- Page 1 Wine Cabinet INSTRUCTION MANUAL Model Numbers: HW07MA HW19MA HW40RMA HW46MA BEFORE USE, PLEASE READ AND FOLLOW ALL SAFETY RULES AND OPERATING INSTRUCTIONS.
-
Page 3: Disposal Of Old Appliances
DISPOSAL OF OLD APPLIANCES Before disposing of an old appliance remove any plugs and power leads to ensure that the appliance is inoperative. Remove the door, but leave the shelves in place to prevent children climbing inside. This symbol on the product indicates that it must not be discarded as general household waste. Instead it should be handed over to the applicable collection point for the recycling of electrical and electronic equipment. -
Page 4: Electrical Requirements
• in the Electrical Requirements section. HW07MA This model is designed for built-in installation only. Cooling air is taken in through the vents in the front plinth. This area must be kept clear when the appliance is installed. Appliance dimensions are 870 x 147 x 475mm (H x W x D). -
Page 5: Operating Your Wine Cabinet
Reversing the Door Note: The door on the HW40RMA model is not reversible. HW07MA, HW19MA, HW46MA These models are supplied with the door opening from the left hand side. To reverse the opening direction, please follow the instructions given below: •... - Page 6 Setting the Temperature Control Set the required temperature by pressing the SET button. The display will scroll through the available temperature • settings in decrements of 1°C. When the button is pushed for the first time, the display will show the default temperature (12°C).
- Page 7 ON/OFF Switch To turn OFF the appliance, press the ON/OFF button. (Press and hold the button for approximately 2 seconds) °C/°F Switch Press to select whether the temperature is displayed in degrees Celsius or Fahrenheit. Light Switch Press to turn the interior light on/off. UP Button Press to increase the set temperature in 1°C increments.
- Page 8 “Upper Chamber” Display • Indicates the temperature of the upper compartment. “Lower Chamber” Display • Indicates the temperature of the lower compartment. Setting the Temperature Control • The upper and lower compartments of the wine cabinet are independently controlled. The temperature setting of the upper compartment can be set between 5 - 12°C (40 - 54°F).
-
Page 9: Care And Maintenance
HW40RMA The bottles on the top five shelves should be positioned into the slots in the shelves so that the necks of the bottles are adjacent to each other. The bottles on the bottom two shelves can be laid side by side in the slots in the shelves. The shelves can be removed if larger bottles are to be stored. - Page 10 Cleaning Your Wine Cabinet • Turn off the power, unplug the appliance and remove all items including the shelves. • Wash the inside surfaces with a warm water and baking soda solution. The solution should be about 2 tablespoons of baking soda to a litre (2 pints) of water. •...
-
Page 11: Troubleshooting Guide
PROBLEMS WITH YOUR WINE CABINET? If you have a problem with your Wine Cabinet please consult the troubleshooting guide below for a possible solution to the problem before you call a Service Engineer. TROUBLESHOOTING GUIDE PROBLEM POSSIBLE CAUSE Wine Cabinet does not operate. Appliance not plugged in or power not switched on.
