WZE - 3
Instruction Manual
As of: July 2008
,
.
ALL ARTWORK
PICTURES AND TEXTS ARE COVERED BY OUR COPYRIGHT
(
.
.
-
-
)
.
THEY MUST NOT BE COPIED FOR REPRODUCTION
E
G
ON CD
ROM DISKS OR INTERNET
SITES
OR USED IN THEIR ENTIRE FORM OR IN EXCERPTS WITHOUT OUR PREVIOUS WRITTEN AGREEMENT
-
-
,
.
IF YOU ARE DOWNLOADING PDF
FILES FROM OUR INTERNET HOME
PAGE FOR YOUR PERSONAL USE
MAKE SURE TO CHECK FOR UPDATED VERSIONS
,
.
WE CANNOT TAKE ANY LIABILITY WHATSOEVER FOR DOWNLOADED FILES
AS TECHNICAL DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for ARRI Wireless Zoom Extension Unit WZE - 3
- Page 1 WZE - 3 Instruction Manual As of: July 2008 ALL ARTWORK PICTURES AND TEXTS ARE COVERED BY OUR COPYRIGHT THEY MUST NOT BE COPIED FOR REPRODUCTION ON CD ROM DISKS OR INTERNET SITES OR USED IN THEIR ENTIRE FORM OR IN EXCERPTS WITHOUT OUR PREVIOUS WRITTEN AGREEMENT IF YOU ARE DOWNLOADING PDF FILES FROM OUR INTERNET HOME PAGE FOR YOUR PERSONAL USE...
-
Page 2: Table Of Contents
2. Safety Instructions and Legal Disclaimer ... 4 2.1 Safety instructions 2.2 Disclaimer ... 6 3. General Description ... 11 3.1 ARRI Order numbers 4. Setup ... 12 5. Operation of the WZE-3 6. Specifications ... 16 7. ARRI Service ... - Page 3 This page is left intentionally blank...
-
Page 4: Safety Instructions And Legal Disclaimer
ARRI, as they may cause hazards and void the warranty. Do not repair any part of the system. Repairs must only be carried out by authorized ARRI repair shops. Do not remove any safety measure of the system. -
Page 5: Product Identification
Do not operate the system in high humidity areas or expose it to water or moisture. Do not place the system on an unstable cart, stand, tripod, bracket, or table. The system may fall, causing serious personal injury and damage to the system or other objects. Operate the system using only the type of battery indicated in the manual. -
Page 6: Disclaimer
In no event shall ARRI or its subsidiaries be liable for or you have a remedy for recovery of any special, direct, indirect, incidental, or... - Page 7 In the case one or all of the forgoing clauses are not allowed by applicable law, the fullest extent permissible clauses by applicable law are validated. ARRI is a registered trademark of Arnold & Richter Cine Technik GmbH & Co Betriebs KG.
- Page 8 This page is left intentionally blank...
-
Page 9: General Description
ARRI Wireless Remote System („Yellow Radio“). Main features • Light-weight 1-channel radio unit • Fits perfectly to the ZMU-3 - no cabling • Battery power supply for both the WZE-3 and ZMU-3 • fully integrated in the ARRI Wireless Remote Ssytem... - Page 10 battery release button ZMU-3 connector WZE top view WZE bottom view (without battery) 05.21430.0 Battery Charger antenna on/off low battery active radio connection WZE-3 ready radio channel selector switch 05.21208.0 Li-Ion Battery attaching the WZE-3 to the ZMU-3 K4.65860.0 ZMU-3 Bracket assy.
-
Page 11: Arri Order Numbers
ARRI Order Numbers K2.65150.0 Wireless Zoom Extension Unit WZE-3 K4.65860.0 ZMU-3 Bracket assy. 05.21208.0 Li-Ion Battery 7,2V 11.8Wh 05.21430.0 Battery Charger 05.20368.0 Power Cord EU 05.20369.0 Power Cord UK 05.20370.0 Power Cord US... -
Page 12: Setup
4. Setup Attaching the WZE-3 to the ZMU-3 Plug the WZE-3 onto the ZMU-3 and secure the connec- tion using the ZMU-3 bracket K4.65860.0 ZMU-3 Bracket assy. Slide the bracket over the ZMU-3 rosette, rotate it, until the lug hides under the WZE-3‘s knurled screw. Fasten the bracket on the WZE-3 and use a 3mm hex wrench to secure the bracket on the ZMU-3‘s rosette edge. - Page 13 Due to local telecommunications regulations, only certain channels are allowed in some countries. The WZE-3 must be used in odd numbered channels in France. In all other countries, radio channels from 0-7 may be programmed if there are no local telecommunication restrictions for the 2.4 GHz ISM-band.
-
Page 14: Operation Of The Wze-3
5. Operation of the WZE-3 Slide-in the battery into its compartment. Switch-on the WZE-3 using the blue „on/off“ button. The unit tries to connect to a corresponding radio unit. If ok, both the „ready“ and „RF-active“ LEDs glow green after a few moments. If not, check the following table: signal description green... -
Page 15: Battery Maintenance
Battery maintenance The following batteries are recommended for use with the WZE-3: SONY NP-FM Series (e.g. NP-FM 500H) Recommended Charger: SONY BC-VM50 For safety purposes do not use other than the recom- mended charger and battery types. Please also take note of the following directives for battery handling: Do not incinerate Do not expose to temperatures beyond... -
Page 16: Specifications
3.74*1.97*1.93in (5.4*1.97*1.93in) Weight 215g (7.6oz) complete with bracket assy. (without battery) Declaration of Conformity We, Manufacturer ARRI CINE + VIDEO GERÄTE GmbH Mariahilfer Strasse 136 A-1150 Wien declare that the product Wireless Zoom Extension Unit WZE-3 is in conformity with... -
Page 17: Arri Service
Etobicoke, Ontario Canada M8W 4W3 phone: +1 416 255 33 - 35 fax: +1 416 255 33 - 99 E-mail: service@arrican.com ARRI Australia PTY Limited. Australia Unit 6C, 5 Talavera Road Macquarie Park NSW 2113 Sydney Australia phone: +61 2 9855 - 4308... - Page 18 © ARRI 2008 WZE User Manual ARRI Order no. K5.67921.0 ARNOLD & RICHTER CINE TECHNIK Türkenstr. 89 D-80799 München Phone +49 (0)89 - 3809-0 Fax +49 (0)89 - 3809-1244 www.arri.com...
