Summary of Contents for Matrix MEH600
- Page 1 MEH600/900 MEP600/900 Extractors Manual for Installation, Use and Maintenance...
- Page 2 Important The manufacturer cannot be held responsible for injuries or losses caused by incorrect use or installation of this product. Please note that the manufacturer reserves the right to invalidate the guarantee supplied with this product following incorrect installation or misuse of the appliance or use in a commercial environment. This appliance is not designed to be used by people (including children) with reduced physical, sensorial or mental capacity, or who lack experience or knowledge about it, unless they have had supervision or instructions on how to use the appliance by someone who is responsible for their safety.
-
Page 3: Using Your Extractor
Using your Extractor For best performance, you should switch on the extractor 15 minutes before starting to cook and leave it to run for approximately 15 minutes after the end of cooking. Control Panel A – Power off button B – Speed level buttons C –... -
Page 4: Care And Maintenance
Care and Maintenance IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE ELECTRICITY SUPPLY. Cleaning You should use a nonabrasive cleaner. Any abrasive cleaner (including Cif) will scratch the surface and could erase the control panel markings. -
Page 5: Changing The Light
Changing the Light DO NOT CHANGE THE LIGHT BULB IMMEDIATELY AFTER USE AS THE BULB WILL BE HOT. ALLOW IT TO COOL BEFORE REMOVING IT. Unscrew the light bulb cover. Unscrew the light bulb and replace with the required light bulb as shown in the table below. Finally, replace the light bulb cover. -
Page 6: Mains Electricity Connection
Mains Electricity Connection THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE POLE SWITCHED FUSE SPUR OUTLET AND PROTECTED BY A 3A FUSE. Warning! This appliance must be earthed We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. -
Page 7: Electrical Information
Electrical Information Mains electrical voltage: 230 – 240Vac, 50Hz Total rated power consumption: MEH: 200W MEP: 180W Troubleshooting If your extractor is not working: Check that the mains supply has not been switched off. Check that the fuse in the spur has not blown. -
Page 8: Mounting Your Extractor
LEAST 760mm. The width of any hob must not be greater than the width of the extractor installed above it. Fig. 3 Fig. 3 MEH600 MEH900 MEP600/900 Ducting and Ventilation 60.5 For best performance and lowest noise output, we recommend 115.5... - Page 9 INSTALLATION Figu re 2 - M ar k wal l as req ui red (see ta bl e 1) Tools required Mark wall as required (see table 2) Fig. 5 Fig. 6 Drill holes Fit wall fixings and top screws - Ensure that any fixings you use Figu re 3 - D rill h oles are appropriate for the wall type.
- Page 10 Figu re 7 - Mo unt chimne y bracke ts Mount chimney brackets Fix ducting (seal joint) Figu re 8 - Fix ducting (s ea l joint) Figu re 7 - Mo unt chimne y bracke ts Figu re 8 - Fix ducting (s ea l joint) Figu re 10 - Adj ust an d s ecure the chim ne y Fig.
- Page 12 Serviced by To contact our Customer Care Department, or for Service, please contact us on the details below. Passionate about style Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY T : 01949 862 012 F : 01949 862 003 E : service@cda.eu W : www.cda.eu...
