  • Page 1 DISHWASHER User Manual Model Number: DC6652W...

  • Page 2: Table Of Contents

    Technical Specifi cation Installation Setting Up Your Dishwasher GUARANTEE NOW Using Your Dishwasher SERVIS.CO.UK 0800 0124382 Maintenance Parts & Labour for 2 years. Go to www.servis.co.uk for more information Troubleshooting Product Fiche Guarantee Index T: 0800 0124 382 T: 0800 0124 382...

  • Page 3: Welcome

    Fill hose WARRANTY Servis provides you with a guarantee which will protect you should your Dishwasher develop an Figure 1 electrical or mechanical fault during the guarantee period. To ensure that you get a prompt and efficient service, please register your Dishwasher immediately.
  • Page 4 Before connecting your Dishwasher, ensure that all electrical connections match the values on the rating plate. Servis cannot be held responsible for any damage that may occur due to Faulty components must only be replaced by a suitably qualified Service Agent using improper connections.
  • Page 5 SAFETY INSTRUCTIONS Do not make any alterations to your Dishwasher, unless authorised to do so by Servis. Place hollow items, such as bowls, glasses and pots into the Dishwasher face-down wherever possible. However, do not place tall glasses so that their stems can block the rotary spray arm.

  • Page 6: Your Dishwasher

    YOUR DISHWASHER FRONT VIEW REAR VIEW Control Panel Door Handle On/off switch Cold water Power Cable inlet Drain hose Feet Feet Feet Feet On/off switch. Power cable. Door handle. Drain hose; provides an outlet for the dirty water from your Dishwasher. Control panel.
  • Page 7 YOUR DISHWASHER INSIDE VIEW (WITH DRAWERS) INSIDE VIEW (WITHOUT DRAWERS) Drying nozzle Upper Drawer Cutlery Box Lower Drawer Detergent compartment/ Rinse aid Filters Salt Compartment compartment Door Upper basket. Drying nozzle (one each side). Lower basket. Detergent compartment/Rinse aid compertment. Cutlery box.

  • Page 8: Technical Specifi Cation

    TECHNICAL SPECIFICATION INSTALLATION TECHNICAL SPECIFICATION INSTALLATION REQUIREMENTS To avoid risk of injury, please take care when moving your Dishwasher. It is heavy and we Capacity 12 place settings recommend that a minimum of two people move your Dishwasher. Height 845 mm To unpack your Dishwasher and manoeuvre it to the installation area, one person should hold it Height (without worktop) 815 mm...

  • Page 9: Adjusting The Feet

    INSTALLATION ADJUSTING THE FEET WATER SUPPLY CONNECTION For safe operation, it is important that your Dishwasher is level and securely positioned on all Your Dishwasher uses an energy efficient cold fill system, which means that the Dishwasher is four feet. Incorrect installation may cause the Dishwasher to vibrate and increase your water and filled with cold water which is then heated to wash the dishes.

  • Page 10: Drain Hose Connection

    INSTALLATION WATER SUPPLY CONNECTION The drain hose Screw the straight end of the hose clockwise to a 19mm (3/4’’) cold water tap until hand can be connected tight (fig 8). Take care not to trap or kink the hose. to a standpipe, as shown.

  • Page 11: Electrical Connection

    INSTALLATION ELECTRICAL CONNECTION PREPARING YOUR DISHWASHER FOR FIRST USE Remove all packaging from the Dishwasher . Your Dishwasher requires a 220-240V, 50Hz mains supply. Do not use any other supply. Set the water softener level (see page 20). Your Dishwasher may be fitted with a moulded plug, which cannot be rewired. Add 2 kg of salt to the salt compartment and fill with water until it is almost overflowing If the fuse cover becomes damaged, you must not use the plug.

  • Page 12: Setting Up Your Dishwasher

    SETTING UP YOUR DISHWASHER CONTROL PANEL OVERVIEW SETTING THE WATER SOFTENER LEVEL The effectiveness of your Dishwasher depends on the softness of the water supply. For this reason, your Dishwasher is equipped with a system to reduce the hardness in the mains water. To find out the water hardness level in your area, contact your water company.

  • Page 13: Filling With Salt

    SETTING UP YOUR DISHWASHER Filling With Salt Filling With Rinse Aid To fill the salt compartment (fig 11): To fill the rinse aid compartment (fig 12): Open the Dishwasher. Open the Dishwasher. Remove the lower basket. Remove the rinse aid compartment cap by turning it counter clockwise. Open the salt compartment cap by turning it counter clockwise.

  • Page 14: Using Your Dishwasher

    USING YOUR DISHWASHER Loading Your Dishwasher Your Dishwasher has two main baskets for your dishes and a cutlery box for cutlery and other small items. Upper Drawer The upper basket is designed for tea plates, dessert plates, salad bowls, cups and glasses. The lower basket is designed for larger or deeper items, such as pots with long handles, pot lids and large plates.
  • Page 15 USING YOUR DISHWASHER Do Not Block The Upper Spray Arm Adjusting The Upper Basket: Do not overload the drawers or place items where they can block the rotary spray arms (fig 14). If The upper basket can be raised to create a larger space in the lower basket (fig 15). This is necessary, t he upper basket can be raised to create a larger space in the lower basket.

