Page 2: Safety Information
Osiris-Jaegar – Installer Guide Safety Information. Before installing the equipment, please read this guide carefully. To prevent electrical shock hazards, disconnect the power from electrical sources before working on the equipment. Make all connections with the power turned off. Do not make or remove connections when the power is turned on. -
Page 3: Camera Menus
Osiris-Jaegar – Installer Guide Camera Menus. Configuration of the camera takes place using the internal menu. There are two versions: • A quick menu that contains only the most commonly used settings, and • A comprehensive main menu where all settings are accessible. - Page 4 Osiris-Jaegar – Installer Guide The main menu The main menu provides access to all camera configuration features and contains numerous sub-menus within it: Silent Sentinel Oculus Send a Preset 2 command to access the Main Menu – Version n.nnn (xxxx) xx...
- Page 5 Osiris-Jaegar – Installer Guide Setup Silent Sentinel Oculus The setup menu is protected by a password. The default Version n.nnn (xxxx) xx setting for the password is AAAAAA (6 characters) – this SN: FFFFFFFF POST: 000000000 can be changed within the Miscellaneous section.
- Page 6 Osiris-Jaegar – Installer Guide Camera 1 options Osiris Open Platform Options displayed in the Camera 1 options will vary between Version n.nnn (xxxx) xx configurations and are specific to the chosen payload that is SN: FFFFFFFF POST: 000000000 installed. This menu provides access to the supported functionality and settings of the camera –...
- Page 7 Osiris-Jaegar – Installer Guide Communications Silent Sentinel Oculus Version n.nnn (xxxx) xx SN: FFFFFFFF POST: 000000000 Camera number Protocol PelcoD Auto-protocol PelcoD mode Traditional Baud rate 9600 Data-bits 8-bits Parity None Stop-bits Exit menu Default values shown. Camera number sets the protocol address for the camera. Default is Camera 1 – selected in firmware menu.
- Page 8 Osiris-Jaegar – Installer Guide Configuration Osiris Open Platform Version n.nnn (xxxx) xx SN: FFFFFFFF POST: 000000000 Reverse Tilt Positioning speed Low voltage PSU Pan limit left Pan limit right Tilt limit down Tilt limit up Set North Store Wash duration...
- Page 9 Osiris-Jaegar – Installer Guide Miscellaneous Osiris Open Platform Version n.nnn (xxxx) xx SN: FFFFFFFF POST: 000000000 >Date and time Debug messages >Diagnostics Hide quick menu Idle func (tour) Idle timeout IR Lamp Auto-On Auto POST Return to Off-pos PTZF Timeout...
- Page 10 Osiris-Jaegar – Installer Guide Presets Each preset allows you to define a camera pan and tilt position as well as a zoom setting. You can define up to 128 presets which can then be either accessed using a Goto command, selected from the Goto Preset menu or can be linked together within one or more camera tours.
- Page 11 Osiris-Jaegar – Installer Guide Telemetry Osiris Open Platform This section deals with all of the various messages that can be Version n.nnn (xxxx) xx overlaid onto the video display in order to assist the operator. SN: FFFFFFFF POST: 000000000 Disable OSD...
- Page 12 Osiris-Jaegar – Installer Guide Environmental X and Environmental Y - These control the position of the internal (PCB) Temperature/Humidity information on the screen. Setting the X value to 0 will hide the text. Which Camera X and Which Camera Y – These set the position of the indicator of when Primary or Secondary camera control is selected.
- Page 13 Osiris-Jaegar – Installer Guide To edit / create a Position tour Enter the Setup menu, choose Tours and then the required Position Tour number (1 - 16). Choose the Edit/record tour option. Choose the Add option to display the list of available positions (‘@’ indicates a preset position is programmed).
- Page 14 Osiris-Jaegar – Installer Guide Video settings This section deals with the default video feed at power on and allows the level and gain to be adjusted for the video outputs. Osiris Open Platform Version n.nnn (xxxx) xx SN: FFFFFFFF POST: 000000000...
-
Page 15: Appendices
Osiris-Jaegar – Installer Guide Appendices Appendix 1 – Extended functions The base preset number (OSD Menu) can be set in the Configuration menu (the default is 2) for use with controllers of limited preset numbering all functions have fixed location preset value that can be used to initiate them. - Page 16 Osiris-Jaegar – Installer Guide Appendix 2 – Startup POST information Power On Self Test. Osiris Open Platform Version : Firmware version number and check code. Version n.nnn (xxxx) C1 C1 : Firmware security code - {Factory use only} SN:FFFFFFFF Cam:001...
- Page 17 Osiris-Jaegar – Installer Guide Appendix 3 – Power and signal connections Camera power requirements The camera can accept a range of input voltages, as follows: Input voltages 28VDC (26-36VDC) Power 70W (150W peak) Standard payloads. 100W (150W peak) Large / Dual payloads.
- Page 18 If used in residential/domestic situations it may cause radio interference which will require the user to take adequate remedial measures. The Osiris PT platform is compliant with the provisions of the the EMC Directive (89/336 EEC) and the CE marking Directive (93/68 EEC).
- Page 19 Osiris-Jaegar – Installer Guide Appendix 6 – Camera and Lens Options Lens options - PAIR2 Enhanced view selects if the output image includes image Osiris Open Platform enhancement or is direct from the camera. Version n.nnn (xxxx) xx SN: FFFFFFFF POST: 000000000 Stabilizer enables/disables the image stabilisation.
- Page 20 Osiris-Jaegar – Installer Guide Camera 1 options – Hitachi Osiris Open Platform Example functions shown for illustrative purposes only – Version n.nnn (xxxx) xx Hitachi HK5000D. SN: FFFFFFFF POST: 000000000 Show Camera Menu Camera Menu T/O Exit menu Example values shown.
- Page 21 Osiris-Jaegar – Installer Guide Appendix 7 – Using SSUtility SSUtility is a camera control application supplied by Silent Sentinel which allows you to operate multiple cameras that use a variety of control protocols. This section is intended to provide a brief overview to the operation of SSUtility.
-
Page 22: Table Of Contents
F: +44 (0)1992 500272 E: info@silentsentinel.com www.silentsentinel.com Release 1.2 – November 2014 Applicable to Osiris (Mk3) / Jaegar firmware releases – v1.099, v1.100, v1.102 Customised and bespoke firmware versions may differ ni some instances. (Derived from DN131101 – v2.1) Silent Sentinel...
