the user manual are based on current product information. Autoadapt reserves the right to make alterations without previous notice. © 2015 Autoadapt AB...
  • Page 28 AUTOADAPT AB Åkerivägen 7 S-443 61 Stenkullen Sweden Phone: +46 302 254 00 E-mail: info@autoadapt.com...
