Thank you for purchasing a Panasonic product.
Table of Contents
Finding the controls ......................................................................................2
Installations and connections .......................................................................4
Setting your fax telephone number ...............................................................7
Setting your logo ...........................................................................................8
Character input and command key table ......................................................9
Voice guide .................................................................................................10
Automatic dialing on the main unit ..............................................................11
Automatic dialing on the portable handset (KX-FKD401) ...........................13
Intercom ......................................................................................................15
Sending faxes .............................................................................................16
Receiving faxes .........................................................................................17
Operating the built-in answering device ......................................................20
Call block ....................................................................................................22
Specifications .............................................................................................23
This guide explains some basic features and operations, but not all of them.
For further details, see the Japanese operating instructions.
This product is designed for use in Japan.
Panasonic cannot provide service for this product if used outside Japan.
KX-PD301DL includes 1 portable handset and 1 main unit.
KX-PD301DW includes 2 portable handsets and 1 main unit.
Any details given in this guide are subject to change without notice.
This unit is equipped with the voice guide features. (Japanese only)
For details about voice guide, please see page 10.
Quick Reference Guide
Model No.
Facsimile
KX-PD301DL
KX-PD301DW
Main unit:
KX-PD301
Portable handset:
KX-FKD401
Advertisement
Table of Contents
Related Manuals for Panasonic KX-PD301DL
Summary of Contents for Panasonic KX-PD301DL
-
Page 1: Table Of Contents
For further details, see the Japanese operating instructions. This product is designed for use in Japan. Panasonic cannot provide service for this product if used outside Japan. KX-PD301DL includes 1 portable handset and 1 main unit. KX-PD301DW includes 2 portable handsets and 1 main unit. -
Page 2: Finding The Controls
Finding the controls Main unit Liquid crystal display Enhanced Record button records the previous 1 minute of the current telephone conversation. Function/Set button To record the previous 1 minute of telephone To register a function or apply a setting. conversation, press (Enhanced record). - Page 3 Finding the controls Portable handset (KX-FKD401) Liquid crystal display Earpiece How to use To redial the telephone ● numbers in the redial list. The last 10 telephone numbers dialed are stored in memory. To start a search in the ● Portable handset number and Number Display log.
-
Page 4: Installations And Connections
Installations and connections Installing the ink film Open the control panel. Pull up the green lever and open the back cover. Insert the orange Insert the ink film. gear into the left slot of the main unit. • Do not place the ink film on the back side of the control panel. -
Page 5: Installing Recording Paper (A4 Size)
Installations and connections Installing recording paper (A4 size) Open the recording paper tray. Set up the recording paper stands. Pull out the front stand first. Insert the recording paper into the Recording paper recording paper tray. (Up to 15 sheets) Printing side is Fan the stack of recording paper. -
Page 6: Connecting The Main Unit
Installations and connections Connecting the main unit After connecting... ① This unit will automatically select the dialing mode Raise the antenna. (Pulse/Tone). ② When the following is displayed, press (Function/Set) to set the date Connect the cord and and time. ﾋﾂﾞｹ... -
Page 7: Setting Your Fax Telephone Number
(Hold/Intercom) button replaces the digit with a space. To correct a mistake, press (Flash/Erase). Press (Function/Set). ﾄｳﾛｸ ｼﾏｼﾀ Press (Stop). Charger After your Panasonic battery is fully charged, it will last up to about 5 hours of conversation. -
Page 8: Setting Your Logo
Setting your logo Example: Micah 1. Press once. ｱﾅﾀﾉ ﾅﾏｴ？ [ AB ] Cursor 2. Press six times. ｱﾅﾀﾉ ﾅﾏｴ？ [ AB ] 3. Press six times. Press (Function/Set). ｱﾅﾀﾉ ﾅﾏｴ？ [ AB ] ｷﾉｳ ﾄｳﾛｸ ﾓｰﾄﾞ 4. Press to move the cursor to the next space Press and press four times. -
Page 9: Character Input And Command Key Table
Character input and command key table Pressing the dial keys will select a character as shown below. Character Katakana Alphabets Numbers Display of the main unit and the ［ｶﾅ］ ［AB］ ［12］ portable handset Dial key Portable Main handset unit KX-FKD401 アイウエオ... -
Page 10: Voice Guide
Voice guide Operation guide The unit starts the following voice guidance in Japanese: Operations To cancel the operation guide (using the main unit) Send a fax (Select “ ﾅｼ ” ) Copy Store telephone numbers in the one-touch dialers (Select “ ﾅｼ ” ) Make a call using the phonebook/ redial/one-touch dialer/caller ID log Print fax documents from the memory... -
Page 11: Automatic Dialing On The Main Unit
Automatic dialing on the main unit Storing names and telephone Making a voice call using the numbers in the phonebook phonebook You cannot store directly in the phonebook of the main unit. You need to transfer the stored phonebook of the portable handset to the main unit. - Page 12 Automatic dialing on the main unit Storing telephone numbers in the Making a voice call using the one-touch dialer one-touch dialer Press (Function/Set). Lift the handset. Press the one-touch dial button ( Press the one-touch dial button ( Example: One-touch dial button 1 You can also make a call by pressing the one-touch ...
