Summary of Contents for Spreadmaster SQ 404 F
- Page 1 IMPORTANT Maximum PTO Speed is 500 RPM SQ/TF Series OPERATING INSTRUCTIONS AND SPARE PARTS AREFULLY EFORE PERATING ACHINE July 2006...
-
Page 2: Technical Data
Technical Data SERIES "SQ/TF” Model SQ/TF 404 F SQ/TF 600 F SQ/TF 800 F SQ/TF 1000 F 400 li/480 kg 530 li/636 kg 820 li/984 kg 1000 li/1200 kg Capacity Empty weight 104 kg. 146 kg 146 kg. 154 kg. Loading height 0.93 m 0.97 m... -
Page 3: How To Use The Machine
SAFETY REGULATION - take notice of this sign 1 - HOW TO USE THE MACHINE The spreader cannot be used for purposes other than those for which it has been designed. The liability is null and void in case of damage occurred if the machine is used for applications different than those specified by the manufacturer. -
Page 4: General Instructions
2 – GENERAL INSTRUCTIONS 1. Strictly adhere to all safety and accident prevention rules, regulations and OSH guidelines in addition to the instructions contained in this manual. 2. The warnings placed on the machine show safety measures to be taken to prevent accidents. 3. - Page 5 2 – GENERAL INSTRUCTIONS (continued) 25. Do not move between the machine and the tractor without having previously engaged the hand brake, or having securely chocked the wheels. 26. Prior to performing any work on the machine be sure that it cannot be inadvertently moved. 27.
-
Page 6: Maintenance
5 - MAINTENANCE 20. Before performing any maintenance or repairs, disengage the power take off, switch off the engine and remove the starting key from the panel. 21. Periodically check the tightness of nuts and screws. Tighten where necessary. 22. Before performing any maintenance on the machine in a raised position, prop it securely with appropriate props. - Page 7 7 - ADJUSTMENTS A - Capacity adjustment 1. Adjust the position of lever opening the port according to: the quantity to be spread, the tractor speed and the fertiliser used by placing the index from 0 to 10 for models working with spreading disc and from 0 to 9 for models working with an oscillating tube.
- Page 8 Diagram Reading Example: Spreading Width Trailing Speed = 2 kph Lever Opening Position = 5 Spreading Width = 8 – 13 – 18 m gm/m² Fertiliser = 1350 – 832 – 600 gm/m² approx 18 m 13 m 2 k ph 4 kph 8 kph 12 kph...
-
Page 9: Maintenance And Preservation
B – Width Adjustment (continued) 6. To obtain the desired distribution, adjust the position of the disc fins: Move them back if the fertiliser is mainly spreading towards the left side. Move them forward if the fertiliser is mainly spreading towards the right side. 8 - MAINTENANCE AND PRESERVATION The spreader is an agricultural implement whose maintenance is difficult to perform. - Page 10 Spreading Table (Kg/Ha) PTO Speed: 540rpm Spreading Working Numbered Rack Position Type of Fertiliser Width (m) Speed (kph) 1R 104 146 186 228 290 354 416 488 580 109 139 171 217 265 311 366 420 Complex 12-12-12 112 137 174 212 249 293 338 SG = 1 Kg/L 114 145 177 208 244 280 124 152 179 209 240...
- Page 11 Spreading Table (Kg/Ha) (continued) PTO Speed: 540rpm Spreading Working Numbered Rack Position Type of Fertiliser Width (m) Speed (kph) 6R 632 698 764 830 944 1056 1170 1207 1244 1282 1296 1320 473 523 573 623 708 792 878 905 933 962 972 990 Complex 12-12-12 379 419 458 498 566 634 702 724 746 769 778 792 SG = 1 Kg/L...
- Page 12 Spreading Table (Kg/Ha) (continued) PTO Speed: 540rpm Type of Spreading Working Numbered Rack Position Seed Width (m) Speed (kph) 1R 26 44 62 100 140 178 244 308 374 440 506 19 33 46 75 105 133 183 231 280 330 379 Clover 16 26 37 60 84 107 146 185 224 264 304...
- Page 14 Series SQ/TF N° Code Quantity Description 58.60.77 Handle 37.30.15 Lever 22.51.25 Screw 21.11.08 22.51.33 Screw 35.10.35 Spacer 20.23.08 Washer 61.17.05 Spring 22.15.84 Screw 21.30.06 37.32.07 Support 600 11 a 37.32.05 Support 404 25.00.60 Cotter pin 58.38.22 Washer 58.30.53 Plug 20.19.16 Washer 61.01.43 Spring...
- Page 15 N° Code Quantity Description Optional 51.05.05 Tank N° Code Quantity Description 25.81.03 58.38.90 Washer 61.17.15 Spring 58.33.64 Plug 39.38.15 Agitator for powder 58.33.64 Plug 27.55.59 Ring 25.61.56 Ring 60.00.43 Bearing N° Code Quantity Description 35.10.07 Spacer 41.10.05 35.20.05 Fork 60.00.31 Bearing 63.80.02 Cross...
- Page 17 Accessories Code 99.15.59 99.12.56 99.12.52 99.12.05 The tapered spouts without end deflector are used for spreading on rows of trees, etc. For each shorter spout there is a corresponding narrowed inter-row spout. This system ensures that the fertiliser is spread almost entirely at the sides, over a band approximately 3' wide, leaving a central strip parallel to the tractor still to be spread –...
- Page 18 NOTES __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________ __________________________________________________________________________...
- Page 19 Imported and Distributed by: P.O. Box 578 30 Hurlstone Drive New Plymouth (06) 759 8402 NEW PLYMOUTH...