  • Page 16: Filling With Detergent

    USING YOUR DISHWASHER Filling With Detergent Combined Detergents Once you have loaded the Dishwasher, you must put in detergent. To fill the detergent Some manufacturers produced combined detergents. These contain a mixture of detergent, compartment (fig 16): salt and/or rinse aid. Check the labelling on the detergent product you are using and adjust the amount of salt or rinse aid you use separately in your Dishwasher.

  • Page 17: Child Lock

    USING YOUR DISHWASHER Running Your Dishwasher Changing The Programme While It Is Running Once you have loaded your Dishwasher: To change programmes while the Dishwasher is running: Close the Dishwasher door. Press the Start/Pause button to pause the programme. Switch on your Dishwasher. The last programme used is automatically selected. Use the Programme Select Button to select a different wash programme.
  • Page 18 USING YOUR DISHWASHER DISHWASHER PROGRAMMES Programmes Wash Types of food fragments Contamination Amount of Full Load Half Load Temp. Level Detergent Prog. Power Water Prog. Power Water (°C) Required* Duration Used Used Duration Used Used (minutes) (Kw/hour) (Litres) (minutes) (Kw/hour) (Litres) Prewash Fresh less dirty, coffee, milk, tea...
  • Page 19 USING YOUR DISHWASHER DISHWASHER PROGRAMMES - WASH STEPS STANDARD LOADS AND TEST DATA Capacity Programmes Steps Upper and lower baskets: 12 place settings. The upper basket should be adjusted to the lower Prewash Prewash position (see page 26 for further information). Quick 40°C 40°C wash Cold rinse...

  • Page 20: Maintenance

    MAINTENANCE GENERAL MAINTENANCE Filters: From time to time it may be necessary to carry out some routine maintenance of your If any food waste remains on the coarse and fine filters, remove them and clean them Dishwasher to ensure that it operates as intended. Before cleaning your Dishwasher: thoroughly.
  • Page 21 MAINTENANCE Spray Arms: Water Inlet Filters: Your Dishwasher contains two spray arms (fig 18). One at the bottom of the Dishwasher and one Water inlet filters prevent dirt and foreign materials from entering your Dishwasher . It is on the underside of the upper basket. recommended that these filters are cleaned when your Dishwasher is unable to receive sufficient water, although your water supply is on and the tap is open.
  • Page 22 MAINTENANCE Clean the filter thoroughly with a soft brush, wash with soapy water and rinse thoroughly. Re-insert the filter by gently pushing it back into place. A second water inlet filter is located in the tap end of the water inlet hose. To remove the second water inlet filter: Use a pair of long-nosed pliers to gently pull on the plastic bar in the filter.

  • Page 23: Troubleshooting

    The water inlet filters are Clean the water inlet filters If your Dishwasher has developed a fault not covered in this manual, please contact the Servis blocked. (see page 38 for detailed helpdesk. instructions). Your Dishwasher is not...
  • Page 24 TROUBLESHOOTING Fault Possible Cause Solution Fault Possible Cause Solution Your Dishwasher is vibrating. The feet of your Dishwasher Adjust the feet (see page 13 White stains left on dishes Salt compartment cap not Close salt compartment cap are not correctly adjusted. for further information).
  • Page 25 Rinse aid dosage set too low. Increase rinse aid dosage If problems persist or you experience any malfunctions not described here, contact an authorised setting (see page 22 for Servis engineer. further information). Dishes unloaded too fast. Allow dishes to stand before unloading the Dishwasher .

  • Page 26: Product Fiche

    *** Drying efficiency class A on a scale from G (least efficient) to A (most efficient). If problems persist contact an authorised Servis engineer. **** The Eco 50°C is the standard cleaning cycle to which the information in the label and fiche relates.

  • Page 27: Guarantee

    All packaging and materials used are environmentally friendly and recyclable. Please dispose For your Servis guarantee to be valid, you will need to retain your original purchase of any packaging in an environmentally friendly manner. Consult your local council for further receipt and be able to provide it when you make a claim.

  • Page 28: Index

    INDEX Adding detergent ..........27 Electrical connection........17 Loading your dishwasher ......25 Tablet detergent button ........19 Adding rinse aid ..........22 Technical specification ....... ..11 Adding salt.............21 Troubleshooting information ......41 A djusting the feet...........13 A djusting the upper basket ......26 Feet, adjusting ..........13 Pausing a programme ........19 Filling with detergent ........27 Preparing your dishwasher for first use..18...
  • Page 29 T: 0800 0124 382 E: info@servis.co.uk The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
