Summary of Contents for Comfort audio Sync DY10

  • Page 1 Comfort Digisystem User Manual SecureStream Technology Sync DY10 English...
  • Page 2: Table Of Contents

    User Manual Contents Page Introduction to Comfort Digisystem Introducing Sync DY10 Functions – Sync DY10 Getting started First use Menu Radio range and channels Accessories included Troubleshooting Service and warranty Technical data Important safety instructions Mounting Instructions Sync DY10...
  • Page 3: Introduction To Comfort Digisystem

    Before using the product, please read through the User Manual. Comfort Digisystem is equipped with SST – SecureStream Technology – digital technology that enables interception-proof radio transmission in real time. Sync DY10...
  • Page 4: Introducing Sync Dy10

    Introducing Sync DY10 Sync DY10 is a device that is mounted on the wall or placed on a table in, for example, a classroom, a lecture hall or a conference room. The purpose of the DY10 is to give people carrying around one or more Comfort Digisystem units easy access to the right channels and the code key for the system used in the premises, i.e.
  • Page 5: Functions - Sync Dy10

    Functions – Sync DY10 Function indicator Screw mounting Display Function button Menu button On/Off Function button Screw mounting Strain relief for Charge socket charging cable Locking screw for wall mounting Sync DY10...
  • Page 6: Getting Started

    Getting started Charging and mains connection Sync DY10 is rechargeable, but is usually powered by mains electricity. For battery operation DY10 must be charged for at least two hours before first use. An empty battery takes around two hours to charge fully.
  • Page 7: First Use

    Freely positioned unit Sync DY10 can also be placed on a table. The unit will not move, thanks to the soft rubber frame on the bottom of the unit.
  • Page 8 Function indication When Sync DY10 is operational and activated (see menu section Channels ) this is shown by means of the function indicator. When in battery operation mode the indicator flashes, and when connected to the mains it produces a constant white light.
  • Page 9: Menu

    In most European countries, channels 1, 2 and 3 are free channels that do not require a licence. Under Increased range more channels can be selected. These channels, Radio range and channels however, often require licences; see Sync DY10...
  • Page 10 When the Active box is ticked, DY10 sends out pairing information for the Connecting Channel continuously. If the Connecting Channel is not to be used, the Active box should not be ticked. Sync DY10...
  • Page 11 Therefore, set power output as low as possible, taking into account the intended area of use. The estimated range for minimum to maximum power is about 0.5-10 m, but may vary depending on the environment. Sync DY10...
  • Page 12 3 seconds of the unit being started by pressing the Menu button. A PIN code is needed to be able to unlock selected menu functions when the PIN code has been activated. If you forget your PIN code, please contact your point of purchase to unlock the unit. Sync DY10...
  • Page 13 Here it is possible to activate the desired menu language. On delivery the menu language is set to English. Factory reset Resets the unit to the factory settings. Also deletes all pairing information. About Here there is information about the software contained in the unit. Sync DY10...
  • Page 14: Radio Range And Channels

    Radio range and channels Sync DY10 has a built-in antenna. The range (how far Sync sends pairing information) is adjustable within about 0.5-10 m. This may vary depending on the environment. DY10 sends only the pairing information for the service channel 869.850 MHz.
  • Page 15: Troubleshooting

    See the section Transmission power. Service and warranty Comfort Audio AB accords a limited warranty for two years as of the date of delivery. This covers all defects of manufacture and materials. For ac- cessories the warranty period is 90 days as of the date of delivery. Local agreements or regulations may exist.
  • Page 16: Important Safety Instructions

    12) Servicing may only be performed by a service provider approved by Comfort Audio AB. Servicing is required when the product has been damaged in any way, e.g. the plug or cord has broken, liquid has...
  • Page 17 19) Never charge the product in an enclosed non-ventilated space such as a bag, case or other enclosed storage area. 20) Only batteries and charging units from Comfort Audio AB may be used. 21) You cannot change the battery yourself; please contact your point of purchase.
  • Page 18 Sync DY10...
  • Page 19: Mounting Instructions

    Mounting Instructions Wall mounting Mount the brackets for Sync DY10 on the wall. See the template below. The template is not drawn to scale. Max: 4.8mm Max: 9.8mm Min: 6mm Min: 5mm Sync DY10...
  • Page 20 Manufactured by: Comfort Audio AB Box 154, SE-301 05 Halmstad, Sweden Tel. +46 35 260 16 00 Fax +46 35 260 16 50 info comfortaudio.com www.comfortaudio.com...
