NORBAIN XM17HD-LED User Manual

Tft lcd monitor
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
USER' S
TFT LCD MONITOR
MANUAL
MODEL: XM17HD-LED/ XM19HD-LED

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XM17HD-LED and is the answer not in the manual?

Questions and answers

Summary of Contents for NORBAIN XM17HD-LED

  • Page 1 USER’ S TFT LCD MONITOR MANUAL MODEL: XM17HD-LED/ XM19HD-LED...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS CE information ------------------------------------------------------------------------ 3 Safety Precautions ------------------------------------------------------------------- 3 Scope -------------------------------------------------------------------------------------- 5 Functional specification ------------------------------------------------------------- 5 Controls and indicators -------------------------------------------------------------- 7 OSD Menu -------------------------------------------------------------------------------- 8 Regulatory Agency ------------------------------------------------------------------- 19 Reliability ------------------------------------------------------------------------------ 19 Mechanical ------------------------------------------------------------------------------ 20...

  • Page 3: Ce Information

    CE INFORMATION The product must be installed according to the currently valid installation regulations for EMC to guarantee the designed use and to prevent EMC problems. The device supplied with this manual is according to the EC, EMC Directive, 2004/108/EC, LVD 2006/95/EC and RoHS 2011/65/CE SAFETY PRECAUTIONS 1.
  • Page 4 When replacement parts are required, be sure that the service technician uses components specified by the manufacturer which have the same characteristics as the original parts. UNAUTHORIZED SUBSTITUTIONS MAY RESULT IN FIRE, ELECTRICAL SHOCK OR OTHER HAZARDS. Upon completion of any service or repairs, ask the technician to perform safety checks to determine that the equipment is in safe operating condition.

  • Page 5: Scope

    1. Scope This specification is used to define the performance of XM xx HD series color TFT LCD (LED Backlit) monitor. This system supports both video input and PC input. In video input mode, the system can automatically detect PAL or NTSC signals. In PC mode, this system can support up to 1280 x 1024 VESA standard.
  • Page 6 2.5 Audio Input Signal Level: 1.0 Vrms 2.6 Environmental Temperature Operating: 0 C to +40 Storage: -20 C to +60 Humidity Operating: 10% to 85% (non-condensing) Storage: 10% to 95% (non-condensing) 2.7 EDID This series of displays support EDID, but does not support DDC2B function. 2.8 Connectors VIDEO AUDIO: Stereo Phone Jack x2, OUT x1, IN x1...

  • Page 7: Controls And Indicators

    3. Controls and indicators A. “i” Channel button Press the button to select input signal. B. “-“ / “+” buttons Press the buttons to scrolling the cursor to desired function. Press the buttons to adjust the value of selected function in sub OSD menu. C.

  • Page 8: Osd Menu

    4. OSD Menu Hot key ： - / + VOLUME：Press button to enter the function and press buttons to adjust the volume value, then press MENU button to exit OSD menu.. FREEZE：Press button to enter the function and press any button to release the function.
  • Page 9 PC mode ： MAIN ADJUST, COLOR ADJUST, IMAGE ADJUST (VGA only), INFORMATION, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enable MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 10 MAIN ADJUST： - / + 1. Press buttons to select an item, then press MENU button to Enter adjust item or function. - / + 2. Press buttons to adjust the value, then press MENU button to Exit adjusts. VIVID MODE：Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS：Adjust the brightness value CONTRAST：Adjust the contrast value...
  • Page 11 COLOR ADJUST：Press MENU button to enter the sub-menu Set the color temperature of the LCD monitor for the CIE coordinate 9300˚k or 6500˚k or USER MODE - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item, - / + 3.
  • Page 12 IMAGE ADJUST (VGA only)：Press MENU button to enter the sub-menu - / + 1. Press buttons to select an item 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return AUTO ADJUST：Press...
  • Page 13 LANGUAGE：Press MENU button to enter the sub-menu - / + 1. Press buttons to select language 2. Press MENU button to enter SETUP MENU：Press MENU button to enter the sub-menu - / + 1. Press buttons to select an item 2.
  • Page 14 AUTO SHIFT：Adjust AUTO SHIFT ON/OFF OFF – No Function ON – Every one hour there will one scan line from bottom to top to prevent panel sticking. AUTO SHIFT line EXIT：Press MENU button to return to the main menu RECALL：Recall the Brightness, Contrast, Sharpness, Saturation, Tint, Volume value of the mode data and DLC = ENABLE, Vivid Mode = USER, OSD Timeout = 15, Green Mode = OFF, Auto Shift = OFF, then press MENU...
  • Page 15 - / + 3. Press buttons to adjust the value(ON or OFF) 4. Press MENU button to return CVBS1：Setting the audio input source in CVBS1 channel CVBS2：Setting the audio input source in CVBS2 channel S-VIDEO：Setting the audio input source in S-VIDEO channel VGA：Setting the audio input source in VGA mode HDMI：Setting the audio input source in HDMI mode EXIT：Press...
  • Page 16 Video/HDMI mode ： MAIN ADJUST, COLOR ADJUST, SCAN SETTING, INFORMATION, LANGUAGE, SETUP MENU, RECALL, AUDIO CONTROL, EXIT Press MENU button to enable MAIN MENU. - / + Press buttons to select an item, then Press MENU button to enter the function or next sub menu.
  • Page 17 2. Press MENU button to select adjust item, - / + 3. Press buttons to adjust the value 4. Press MENU button to return VIVID MODE：Select the VIVID MODE (0~3 and USER) 0: NORMAL, 1: TEXT, 2: PHOTO, 3: MOVIE BRIGHTNESS：Adjust the brightness value CONTRAST：Adjust the contrast value SHARPNESS：Adjust the sharpness value...
  • Page 18 Video mode： ： ： ： HDMI mode： ： ： ： - / + 1. Press buttons to select an icon 2. Press MENU button to select adjust item - / + 3. Press buttons to adjust the value 4. Press MENU button to return OVERSCAN：Select scan mode is Over scan, Under scan or 4:3...

  • Page 19: Regulatory Agency

    5. Regulatory Agency 5.1 Safety Approvals This series design shall meet the standards of the following domestic and foreign agencies: CE LVD : EN 60950-1:2006+A11:2009+A1:2010+A12:2011 5.2 EMI/EMS Emission Approvals This series design shall meet following EMI/EMS specifications: CE COMPLIANCE: EN55022:2010+AC:2011 class B, EN55024:2010, EN50130-4:2011 6.

  • Page 20: Mechanical

    7. Mechanical 7.1 Cabinet Material: Plastic Finish: Black 7.2 Dimensions Unit: mm Model XM17HD-LED XM19HD-LED...
  • Page 21 NORBAIN SD LTD 210 Wharfedale Road Winnersh Triangle Wokingham Berkshire RG41 5TP ubject to change without notice United Kingdom 1-3121-1954G02...

This manual is also suitable for:

Xm19hd-led