-
Page 13: Automatic Dialing On The Portable Handset (Kx-Fkd401)
Automatic dialing on the portable handset (KX-FKD401) Storing names and telephone Making a voice call using the numbers in the phonebook phonebook Press Press (Search button) repeatedly until “ ｲﾁﾗﾝ ｹﾝｻｸ ” is displayed. Press Press (Search button) repeatedly until the desired name is displayed. - Page 14 Automatic dialing on the portable handset (KX-FKD401) Storing names and telephone Making a voice call using the numbers in the one-touch dialer one-touch dialer You can store up to 2 phonebook entries as the one- Press touch dialer. Press the one-touch dial button ( You can also make a call by pressing the one-touch ...
-
Page 15: Intercom
Intercom An intercom is available between the portable handsets or between the main unit and portable handset(s). Using the main unit: Using the portable handset (KX-FKD401): For single portable handset users For single portable handset users Press (Hold/Intercom). ①... -
Page 16: Sending Faxes
Sending faxes Sending a fax manually Sending a fax using automatic dialing Document Document Document guides Using the phonebook Open the document cover, and adjust the width of the Insert the document (up to 5 pages) FACE UP until a document guides (blue) to the size of the document. -
Page 17: Receiving Faxes
Receiving faxes Receiving faxes Receiving a fax manually (AUTO ANSWER off) Using the main unit: You can select whether to receive faxes on recording paper or in memory. Receive on The received fax will be recording paper printed on recording paper. When the unit runs out of When you hear a ring, lift the handset to answer the the recording paper or the... -
Page 18: Receiving A Fax Automatically
Receiving faxes Receiving a fax automatically Printing all the new faxes (AUTO ANSWER on) received in the memory light on Turn the (Auto Answer) light on by pressing When new faxes are received in memory, the following will be displayed. ﾌｧｸｽｶﾞ... - Page 19 Receiving faxes Printing a specific fax stored in Deleting a specific fax stored in memory memory When not using Number Display Service Press (Caller ID Log/Fax Print). When using Number Display Service Press (Caller ID Log/Fax Print), then press (Select button).
-
Page 20: Operating The Built-In Answering Device
Operating the built-in answering device Recording your own greeting Activating the answering device message light on You can record your own greeting message. When receiving a call, it will be played to callers instead of the pre-recorded Japanese greeting message. Turn the (Auto Answer) light on by pressing The greeting message will be played back. - Page 21 Operating the built-in answering device Listening to all of the recorded Operating the answering device messages from a remote location Press (Playback/Record) when new messages light on are not recorded. When new messages are recorded, only the new messages will be played back. After the messages are played back, the following will be displayed.
-
Page 22: Call Block
Call block Blocking the incoming calls Using the main unit: Using the portable handset (KX-FKD401): To block a call using a message While the unit is ringing, press twice. To block a call using a message While the unit is ringing, press (Block). -
Page 23: Specifications
Specifications KX-PD301DL Portable handset Main unit Battery charger KX-PD301DW (KX-FKD401) Ni-MH battery Power supply AC 100 V (50 Hz/60 Hz) (Part no. KX-FAN55) AC 100 V (50 Hz/60 Hz) DC 2.4 V, 650 mAh • Charging: Transmission: Approx. 10 W Approx. - Page 24 PNQX5333ZA Y1011TU0 Panasonic System Networks Co., Ltd. 2011...
