Summary of Contents for TecSys GPOS
- Page 1 User Manual TecSys GmbH www.tecsys.de Version 1.0 March. 2013 © Copyright 2013 P1 / 16...
-
Page 2: Table Of Contents
Contents Welcome Package contents ............4 Getting to know Front view ..............5 Rear view ..............6 Optional I/O interface ............ 7 Specification Installation Guide Take our the system unit ..........9 Install the Power Adapter ..........10 Install a LCM Customer Display ........11 Install a Second Display .......... - Page 3 Notices The information contained in this document is subject to change without notice. We make no warranty of any kind with regard to this material, including, but not limited to, the implied warranties of merchantability and fitness for a particular purpose. We shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
-
Page 4: Welcome
Welcome The following illustration displays the package contents of your new product. Package contents Power adapter Power cord COM-RJ45 cable (x2) Driver CD © Copyright 2013 P4 / 16... -
Page 5: Getting To Know
Getting to know Front view Zero Bezel Touch screen I-Button Base Fingerprint © Copyright 2013 P5 / 16... -
Page 6: Rear View
Rear view Cable cover Peripheral dummy cover Peripheral dummy cover display dummy cover Power button LCM display display © Copyright 2013 P6 / 16... -
Page 7: Optional I/O Interface
Optional I/O interface © Copyright 2013 P7 / 16... -
Page 8: Specification
Specification Intel CedarView D2550 processor 1.86 GHz 1M Cache Chipset NM10 Main Board System Memory SO-DIMM DDR3 x1, total up to 4G 1066MHz cooling Fanless LCD Size 15" LCD Brightness 300nits Display Resolution 1024 x 768 True Flat Resistive touch Touch Screen True Flat P-CAP touch (option) Storage... -
Page 9: Installation Guide
Installation Guide Take our the system unit Take the system unit out of the carton. Remove the unit from the carton by holding it by the foam inserts. Another carton includes the accessories: Power adapter (65W), power cord, COM-RJ45 cable(x2), and Driver CD. ©... -
Page 10: Install The Power Adapter
Install the Power Adapter Remove the Cable cover. Route the power adapter through the stand gap. Connect the cable to the DC-IN port on system IO panel. ① ② ③ © Copyright 2013 P10 / 16... -
Page 11: Install A Lcm Customer Display
Install a LCM Customer Display Place the system face down. Make sure not to scratch the screen. Remove the 2 x screws to open the dummy cover. Assemble the LCM customer display hinge into the customer display slot and fasten 2 x screws. Route the LCM display cable through the stand gap as shown in the picture. -
Page 12: Install A Second Display
Install a Second Display Place the system face down. Make sure not to scratch the screen. Remove the 2 x screws to open the dummy cover. Assemble the 2 display hinge into the customer display slot and fasten 2 x screws. Route the 2 display cable through the stand gap as shown in the picture. -
Page 13: 2Nd Vga Power Setting
2nd VGA Power Setting Power on the system, and press the <DEL> key when the system is booting up to enter the BIOS Setup utility. Select the Advanced tab. Select VGA/COM Power and LCD Brightness Configuration Ports and press <Enter> to go to display the available options. -
Page 14: Install The Msr / Fingerprint / Ibutton Module
Install the MSR / Fingerprint / iButton Module MSR/Fingerprint/iButton module can be installed to either side of the system. Choose one side and follow the steps below. Make sure the unit is powered down before starting. Open the diverse cover. Connect MSR/Fingerprint/iButton to System connector. - Page 15 Safety information IMPORTANT SAFETY INSTRUCTIONS 1) Carefully read and follow these instructions. Pay attention to the danger and caution labels displayed on the product. 2) Only operate the product based on the type of power indicated on the label. Consult your dealer or local power company if unsure of the type of power available.
-
Page 16: Version Change History
Version Change History Version Change Date Change Content V1.0 March, 2013 Release © Copyright 2013 P16 / 16...
